Installing Cards and Jumpers,
Continuity Check for Model
4190-8103 with UL Card
Installed
Continued
For 4190-8103 IMS systems with the terminal block mounted to the PC chassis,
verify the information listed in Table 6-11.
Table 6-11. IMS 4190-8103 Model with UL Card ⎯ Device
Connection Points for Outputs 1 and 2
Location
TB1-2 to TB1-4
TB1-8 to TB1-10
TB1-4 to TB1-6
TB1-10 to TB1-12
6-9
Value
Short (<1 ohm)
Short (<1 ohm)
Open Circuit
Open Circuit
Function
Output #1 Relay
Normally Closed
Output #2 Relay
Normally Closed
Output #1 Relay
Normally Open
Output #2 Relay
Normally Open
