Operating and Programming
Instructions for the Control Units
of Vibratory Drives
ESK 2002
BA
Rhein-Nadel Automation GmbH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESK 2002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RNA ESK 2002

Summary of Contents for RNA ESK 2002

  • Page 1 Operating and Programming Instructions for the Control Units of Vibratory Drives ESK 2002 Rhein-Nadel Automation GmbH...

  • Page 2: Performance Characteristics

    The control unit complies with the following Control unit ESK 2002-10 manages a total output of 10 regulations: amps and control unit ESK 2002-16 a total output of 16 amps. EC - EMC Directive 89/336/EEC The unit has the following performance characteristics: EC Low voltage equipment directive −...

  • Page 3: Safety Instructions

    Commissioning Instructions The device described in this manual is a control unit for operating RNA bowl feeders and linear feeders. The limit values specified in the technical data must be Before connecting up to the mains and observed.
  • Page 4 OPERATING MODE Bowl feeder frequency coding in connector. Operating mode 2 With bridge: 100 / 120Hz With bridge: 6000 / 7200 oscillations/min Operating mode 1 Without bridge: 50 / 60Hz Without bridge: 3000 / 3600 oscillations/min Sensor Inputs and Sensor Links The control unit has two built-in sensor inputs.
  • Page 5 "Standby" "Active" channel 3 "Active" channel 2 "Active" channel 1 Remote Control channel 3 Remote Control channel 2 Remote Control channel 1 Sensor Input 1 Sensor Input 2 Rhein - Nadel Automation GmbH Page 5 Boîtiers de commande ESK2001...
  • Page 6 Operation General On/off Cursor up Enter Cursor down main switch channel 1 channel 2 channel 3 Control unit plug connections Mains power The control unit is isolated from the mains with a double-pole switch. switch XS 3 Plug connector for sensors Channel 1 Plug connector for bowl feeder ( <...

  • Page 7: Switching On The Control Unit

    Switching on the Control Unit Switch on the control unit with the mains power switch. The main menu will appear in the display showing the last setpoint set in channel 1 (bowl feeder feed rate). KANAL l KANAL 2 CODE The following displays may also appear depending on the circuit state of the unit.
  • Page 8 Programmed application examples KANAL l KANAL 2 CODE Call memorized settings P1-10 based on application examples. (ask for our catalogue fax 0241/5109-219 or by Internet www.rna.de) Output preset with an external voltage KANAL l KANAL 2 CODE Store parameters...
  • Page 9 KANAL 2 CODE * RNA-Feeder with 200 V = 90 % 4.5.2 Code C002 for Channel 2 (power output 2) Aim: Setting and limiting the vibration amplitude, the remote control, the soft start time and the soft stop time.
  • Page 10 KANAL 2 CODE * RNA-Feeder with 200 V = 90 % 4.5.4 Code C003 Lock Setpoint Aim: Blocking the setpoints in the main menu. The values can no longer be changed directly. Changes can only be made using code C001 and code C002.
  • Page 11 4.5.6 Code C006 Sensor Links Aim: Linking two previously activated sensor inputs. Select code set code KANAL l KANAL 2 CODE Code C006 KANAL l KANAL 2 CODE Only one of the eight sensor links can be set active. And (And) link with blow-off of the I = active KANAL l outlet tracks...
  • Page 12 Level control for the hopper Sensor 2 switches relay K1 according to the entered delay time (C005). When the sensor 1 is darkened, relay K1 releases (looking of the hopper). Application: Sensor 1 = back pressure control Sensor 2 = level control Relay K1 = hopper control Level control Sensor 2 switches relay K1 according to the entered delay time (C005).
  • Page 13 4.5.8 Code C009 Display Status Aim: Checking the set vibration frequency and the sensor inputs. Select code Set code KANAL l KANAL 2 CODE Code C009 KANAL l KANAL 2 CODE Remote control signal I = active K A N A L l Channel 1 0 = inactive K A N A L 2...

  • Page 14: Scale Drawing

    4.5.11 Code C210 Reset Parameters Aim: Resetting to factory settings or restoring the stored user parameters. Select code Set code KANAL l KANAL 2 CODE Code C210 KA NA L l KA NA L 2 COD E Factory setting KANAL l K A N A L l KANAL 2 K A N A L 2...

  • Page 15: Connecting Diagram

    Connecting Diagram Control Units for Vibratory Drives ESK2002 Rhein - Nadel Automation GmbH Pág. 15...
  • Page 16 HSH Handling Systems AG Wangenstr. 96 CH - 3360 Herzogenbuchsee Tel +(41) 062/95610-00 Fax (+41) 062/95610-10 Internet www.rna.de Email info@handling-systems.ch RNA AUTOMATION LTD Hayward Industrial Park Tameside Drive, Castle Bromwich GB - Birmingham, B 35 7 AG Tel (+44) 0121/749-2566 Fax (+44) 0121/749-6217 Internet www.rna-uk.com Email rna@rna-uk.com...
