Step-5
Upon opening those 12 screws, front enclosure of
with ARGO door attached will be separated from the bottom enclosure having
mounting plate as shown in figure 18. Remove DC jack and Power cable of
COSEC ARGO attached to other half-part of enclosure and keep it aside with
caution.
23
COGNIFACE INTEGRA200
Figure 18
Step-6
Fix four screws in through slots of bottom enclosure. Tighten screw 1 in screw
hole A, screw 2 in screw hole B, screw 3 in screw hole C and screw 4 in screw
hole D with the help of screw driver as shown in figure 19 below.
A
B
D
4
1
3
2
C
Figure 19
