Connecting DACRs to the IMS

Installing with Adapter Cable

If the RS-232 card has a DB9 male connector, complete the following steps.
Refer to the diagram in Figure 5-4 for help. If it has a DB25 male connector,
skip this section, and continue to the next section.
1. Ensure that the power is OFF before starting this procedure.
2. Complete all wiring according to the wiring diagram shown in Figure 5-3.
3. Use the junction boxes at each end of the installed cable to terminate the
field wiring between harness 733-571 and 733-572.
•
The total wiring length from the RS-232 port of the CPU to the RS-232
port of the DACR must not exceed 20 feet (610 cm) and must be run in
conduit.
4. Complete Steps 1 through 6 for each DACR that you are installing.
5. After connecting the DACR(s) to the IMS, turn the power ON to the
DACR.
6. Press ESCAPE to enter the configuration mode.
7. Enter CAFÉ at access code screen.
8. Press ENTER to go to the next menu item or use BACKSPACE to go to the
previous menu item until the desired menu item appears. Then press ACK
to select it.
9. At Option 01: Sys Date/Time, enter the date and time using Digits 0 – 9.
Press ENTER to move cursor to the right and BACKSPACE to move
cursor to the left. Press ESCAPE to go to the next option menu.
10. At Option 03: Numb of Lcard, change number to the actual number of
active line cards in the panel being used (1 or 2 for a base unit).
11. At Option 04: PrinterSelect, enter 0 at the enable field for no printer and 1
for printer enabled.
12. Press ESCAPE and then ENTER to go to Option 6 (COM#1 Format) before
pressing ACK.
•
Enter 1 to select Sur-Gard format before pressing ESCAPE.
13. Press ESCAPE and then ENTER or BACKSPACE to go to Option 5
(COM#1 Configuration) before pressing ACK.
14. Verify Option 5 settings.
•
The setting for COM1 should be 9600 baud, no parity, 8 bits, and 1
stop bit.
