Summary of Contents for XONTEL XT-20P
-
Page 2: Table Of Contents
Contents Summary ....................................... 3 Safety Precaution.................................... 3 Product Introduction ..................................4 Interface Description ..................................4 Introduction ....................................5 Packing List ....................................5 Wiring......................................6 User-define Terminal Parameters ..............................6 Login Webpage ....................................6 Protocol ......................................8 Network Parameters ..................................8 Server Parameters .................................. -
Page 3: Summary
Summary Safety Precaution • Read the safety precaution carefully before installing or using. • Please abide by the warning and the relevant safety tips. Please put this manual in convenient place for future reference. Warning This symbol means there are potential safe troubles, it may cause death or serious injury with incorrect operation. This symbol used to remind the user that this device attached the important operation and maintenance instructions. -
Page 4: Product Introduction
Product Introduction IP network ceiling speaker embedded XonTel IP Audio Digital Network audio technology with independent intellectual property rights. It can accept broadcasting initiated by other terminals and servers and support function settings through browser. With Circuit fault detection function, it can detect the working status of the horn and display on the server software. -
Page 5: Introduction
Introduction Packing List IP ceiling speaker is including the following fittings, please check the fittings before the installation, if any missing, please contact the distributor. （1） IP ceiling speaker 1 pcs （2） Waterproof connector 1 pcs Wiring terminal （3.81-2P）1 pcs （3）... -
Page 6: Wiring
Wiring Wiring method 1: Wiring method 2: Note: POE switcher cannot be connected, when using power adapter. Basic Network Settings Enter into the webpage of IP ceiling speaker, and then modify all the parameters according to the live environment. After finishing, click “save”. - Page 7 （2） Enter the user name and password in the web page (the default user name and password is admin） (3) Click OK to enter into IP ceiling speaker webpage.
-
Page 8: Protocol
Protocol XonTel XT-20P supports XonTel protocol (NAS) and SIP protocol (the default is SIP protocol), please select the corresponding protocol as per the server type of the log-in terminal, then set up accordingly. After completing setting and saving it, please restart the device. -
Page 9: Server Parameters
Server Parameters In order to configure server options, XT-20P communication protocol should be NAS. The only number to identify terminal, it cannot repeat with other terminals or hosts, the factory Terminal ID default is 1. Local Port The device port number defaults to 2046. Do not modify without special situation. -
Page 10: Sip Parameters
SIP Parameters In order to configure server options, XT-20P communication protocol should be SIP. The address of the SIP server of the device. Please fill in the IP address or SIP Server domain name of the SIP server correctly. Do not modify without special situation (default is 5060). -
Page 11: Audio Parameters
Audio Parameters Broadcast volume The total volume of audio input by the device during broadcasting, range: 0-15; Set the broadcast playback buffer time (that is, how many seconds later to broadcast after Buffer time the broadcast task is received), to ensure the broadcast output quality when the network environment is poor. -
Page 12: Multicast Setting
Multicast Setting Set whether to enable multicast or not. In the case where there are multiple servers in the LAN, different servers must fill in different addresses and port numbers when they initiate multicast broadcasts without Multicast IP Address interference. Support up to 10 multicast addresses as maximum and priority settings (priority from high to low is 1-10). -
Page 13: Password Settings
Password Settings The username and password of the login web page can be modified from here. Language Settings The language of the web page can be switched between Chinese and English... -
Page 14: Firmware Upgrade
Firmware Upgrade Click the "Update" button, you will enter the firmware upgrade mode after 15 seconds. Note: Do not power off during the upgrade process, otherwise the upgrade may fail and the device fails. Refresh the page then click "Choose File", select the upgrade file provided by the manufacturer, and click "Update" to start the upgrade... -
Page 15: Factory Reset
Factory Reset Factory Reset: all parameters need to be reset to defaults. Reboot Device User can click "Reboot" to reboot the device. -
Page 16: System Logs
System logs From here User can check the XT-20P speaker logs. -
Page 17: Fault Exclude
Fault Exclude Why the terminal cannot login the server? 1). Check the software server and the main controller is normal opened or not. It`s required to close all firewall before open the software server (including system built-in firewall and other antivirus software firewall).
