Jumper Settings

RS-232 Media Card
(P/N 565-327)
Wired Media Card
(P/N 565-413)

Fiber Optic Media Assembly

Table 6-3 lists the jumper configurations for all RS-232 media cards.
Table 6-3. RS-232 Media Card ⎯ Jumper Positions
Jumper
Network Media Mother Board
P3
Service Port
Media Mother Board
P4
Network and Service Port
Supervised
P5
Unsupervised
Table 6-4 lists the jumper configurations for all wired media cards.
Table 6-4. Wired Media Card ⎯ Jumper Positions
Jumper
18 AWG (0.8231 mm
P2
24 AWG (0.2047 mm
There are no jumpers on the fiber optic media assembly.
6-4
Function
Function
2
) Cable
2
) Cable
Position
1-2 (default)
2-3
1-2 (default)
2-3
1-2 (default)
2-3
Position
1 & 2
3 & 4
5 & 6
7 & 8
3 & 4
