Summary of Contents for Ironton 61450
- Page 1 7 Inch Wet Tile Saw Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #61450 READ & SAVE THESE INSTRUCTIONS...
- Page 2 ® Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Grounding .............................. 7 Extension Cords ............................ 8 Main Parts of Tile Saw .......................... 9 Assembly Instructions .......................... 9 Before Each Use .......................... -
Page 4: Intended Use
Intended Use The Ironton 7 Inch Wet Tile Saw is designed for cutting ceramic and clay paving, wall tiles, slate, marble, granite, clay, and terracotta wall and floor tiles. Packaging Contents Tile Saw Water Tank Parallel Guide Miter Gauge ... - Page 5 Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. ...
-
Page 6: Specific Operation Warnings
Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with the power switch is dangerous and must be repaired by an authorized service representative before using. Disconnect the power/air supply from the product and place the switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. -
Page 7: Grounding
Always run with cold water. Grounding ⚠WARNING This machine must be grounded while in use to protect the operator from electrical shock. This unit is equipped with an electrical cord that has an equipment grounding conductor and a grounding plug. -
Page 8: Extension Cords
Extension Cords ⚠WARNING USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause overheating. -
Page 9: Main Parts Of Tile Saw
Main Parts of Tile Saw Subassembly Table Power Switch Switch Plate Fixed Clamp Tray Fence Upper Blade Guard Assembly Instructions 1. Insert the adjusting bracket (1) but do not tighten the screws (M4x10). 2. Fit the diamond cutting wheel. Insert the inner flange (3) in the drive shaft. Mount the cutting wheel (4) on the inner flange (3) (note the direction of rotation). -
Page 10: Before Each Use
Before Each Use ⚠WARNING Ensure the saw is on a flat level stable surface before use. Mount the saw on a steady, dry, and clean workbench that is sturdy enough to support it. Do not use the tile saw before it has been completely assembled and installed according to the instructions. - Page 11 Ensure the blade comes to a complete stop before removing material. Only operate with the guards in place. Do not use toothed blades. Never attempt to free a stalled wheel without first turning the saw OFF and disconnecting the saw from the power source.
- Page 12 Installing the Blade (not included) 1. Unthread the two screws holding the lower blade guard in place. Remove the screws, washers, and lower blade guard. 2. Slide the hex wrench onto the hex nut and the slotted wrench onto the spindle. 3.
-
Page 13: After Each Use
After Each Use ⚠WARNING Store the saw out of reach of children, animals, and other untrained persons. Do not use solvents to clean the saw. Maintenance ⚠WARNING When servicing a tool, use only identical replacement parts. Always unplug the saw before performing any maintenance. -
Page 14: Troubleshooting
Troubleshooting Use the table below to troubleshoot problems before contacting service personnel or your local dealer. If the problem continues after troubleshooting, call your local dealer for assistance. Failure Possible Cause Corrective Action Power is OFF and the cord is not Check the power at the outlet to be The saw will not start. -
Page 15: Parts List
Parts List Reference Part Description Quantity Screw M4×10 Flat washer 4 Lower blade guard Lower blade plate Nut M12×1.5 Outer flange Blade Inner flange Screw M5×10 Flat washer 5 Carry handle Riving knife Screw M4x10 Knob Upper blade guard Lock nut M5 Miter guard Work table Frame... -
Page 16: Replacement Parts
Reference Part Description Quantity Screw M5×16 Switch plate Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 17: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 18 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 18 of 18...
