Fendall Pure Flow 1000
Saline Cartridges
Cartuchos Salino
Cartouches Saline
Before installing the Fendall Pure Flow
1000 Saline Cartridges, inspect product
for damage.
The shipping carton should contain:
• Two (2) Fendall Pure Flow 1000 Saline
Cartridges
• Inspection Tag
• Tamper Evident Seal
• Nozzle Retention Clip
• Two (2) Plastic Fasteners
MODEL "A" (Below)
• Sperian logo on the front
• Refer to pages 3 - 6
MODELO "A" (abajo)
• Logotipo de Sperian en la cara delantera
• Consulte las páginas 3 a 6
MODÈLE A (ci-dessous)
• Logo Sperian sur le devant
• Se reporter aux pages 3 à 6
WARNING
Read all warnings and instructions in
this manual before installing this
equipment.
www.sperianprotection.com
Part # / Nº de peiza / Pièce nº 32-005519 Rev. H
Antes de instalar los Cartuchos Salino de
Fendall Pure Flow 1000, inspeccione el
producto para detectar posibles daños. La
caja de envío debe contener:
• Dos (2) Cartuchos Salino de Fendall Pure
Flow 1000
• Etiqueta de inspección
• Sello con evidencia de manipulación indebida
• Sujetador de retención de boquillas
• Dos (2) sujetador plástico
ADVERTENCIA
Lea todas las advertencias e
instrucciones de este manual antes de
instalar este equipo.
Saline Solution
Model # / Nº de modelo / Modèle nº 32-001050
Avant l'installation, s'assurer que les
Cartouches Saline de Fendall Pure Flow
1000 ne sont pas endommagées. Le carton
d'expédition doit contenir les pièces
suivantes :
• Deux (2) Cartouches Saline de Fendall
Pure Flow 1000
• Étiquette d'inspection
• Sceau de sécurité
• Pièce de retenue des gicleurs
• Deux (2) l'attache de plastique
MODEL "B" (Below)
• No Sperian logo on the unit
• Refer to pages 7 - 10
MODELO "B" (abajo)
• Sin logotipo Sperian en la unidad
• Consulte las páginas 7 a 10
MODÈLE B (ci-dessous)
• Aucun logo Sperian n'apparaît sur l'appareil
• Se reporter aux pages 7 à 10
AVERTISSEMENT
Lire toutes les directives et mises en
garde de ce guide avant d'installer le
bassin.
Sperian Eye & Face Protection, Inc.
®
with/con/avec
Sperian
825 East Highway 151
Platteville, WI 53818 USA
1-800-336-3255
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fendall Pure Flow 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Sperian Fendall Pure Flow 1000

Summary of Contents for Sperian Fendall Pure Flow 1000

  • Page 1 The shipping carton should contain: • Dos (2) Cartuchos Salino de Fendall Pure suivantes : • Two (2) Fendall Pure Flow 1000 Saline Flow 1000 • Deux (2) Cartouches Saline de Fendall Cartridges • Etiqueta de inspección Pure Flow 1000 •...
  • Page 2 ® Rendez-vous à notre site Web pour voir la Vidéo D’installation du Fendall Pure Flow 1000 : www.sperianprotection.com Appelez le Service à la Clientèle au 1-800-336-3255 pour obtenir une copie GRATUITE de la Vidéo D’installation du Fendall Pure Flow 1000...
  • Page 3 Model “A” Cartridge Installation Instructions Instrucciones de Instalación del Cartucho Modelo “A” Instructions D’installation de la Cartouche sur le Modèle A 1. Close the drain spigot by turning handle to the rear. 2. Remove cover by lifting up. 3. Open activating door. 4.
  • Page 4 6. Pull green latch tabs forward to drop down reservoir ensuring that platens are seated on bags and are not resting on the cartridge boxes. 7. Replace cover. 8. Remove rubber bands from activating strap and nozzle. 9. Extend activating straps to the side. Do not pull on the strap.
  • Page 5 10. Snap right-hand nozzle into place on white nozzle plate. 11. Snap left-hand nozzle into place on white nozzle plate. 12. The left-hand and right-hand nozzles must be touching in the middle. Failure to install the nozzles so that they touch may result in the improper operation of the eyewash unit.
  • Page 6 13. Install nozzle retention clip by placing it above hose of left nozzle. 14. Press nozzle retention clip into place above hose of right nozzle. 15. Position the two (2) black straps over top of the activation door with expiration date and batch number visible. Do not twist or cross straps.
  • Page 7 Model “B” Cartridge Installation Instructions Instrucciones de Instalación del Cartucho Modelo “B” Instructions D’installation de la Cartouche sur le Modèle B 1. Close the drain spigot by turning handle to the rear. 2. Remove cover by lifting up. 3. Open activating door. 4.
  • Page 8 6. Pull green latch tabs forward to drop down reservoir ensuring that platens are seated on bags and are not resting on the cartridge boxes. 7. Replace cover. 8. Remove rubber bands from activating strap and nozzle. 9. Extend activating straps to the side. Do not pull on the strap.
  • Page 9 10. Snap right-hand nozzle into place on white nozzle plate. 11. Snap left-hand nozzle into place on white nozzle plate. 12. The left-hand and right-hand nozzles must be touching in the middle. Failure to install the nozzles so that they touch may result in the improper operation of the eyewash unit.
  • Page 10 13. Install nozzle retention clip by placing it above hose of left nozzle. 14. Press nozzle retention clip into place above hose of right nozzle. 15. Position the two (2) black straps out to the sides of the unit, with expiration date and batch number facing down. Do not twist or cross straps.
  • Page 11 Reactivity: 0 Identity: Sperian ® Saline Solution - Product #s 32-000400, 32-000401, 32-000502, 32-001050, 32-001052 Section I Manufacturer: Sperian Eye & Face Protection, Inc. Emergency Telephone: 1-800-336-3255 Address: Information Telephone: 1-800-543-4842 825 East Highway 151 Platteville, WI 53818 USA Date Prepared: 06/18/09...
  • Page 12 Identidad: Solución Salino de Sperian ® – Números de productos: 32-000400, 32-000401, 32-000502, 32-001050, 32-001052 Sección I Fabricante: Sperian Eye & Face Protection, Inc. Télefono de emergencia: 1-800-336-3255 Domocilio: 825 East Highway 151 Télefono de información: 1-800-543-4842 Platteville, WI 53818 USA Fecha de preparación:...
  • Page 13 FICHE SIGNALÉTIQUE HMIS Santé: 0 Classements Inflammabilité: 0 Réactivité : 0 Nom du produit : Solution Salina de Sperian ® - Numéros de produit 32-000400, 32-000401, 32-000502, 32-001050, 32-001052 Section I Fabricant : Sperian Eye & Face Protection, Inc. Téléphone (en cas d’urgence) : 1-800-336-3255 Téléphone (pour obtenir des informations) : 1-800-543-4842...
  • Page 14 www.sperianprotection.com...
