Connecting the 2120 Nodes to the IMS (Retrofit Applications Only),
Continued
Installing with Adapter Cable
(Continued)
REAR VIEW OF QUAD
SERIAL CARD 566-693
LOCATED INSIDE THE IMS
6
1
3 : RXD
4 : CTS
CH. 4
8 : GND
10
5
9 : TXD
CH. 3
CH. 2
CH. 1
NOTES
INSTALLED CABLE 18AWG, OR TO LOCAL CODE.
1
2500 FEET MAX.
2
RS232 BAUD RATE IS 1200.
3
RS232 POWER IS 10 mA (MAX. ).
Installing without Adapter
Cable
TYPI C AL
4190 IMS
TYPICAL CONNECTION
ON QUAD SERIAL
PORT CARD
6
1
10
5
JUNCTION BOX
RED
WIRE A
Pin 2
BLK
WIRE B
Pin 3
GRN
WIRE C
Pin 7
WHT
n/c
If your RS-232 card has a DB25 male connector, complete the following steps.
Refer to Figure 5-1 for help. (If it has a DB9 male connector, complete the
steps in the previous section.)
1. Ensure that the power is OFF before starting this procedure.
2. Complete all wiring according to the wiring shown in Figure 5-1.
3. Use the junction boxes at each end of the installed cable to terminate the
field wiring between harness 733-571 and 733-572.
4. Complete Steps 1 through 3 for each node you are installing.
5. After connecting the node(s) to the IMS, turn the power ON. The IMS
automatically boots up to the initial program screen.
Assy: 733-572
Assy: 733-571
RED
4
BLACK
GREEN
1
2
4
Assy: 733-572
FOR CANADIAN INSTALLATIONS, USE LOCALLY ACCEPTED
4
TERMINAL BLOCK IN ELECTRICAL JUNCTION BOX.
Figure 5-2. Connecting 2120 BMUX Nodes to the IMS
5-5
RED
WIRE A
Pin 2
BLK
WIRE B
Pin 3
WIRE C
GRN
Pin 7
WHT
n/c
JUNCTION BOX
2120
3
BMUX
