Note: To power COGNIFACE INTEGRA200, plug-in the Adaptor and connect the
cable into power cable slot and Switch ON the device. This will provide power to all
the devices: IP Camera, COSEC ARGO and FR Module in COGNIFACE INTEGRA200.

What your Package contains

Ÿ Power Adaptor 12VDC, 2A
COSEC Cogniface Integra200 device unit
Ÿ
Screw Grips Plastic 8X35 - 4 Nos
Ÿ
Screw M5X25 CSK PH - 4 Nos
Ÿ
Mounting Template
Ÿ
Earthing Cable
Ÿ

Variants

The COSEC COGNIFACE INTEGRA200 have 2 variants depending on type
of ARGO device embedded. They are:
Ÿ
COSEC COGNIFACE INTEGRA200E (ARGO FOE212)
Ÿ
COSEC COGNIFACE INTEGRA200M (ARGO FOM212)

Things You will Need

Power Drill
Ÿ
A Screw Driver
Ÿ
COSEC Software with FR license.
Ÿ
7
Pre-Installation Safety Instructions
1. Do not Install the device in extremely hot temperature or under direct
Sunlight or at bright places. This may affect LCD and Finger print Sensor of
device.
2. Recommended height from ground to the top of the device is
151 cm for best results.
3. Recommended distance between the IP Camera and the Face is 60 cm
for more effective face recognization.
4. Do not install on unstable surfaces, near volatile inflammable materials,
Area where volatile Gas is created, where ferro-magnetic field or noise is
induced, where static s created, such as desk made up of plastic or carpet.
5. Do not expose the device to extreme weather condition.

Preparing for Installation

Before Wall mounting COSEC COGNIFACE INTEGRA200, follow the
below given instructions:
Connecting Earthing Cable:
Remove the Earthing Screw with the help of screw driver and connect
the provided Earthing cable in the slot.
Battery Insertion
Note: This is optional if battery backup is not needed.
Recommended Battery Specification: 3.75V, 3000mAh to 5000mAh, Li-
ion (Panasonic/ LG).
8
