Connecting the IMS to the System,
Connecting a Touchscreen
Monitor

Connecting the Mouse

Connecting the Keyboard

Connecting the Software Key

Connecting the Printer
(Optional)
Continued
Position the monitor close enough to the PC so that you can connect the cables
from the monitor to the PC and perform the following steps:
1. Connect the touchscreen controller cable to PC Serial Port, COM 1 or
COM 2 is preferred.
2. Connect the other end of the cable to the touchscreen input connector on the
back of the monitor.
Connect the mouse by completing the following steps:
1. Locate the mouse/keyboard connector on the back of the PC.
2. Plug the connector on the end of the mouse cable into the mouse/keyboard
adapter cable on the PC.
Connect the keyboard by completing the following steps:
1. Locate the mouse/keyboard connector on the back of the PC.
2. Plug the connector on the end of the keyboard cable into mouse/keyboard
adapter cable on the PC.
If you have a parallel software key, connect it by completing the following
steps:
1. Locate the LPT1 connector on the back of the PC.
2. Plug the software key into the LPT1 connector.
3. If desired, plug the printer cable into the software key.
If your PC has a working USB port, you may connect a USB software key by
inserting it into the USB Port.
NOTE: THIS SHOULD BE DONE AFTER THE SECURITY SERVICE
SOFTWARE IS INSTALLED ON THE PC.
For instructions on installing the Security Service, refer to Installing the
Software Security System, 579-825.
Connect the printer by performing the following steps:
1. Locate the serial Com port on the PC that was selected in the program.
2. Plug harness 733-937 into the printer and complete the connections per
Printer Installation Instructions 579-233.
2-7
Continued on next page
