Woodland MEMPHIS Assembly Instructions

Assembly Instructions MEMPHIS Post. 506
F3
W13
W14
Z31
1. 1.
Z30
W8
Z31
W14
W1
Z31

Lets begin:

1. Please take a moment to see how everything fits together by using the diagram above. All the important building parts have
labers to help you see how they fit into the overview. Please note that there is a separate beam list as an additional assembly aid.
All beams are shown horizontally or vertically as they should be positioned and assembled together. The labels on the packages
2. Wooden parts, if necessary, can be treated with natural wax or oil before the assembly of the bed.
Advice: We advise you not to treat the bed to sustain better environment for children (regulating humidity in the air). In addition it saves wax and oil costs and
offers advantage that it is easier to clean with tissues and cloth. Two further benefits: Untreated wood is easier for children to take a grip on handles and the
natural colour of the wood stays longer.
3. For the assembly of the bed you need the following tools: a ratchet with a size ten socket, a cross-end screwdriver (better yet a
cordless screwdriver with a changeable head and size ten ratchet attachment) and a hammer. Assistance is only necessary
when assembling the corner beams of the bed.
16mm 35mm
screws
flange nut M6
110 mm
flathead bolt
Z30
B1-B16
F2
Z32
2. 2.
Z30
W13
W14
W19
Z31
Start the assembly of the bed with the horizontal beams W1, W8, W14 and W19 (W = horizontal, S =
vertical). The labels as shown ´in
on the floor so that you can still walk around the bed while it is in the building phase
CAUTION! All horizontal beams (W1, W2, W8, W9) are built in a way that the side with most
round indentations (=
underneath! The surface of beam W13 with round indentations should face the inner side.
During the beam assembly install the flathead bolts from outside to inside. From the inside screw a
size 6 flange nut using a screwdriver with size 10 attachment. But do not over tighten bolts.
Z32
W9
W2
F1
W1
Z31
Z30
Z30
Z32
W9
W20
W8
W19
W2
W1
Z32 Z31
, can be found on the end of each beam. Position the beams
diagram1.1 diagram1.1
), face inside and the surface with two round indentations face
Z30
W20
W19
W8
W1
110mm flathead bolt
