Summary of Contents for JB Systems EZ-CON 24W
- Page 3 FEATURES • The EZ-CON 24W is a compact yet versatile, user friendly controller with wireless DMX and battery! • Ideal to use in combination with wireless DMX and battery based devices. NO CABLES NEEDED! • For all kinds of applications on stage, DJ, exhibition booths, …...
- Page 4 • Due to safety reasons it is prohibited to make unauthorized modifications to the unit. MAINTENANCE Clean by wiping with a polished cloth slightly dipped with water. Avoid getting water inside the unit. Do not use volatile liquids such as benzene or thinner which will damage the unit. JB SYSTEMS EZ-CON 24W ®...
- Page 5 2. [PAGE SELECT] BUTTON: used to change pages A – B - C 3. MASTER FADER: change the output level of the controller. 4. ANTENNA 5. BATTERY LEVEL INDICATORS: the according LED will be blinking whilst charging the battery. JB SYSTEMS EZ-CON 24W ®...
- Page 6 After a few seconds the blinking stops on both controller and receiver(s). Now they are paired and can start working in wireless DMX mode. ADDRESSING THE CONNECTED UNITS Each time you build a different installation with the EZ-CON 24W, you should check the DMX addresses of the connected projectors. 1. PAGE A : •...
- Page 7 DMX wireless: 2.4GHz Size: 231 x 158 x 59 mm Weight: 1.41 kg The information is subject to change without prior notice. You can download the latest version of this user manual on our website: www.jb-systems.eu JB SYSTEMS EZ-CON 24W ®...
