- Page 1 3 Inch Cutoff Saw Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #61447 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Grounding .............................. 7 Extension Cords ............................ 8 Main Parts of Saw ..........................9 Before Each Use ............................ 9 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Ironton 3 Inch Cutoff Saw has an adjustable cutting guard that can easily be rotated to a safe, convenient position without extra tools. This cut-off saw also features a safety power-on switch to prevent accidental start-up, and overload protection to protect the motor from damage. - Page 5 ⚠WARNING WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. ...
-
Page 6: Specific Operation Warnings
Check for damaged parts before each use. Carefully check that the product will operate properly and perform its intended function. Replace damaged or worn parts immediately. Never operate the product with a damaged part. Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with the power switch is dangerous and must be repaired by an authorized service representative before using. -
Page 7: Grounding
the direction opposite of the accessory’s rotation at the point of the binding. Maintain a firm grip on the saw and position your body and arm to allow you to resist kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during start-up. -
Page 8: Extension Cords
Tools marked Double Insulated do not require grounding. They have a special double insulation system which satisfies OSHA requirements and complies with the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. (See Figure B.) Double insulated tools may be used in either of the 120 volt outlets shown in the following illustration. -
Page 9: Main Parts Of Saw
Main Parts of Saw Reference Subassembly Guard Guard Locking Lever On/Off Switch Cut-Off Disc Hex Screw Before Each Use ⚠WARNING Inspect the accessory for any damages (chips, cracks, tears, excess wear, and loose or cracked wires). Be sure the cut-off disc is in good condition and properly installed on the saw. ... -
Page 10: Operating Instructions
Operating Instructions ⚠WARNING To reduce the risk of injury, use proper guards and use only accessories rated at least equal to the maximum speed marked on the tool. To reduce the risk of injury always wear eye protection ... - Page 11 Installing the Guard 1. Push the guard locking lever outward from its locked position. Slide the guard mounting clamp over the guard mount on the saw. Place the detent so it will slide over the slot in the guard mount. 2.
- Page 12 4. Slide the cutting disc into the guard and place it over the spindle shoulder so it rests flat against the large spindle flange. 5. Re-install and tighten the flange washer and hex screw. General Cutting 1. Mark the workpiece where the cut is to be made. 2.
-
Page 13: After Each Use
After Each Use ⚠WARNING Never touch the blade during or immediately after use; the blade will be extremely hot. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the saw or these instructions to operate it. -
Page 14: Parts Diagram
Parts Diagram Page 14 of 17... -
Page 15: Parts List
Parts List Reference Part Description Quantity Housing Switch button spring Switch button Shank spring Switch shank Switch Tapping screw ST3.9X10 Cord clamp Back cover Brush assembly Carbon brush Tapping screw ST3.9X10 Cord guard Cord Tapping screw ST3.9X14 Aluminum cover Bearing 629-2RS Bearing retainer Recessed screw ST3.9X8 Rotor... -
Page 16: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 17 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 17 of 17...
