Summary of Contents for BLAUBERG Ventilatoren Ducto
- Page 1 AXIAL FANS Ducto Operation manual...
- Page 2 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Disconnect the fan from power supply prior to any connection, servicing and repair operations. Only duly qualified electricians with valid electrical permit for electric operations at the units with operating voltage up to 1000 V are allowed for mounting and maintenance after careful study of the present user's manual.
- Page 3 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING While mounting the fan do not compress the casing! Deformation of the casing may result in the motor jam and noisy operation. Misuse of the fan and any unauthorised modifications are not allowed. Take steps to prevent ingress of smoke, carbon monoxide and other combustion products into the room through open chimney flues or other fire-protection devices.
- Page 4 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Do not use the fan in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the fan intake or extract vents in order to ensure the efficient stream.
- Page 5 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING The product is allowed to be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge provided that they have been given supervision or instruction regarding a safe use of the product and understand the risks involved.
- Page 6 Ducto-U: fan with a fixing bracket Ducto W1: fan with a power cable and a plug Ducto T: fan with a controllable timer (for details please refer to electronic control logic) Ducto Plus: fan with a two speed motor Ducto Power Plus: fan with a high-powered two speed motor OPERATION GUIDELINES The fan is rated for connection to AC single-phase 220…240 V/50 Hz or 220…240 V/60 Hz power supply, depending...
- Page 7 Wiring options are shown in Fig. 13–16. ELECTRONIC CONTROL LOGIC Ducto 100/125/150 T starts operation as the external switch supplies a control signal to the LT input terminal, for instance, during switching the light on. After the control signal is off the fan continues operating for the set time as adjusted from 2 to 30 min and then stops.
-
Page 8: Maintenance
To adjust the fan turn-off delay time, rotate the control knob Toff clockwise to increase and counter-clockwise to decrease the turn-off delay time respectively, adjustable from 2 up to 30 minutes. Ducto Plus / Ducto Power Plus 100/125/150 T (Fig. 18) Operation modes 1, 2 and 3... - Page 11 Wiring diagrams Ducto 100/125/150 Ducto Power Plus 100/125/150 speed 2: high speed 3: low speed Ducto 100/125/150 T Ducto Plus / Ducto Power Plus 100/125/150 T...
- Page 12 Ducto 100/125/150 T 2 min 30 min Ducto Plus / Ducto Power Plus 100/125/150 T off & HS time 2 min 30 min 0 min 1 hour 2 min 15 hour...
-
Page 13: Transportation And Storage Rules
TRANSPORTATION AND STORAGE RULES Transportation is allowed by any transportation vehicle provided that the product is in the manufacturer's original package. Store the delivered product in the manufacturer's original packing box in a dry ventilated premise with the ambient temperature from +5 °C up to + 40 °C and relative humidity less than 80 %. -
Page 14: Acceptance Certificate
ACCEPTANCE CERTIFICATE... - Page 15 Ducto Acceptance certificate Approval mark The fan is recognized as serviceable. Manufacturing date Plus Ducto Ducto-U Power Plus Sold (name and stamp of the seller) Sales date...
- Page 16 B01-(Ducto)EN-02...
