Assembly Instructions for CAPT´N COOK - 503
Diagram1.1
Diagram1.1
Z30
W13
W2
W14
W1
For beams
Z30,Z31,S5,S6
side with the round
indentations face the
middle of the bed.
Before you begin:
1. Please take a moment to see how everything fits together
by using the diagram above. All the important building parts
have stickers to help you see how they fit into the overview.
Please note that there is a separate beam list as an
additional assembly aid. All beams are shown horizontally or
vertically as they should be positioned and assembled
together. The labels on the packages also help you to find
the content.
2. Wooden parts, if necessary, can be treated with wax or oil
before the assembly of the bed.
Advice: We advise you not to treat the bed to sustain better environment for
the children (regulating humidity in the air). In addition it saves wax and oil
costs and offers the advantage that it is easy to clean with tissues and cloth.
Two further benefits: Untreated wood is easier for childrens hands to grip
and helps sustain the natural colour of the wood.
3. For the assembly of the bed you need the following tools:
a ratchet with a size ten socket, a cross-end screwdriver
(better yet a cordless screwdriver with a changeable head
and size ten ratchet attachment) and a hammer.
Assistance is only necessary when assembling the corner
posts of the bed.
Horizontal beams with most
round indentations should
face the inner side of the bed.
W18
S2
W16
W6
W15
W24
S3
Z31
F3
B1-B16
Caution:
If you are going to attach the arm
and back rest set with your
WOODLAND bed, please read the
instructions for the arm and back
rest set before you start with the
assembly.
S7
Predrilled holes for
W17
P1
W25
Z11
Safety rail
Z27
S4
S5
F2
Diagram1.2
Diagram1.2
Not all specifications can be guaranteed.
S6
Safety rail
Z24
F1
S5
W1
110mm flathead bolt
Tighten the scews at the
bottom area and leave the
Indentations
face inside
W8
W14
W1
R
W23
W26
W22
W27
W21
W28
W20
W9
W19
W8
W20
W19
flange
nut M6
S6
S5
W19
© Copyrights by WOODLAND 1998
Advertisement
Table of Contents
Related Manuals for Woodland CAPT'N COOK 503
Summary of Contents for Woodland CAPT'N COOK 503
- Page 1 If you are going to attach the arm indentations face the middle of the bed. and back rest set with your WOODLAND bed, please read the instructions for the arm and back rest set before you start with the Before you begin: assembly.
- Page 2 Corner beams W6: short beam is assembled below W22 or W16 bed inner side © Copyrights by WOODLAND 1998 All specifications are not guaranteed...
- Page 3 Fix wheels to the wooden blocks from below using the screw 16 mm. WARNING! First attach the bracket on the board F2 so that the drawers slide in smoothly. WOODLAND reserves the right for printing errors © Copyrights by WOODLAND 1998...
- Page 4 Important tip: WOODLAND safety rails are double the Euro-Norm EN 747. If you have any technical questions to build the bed please contact us at 0049 2133 2482 - 19. The WOODLAND team hope that you and your family will enjoy the WOODLAND advenuture beds! Wall attachment without wooden block WOODLAND reserves the right for printing errors ©...
