Before You Install

Read before
installing in an
empty slot
1 Loosen the two captive screws that secure the faceplate to the chassis.
2 Move the injector/ejector handles to the outward position.
3 Pull the faceplate away from the system. See Figure 1. Save the faceplate
R
10/100BASE-TX F
Before you install your new module, follow the appropriate preinstallation
instructions in this section, depending on whether you are installing the
initial 10/100BASE-TX module or replacing one.
Your system is shipped with no modules installed and with protective
faceplates covering the installation slots. Before you install the module,
remove the protective faceplate that covers the selected installation slot.

To remove the faceplate:

for future use.
Figure 1 Removing the Faceplate
N
R S
PWR RUN SYS
Injector/Ejector handle
E
AST THERNET
PCMCIA
INS
ERROR
PS1 TEMP CONFIG
INS PS2 FAN
Captive screw
M I G
ODULE NSTALLATION UIDE
ETHERNET
MODEM TERMINAL
10BT
Faceplate
3
