Pottery Barn Mason Medicine Cabinet Assembly Instructions

Wall mount

Please read all instructions before beginning assembly.

For your safety and convenience, assembly by two people is recommended.

Use the parts and hardware lists to identify and separate each of the components included.

Save all packing materials until assembly is complete to avoid the accidental discarding of smaller parts or

PARTS:

1 – Cabinet – (1 x)

2 – French Cleat (1 x)

3 –Glass Shelf (3 x)

HARDWARE:

A –Toggle(Dia.1/2" x 2 1/2") – (2 x ) B –Toggle screw(Dia.1/8" x 2 1/4") - ( 2 x) C – Screw(Dia.1/8" x 2") - ( 2x )

D –Anchor(Dia.1/2" x 1 1/4") – (1x)

TOOLS NEEDED: (not included)

Phillips screwdriver

ASSEMBLY INSTRUCTIONS:

Attention: For safe mounting of this product, it is important to use the proper hardware for your wall type. The

hardware included here is meant for drywall mounting only. If your walls are made from concrete, brick or plaster,

please consult your local hardware store for assistance in selecting the appropriate hardware.

Determine the desired height of the cabinet, measure the position of French Cleat "2", use a pencil to mark the

wall through the pre-drilled holes on the ends of French Cleat "2", this mark is the insertion points for the

mounting hardware. (See Fig.1)

Fig.1

Mason Medicine Cabinet – Wall Mount

Assembly Instructions

E – Anchor screw (Dia.1/8" x 1 1/4" - (1x)

1 of 2

F – Shelf pin - (12x)

Table of Contents

Do you have a question about the Mason Medicine Cabinet and is the answer not in the manual?

Page 1 Mason Medicine Cabinet – Wall Mount Assembly Instructions Please read all instructions before beginning assembly. For your safety and convenience, assembly by two people is recommended. Use the parts and hardware lists to identify and separate each of the components included.
Page 2 Fig.2 Install the Toggle (A) into the drywall by first aligning the pointed end of the toggle (A) against the mark from previous step. Use the Phillips screwdriver to rotate the Toggle (A) clockwise as you push the toggle lightly into the wall.
Page 3 Assembly is complete. (See Fig.7) Care Instructions: Dust with a clean, soft damp cloth and wipe dry immediately. Avoid the use of chemicals and harsh cleaning agents. thank you for your purchase stores | catalog | www.potterybarn.com CAM-insert B x 2 CAM-lock A x 2 Dowel C x 2 3 of 2...
