5.3 Operation Of Control Units, Setting Temperature and Time
(The press must always be in the open position before the controller is set)
HOLD HOLD
STOP STOP PV PV
SV SV
COUNTER
MODE DOWN
HOLD HOLD AT AT
STOP STOP PV PV
SV
COUNTER
CLEAR DOWN
Setting Digital Counter to Zero
1. Press 'CLEAR' button and 'COR' will appear in controller window and
'COUNTER' value will flash.
2. Press 'CLEAR' button again to zero counter.
Setting Temperature
1. Switch on machine.
°C °C 2. Press 'UP' and 'DOWN' buttons to change
temperature values.
3. The
required value is achieved.
4. Press 'START/STOP' button to start
machine heating.
UP
Setting Time
1. Switch on machine.
2. Press 'UP' and 'DOWN' buttons to change
time values.
T T
3. The
required value is achieved.
4. Press 'START/STOP' button to start
machine.
UP
unit stores automatically
unit stores automatically
once
once
