LEGRAND Tynetec REACH Self-Installation Instructions

The users telephone MUST BE connected to the Alarm Unit
incoming line must not be used.
TRUSTED TECHNOLOGY.
If the user has extension telephones care should be taken to ensure that these are also connected via the
CARING FOR PEOPLE
Alarm Unit
Failure to connect the users telephones as described above may cause difficulties with alarm calls – if in
doubt seek advice.
REACH/REACH
If the user has a DECT telephone the base station MUST BE at least 2 metres away from the Alarm Unit.
PLUS ALARM UNIT
Failure to provide this separation may result in reduced range of personal pendants or other radio devices.
All telephone equipment has a Ringer Equivalence Number (REN) which is used to calculate the number of
items that can be connected to a single telephone line.
A REN of 4 is the maximum allowed on a standard UK telephone line - the Alarm Unit has a REN of 1
Please find enclosed your At-Home Alarm and Touch 2 Pendant.
If the REN total of all equipment connected to a telephone line exceeds 4 the equipment may not operate
REN 1
correctly. With different types of equipment there is no guarantee of correct operation even if the REN is
All the equipment is ready to use (see below) and will be activated by following the
less than 4. Typically 1 or 2 standard telephones (REN 1) can be used with the Alarm Unit.
instructions overleaf.
Avoid using strong detergents or polish when cleaning the Alarm Unit unit or Touch pendant.
Wipe clean with a damp cloth and polish with a dry duster.
Supplied in the box...
At-Home Alarm
2. UNPACKING THE AT-HOME ALARM
The At-Home Alarm is supplied with a Power Lead, a Telecom Lead, a Touch Pendant and a wearing ki
A stand can be fitted if the unit is being mounted upright or a connector cover if it is being placed flat.
The stand/cover must be fixed with the screw provided.
At-Home Alarm
AC Adapter with UK and EU Plugs
Legrand Assisted Living & Healthcare
Blyth Workspace, Commissioners Quay, Quay Road, Blyth, Northumberland NE24 3AG.
T: +44 (0) 1670 352 371 | www.aidcall.co.uk | www.jontek.co.uk | www.tynetec.co.uk
Registered Office: Great King Street North, Birmingham, B19 2LF. Registered in England No. 00115834
1. IMPORTANT INFORMATION
FUTURE PROOF IP READY TECHNOLOGY
The users telephone MUST BE connected to the Alarm Unit
incoming line must not be used.
¢ ¢ TEL socket. If the user has extension telephones care should be taken to ensure that these are also
Alarm Unit
Failure to connect the users telephones as described above may cause difficulties with a
doubt seek advice.
If the user has a DECT telephone the base station MUST BE at least 2 metres away from
Failure to provide this separation may result in reduced range of personal pendants or o
All telephone equipment has a Ringer Equivalence Number (REN) which is used to calcu
items that can be connected to a single telephone line.
A REN of 4 is the maximum allowed on a standard UK telephone line - the Alarm Unit h
If the REN total of all equipment connected to a telephone line exceeds 4 the equipmen
REN 1
correctly. With different types of equipment there is no guarantee of correct operation
less than 4. Typically 1 or 2 standard telephones (REN 1) can be used with the Alarm Un
Avoid using strong detergents or polish when cleaning the Alarm Unit unit or Touch pen
Wipe clean with a damp cloth and polish with a dry duster.
2. UNPACKING THE AT-HOME ALARM
The At-Home Alarm is supplied with a Power Lead, a Telecom Lead, a Touch Pendan
A stand can be fitted if the unit is being mounted upright or a connector cover if it is
The stand/cover must be fixed with the screw provided.
At-Home Alarm
Power Lead
Power Lead
¢ ¢ TEL
socket.
Touch 2 Pendant
Stand
Touch Pendant
Wearing Kit
Connector Cover
Telecom Lead
Telecom Lead
Stand/Cover Screw
