3Com 3C54321 Installation Manual page 5

10/100BASE-TX F
6 Tighten the captive screws to secure the module in the chassis.
Figure 2 Installing the 10/100BASE-TX Module
R
R N S
PWR RUN
Injector/Ejector handle
After you have installed the module, see Chapter 4: Cabling the System in
your Getting Started Guide for information about cabling your module to
the network.
The system resets itself when you install a module with the power on or
when you remove and reinstall the power cord.
If you physically change the configuration of the system after you have
defined an IP interface, the port designated for that interface may no
longer be valid. You may need to redefine the interface using the
ip interface define
see the Command Reference Guide. For additional information about
defining IP interfaces, see your system's Implementation Guide. These
documents are on the Software and Documentation CD.
E
AST THERNET
PCMCIA
INS
ERROR
SYS INS PS1 PS2 FAN TEMP SERVICE
100 BASE - TX
3C54321
PWR
ERR
Captive screw
command. For details about this command,
M I G
ODULE NSTALLATION
ETHERNET
MODEM
TERMINAL
10BT
1X 2X 3X 4X 5X 6X
L E T L E T L E T L E T L E T L E T
INS
100BASE-TX
5
UIDE
module
