Summary of Contents for RNA ESM 906
- Page 1 Operating Instructions Modular control units ESM 906 ESM 910 Rhein-Nadel Automation GmbH Rhein-Nadel Automation GmbH 14.04.2014 VT-BA ESM906-910-GB...
- Page 2 Table of contents Chapt........................Page Technical datas....................Safety notes....................Commissioning instructions ................Connecting diagram..................Plan dimensionnel……………………………………………………………….. Declaration of conformity as defined by Low voltage directive 2014/35/EU and EMC directive 2014/30/EU Herewith we declare that the product complies with the following provisions: Low voltage directive 2014/35/EU EMC directive 2014/30/EU applied harmonized standards:...
- Page 3 The fuses are accessible from the front panel. It is a microfuse 5x20 mm. The value for the module ESM 906 is 10 A super quick. This fuse is only to protect the internal semiconductor. An overload fuse to protect the complete unit has to be done external (i=6A).
- Page 4 Steps must be taken to ensure that all persons working with this control unit are familiar with the safety regulations and observe them. The device described in this manual is a control unit for operating RNA bowl feeders and linear feeders. The limit val- ues specified in the technical data must be observed.
- Page 5 50/60 Hz voltage source max. 6 A (ESM 906) 0...+10 Volt DC max. 10 A (ESM 910) fuse F1 only for ESM 906 variable signal current loop 12..24 V DC 0...+20 mA DC Note: The connecting diagram for the Modul ESM910 is identical. Only the two statusoutputs on clamp 1 upto 4 are not available.
- Page 6 Rhein-Nadel Automation GmbH Reichsweg 19/23 D - 52068 Aachen Tel (+49) 0241/5109-159 Fax +(49) 0241/5109-219 Internet www.rna.de Email vertrieb@rna.de Rhein-Nadel Automation GmbH Zweigbetrieb Lüdenscheid Nottebohmstraße 57 D - 58511 Lüdenscheid Tel (+49) 02351/41744 Fax (+49) 02351/45582 Email werk.luedenscheid@rna.de...
