RNA ESG 2000 Instructions Manual

For vibratory drives

Advertisement

Quick Links

Instructions for the Control Units
for Vibratory Drives
ESG 2000
BA
Rhein-Nadel Automation GmbH
Rhein-Nadel Automation GmbH
1
14.04.2014
VT-BA ESG2000 -GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESG 2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RNA ESG 2000

  • Page 1 Instructions for the Control Units for Vibratory Drives ESG 2000 Rhein-Nadel Automation GmbH Rhein-Nadel Automation GmbH 14.04.2014 VT-BA ESG2000 -GB...
  • Page 2 Table of contents Chapt........................Page Technical data Safety notes....................Commissioning instructions ................Operation Dimensional drawing..................Connection diagram..................Declaration of conformity as defined by Low voltage directive 2014/35/EU and EMC directive 2014/30/EU Herewith we declare that the product complies with the following provisions: Low voltage directive 2014/35/EU EMC directive 2014/30/EU applied harmonized standards:...
  • Page 3: Performance Characteristics

    Remote control input: 24V DC (10-24 VDC) Outputs: 2 optocouplers Status output (optocoupler): max. 30V DC 10mA Operating temperature: 0 ... 50° C Type of protection: IP 54 Accessoires RNA-Mat-code Label Denomination Type Manufacteur Supplier Connector Harting Mains plug C16-1 Amphenol...
  • Page 4: Safety Instructions

    Steps must be taken to ensure that all persons working with this control unit are familiar with the safety regulations and observe them. The device described in this manual is a control unit for operating RNA bowl feeders and linear feeders. The limit val- ues specified in the technical data must be observed.
  • Page 5: Operating Mode

    OPERATING MODE Bowl feeder frequency coding in connector. Operating mode 2 With bridge: 100 / 120Hz With bridge: 6000 / 7200 oscillations/min Operating mode 1 Without bridge: 50 / 60Hz Without bridge: 3000 / 3600 oscillations/min Status Outputs The status outputs are used for remote diagnostics of the control unit operating mode or for linking several control units together.
  • Page 6: Switching On The Control Unit

    Operation General ON/ OFF Cursor up Return Cursor down XS 4 Mains power switch Channel 1 Control unit plug connections Mains power The control unit is isolated from the mains with a double-pole switch. switch Channel 1 Plug connector for bowl feeder ( < 10A) XS 4 Plug connector for optocoupler outputs and remote control input The control unit display (membrane keyboard)
  • Page 7 Switch on the control unit with the mains power switch. The main menu will appear in the display showing the last set- point set in channel 1 (bowl feeder or linear feeder feed rate). KANAL l KANAL 2 CODE The following displays may also appear depending on the circuit state of the unit. The remote control has been activated but is currently not available on the unit.
  • Page 8 Soft stop time 0 - 5 sec. KANAL l KANAL 2 CODE Return Store and return to KANAL l KANAL 2 main menu CODE * For RNA-Feeder with 200 V = 90 % Rhein-Nadel Automation GmbH 14.04.2014 VT-BA ESG2000 -GB...
  • Page 9 4.5.2 Code C003 Lock Setpoint Aim: Blocking the setpoints in the main menu. The values can no longer be changed directly. Changes can only be made using code C001. Select code Set code KANAL l KANAL 2 CODE Code C003 KANAL l KANAL 2 CODE...
  • Page 10: Scale Drawing

    4.5.6 Code C210 Reset Parameters Aim: Resetting to factory settings or restoring the stored user parameters. Select code Set code KANAL l KANAL 2 CODE Code C210 KANAL l KANAL 2 CODE Factory setting KANAL l KANAL l KANAL 2 KANAL 2 CODE CODE...
  • Page 11: Connecting Diagram

    Connecting Diagram Rhein-Nadel Automation GmbH 14.04.2014 VT-BA ESG2000 -GB...
  • Page 12 Rhein-Nadel Automation GmbH Reichsweg 19/23  D - 52068 Aachen Tel (+49) 0241/5109-159  Fax +(49) 0241/5109-219 Internet www.rna.de  Email vertrieb@rna.de Rhein-Nadel Automation GmbH Zweigbetrieb Lüdenscheid Nottebohmstraße 57  D - 58511 Lüdenscheid Tel (+49) 02351/41744  Fax (+49) 02351/45582 Email werk.luedenscheid@rna.de...
