- Page 1 USER GUIDE ups 620 Rackmount 1000 VA, 1500 VA, 2000 VA and 3000 VA Company...
- Page 2 Important Notice The UPS ground (earth) conductor carries leakage current from the loads in addition to any leakage current generated by the UPS. This UPS generates no more than 1 mA of current. To limit the total leakage current to 3.5 mA, the load leakage must be limited to 2.5 mA. The three- wire receptacle that you plug the UPS into must have a good (low-impedance) ground (protec- tive earth) connection to provide a safe path for leakage current.
- Page 3 ® u p s 6 2 0 Rackmount 1000 VA, 1500 VA, 2000 VA and 3000 VA User Guide Company STM-0303A © Copyright 1999, Best Power. All rights reserved.
- Page 4 If You Have a Question Customer Support If you have a question or problem, Table 3, Troubleshooting, may help. If you need more help, please have your UPS model number and serial number (on the back label) nearby, and call the SOLA office nearest you (see the SOLA offices section). SOLA’s service technicians have in-depth knowledge of the UPS and power problems.
-
Page 5: Table Of Contents
Table of Contents Safety Instructions ........... .2 UPS Features . -
Page 6: Safety Instructions
Safety Instructions IMPORTANT SAFETY INSTRUCTIONS! SAVE THESE INSTRUCTIONS! This User Guide contains important instructions for your Sola 620 Rackmount that must be followed during installation and maintenance of the UPS and batteries. CAUTION! Whenever the Sola 620 Rackmount is “On,” there may be dangerous voltage present at the unit’s outlets. -
Page 7: Ups Features
UPS Features The Sola 620 Rackmount provides protection against power problems, including power outages, brownouts, and sudden increases in power. It also provides spike suppression and line noise filtering to protect your equipment. Front panel LEDs and an audible alarm keep you aware of the unit’s status. - Page 8 1500 A 2000 A 3000 A Back Panel Details Input Power Connector BestDock Access Panel External Battery Connector Voltage Selection Switches Fuse External Battery Connectors RJ45 Jacks 10. Circuit Breaker Aust 10A Outlets 11. Aust 15A Outlets Interface Port www.solaaust.com.au SOLA Never Stops Innovating...
-
Page 9: Rack Installation
Rack Installation Mount the Sola 620 Rackmount in a 19-inch (483-mm) EIA 310 C standard rack. Do not try to mount the unit if the rack is too wide. Do not rely on the front mountings only to support the weight of the unit. Install a stationary shelf or supporting angle brackets (available as standard rack hardware from electronics distributors) below the intended rack location for the Sola 620 Rackmount. -
Page 10: Wall Installation
Wall Installation The Sola 620 Rackmount is shipped with screws and brackets to mount it to a wall surface. You must attach one bracket to each side of the UPS, and then mount the UPS to the wall. Install the UPS by following the instructions below. -
Page 11: Connection To External Battery Packs
Connection to External Battery Packs Before connecting the input power cord, connect all intended battery packs to the Sola 620 Rackmount by following the guidelines below. The battery packs for 1000 and 1500 VA units may be linked serially (daisy-chained) to a maximum of two packs. -
Page 12: Quick Startup
Quick Startup Connect the power cord to the back of the unit. Plug the UPS into a wall outlet. Let the unit charge the battery for at least 8 hours. You may use the unit while the battery charges, but the battery backup runtime will be reduced until the battery is fully charged. Start the Sola 620 Rackmount by pressing and holding the On/Standby button (large button in the center of the front panel) in for about one second. -
Page 13: Symbols, Leds And Audible Alarms
Symbols, LEDs and Audible Alarms The front panel indicators (LEDs) and an audible beep indicate the unit status. The unit beeps whenever the unit is on battery power or an alarm exists. See Figure 1 for information about the LEDs and Table 1 for information about alarm displays. Figure 1: Front Panel LEDs Constant: Operating on Blinking: Operating in... - Page 14 Table 1: Alarm Conditions Alarm Display Alarm Description What You Should Do 2 beeps per second. The UPS is overloaded (in Line Shut off the least important equipment Mode). Your equipment needs more connected to the UPS. If this solves the power than the UPS can supply.
-
Page 15: Bestdock
To silence an alarm, press the alarm silence button on the front panel. The beep will stop, but the alarm light will stay on. Note: Silencing the alarm does not solve the problem that caused it. To correct the problem, see Tables 2 and 3. Table 2: Audible Beeps Number of Beeps What It Means... -
Page 16: Troubleshooting
Troubleshooting If you have a question or problem, the troubleshooting table may help. (See Table 3.) If you need assistance, phone SOLA Service or your local SOLA office. Please have the model number and serial number (located on the rear of the unit) available. If the unit must be returned, SOLA will give you a Return Authorisation (RA) number. -
Page 17: Replacing The Batteries
Replacing the Batteries (1000VA and 1500VA only) The Sola 620 Rackmount batteries are user-replaceable and can be replaced while the Sola 620 Rackmount has AC input applied and powers the loads (hot-swappable). This means that, if necessary, you can replace the batteries while the UPS is running. Before you replace the batteries, make sure that you read the safety information below. -
Page 18: Battery Replacement Instructions
Battery Replacement Instructions (1000VA and 1500VA only) Phone SOLA Service to order a replacement battery pack. It must be the same type and rating of the original batteries. See Battery information in Specifications. If it is necessary, the batteries may be replaced while the Sola 620 Rackmount is running, with the protected equipment attached. -
Page 19: Interface Port
Interface Port The Sola 620 Rackmount comes equipped with CheckUPS II power management software. Instructions included with the CheckUPS II CD tell you how to install the software. An interface cable for the following systems is provided. SCO UNIX/XENIX UNIX and Compatible Systems OS/2 Windows 3.X, 95 and NT Novell NetWare... -
Page 20: Specifications
Specifications SOLA reserves the right to change specifications without prior notice. Line Transient Protection: Passes ANSI/IEEE C62.41 Category A testing. Safety Compliance: Designed to meet AS 3260, IEC 950. EMC Compliance: AS 3548; CISPR 22 Class B, Vfg 243-91/46-92 B, EN55022, CE Mark Self-certified to: CE Marking Directive 93/68/EEC, Low Voltage Directive 73/23/EEC;... -
Page 21: Warranty
AC Output Distribution: 1000 Model: four Austrailan 10 ampere receptacles 1500 Model: four Austrailan 10 ampere receptacles 2000 Model: three Austrailan 10 ampere receptacles 3000 Model: three Austrailan 15 ampere receptacles Load Compatibility: Power factor corrected switch mode power supply loads can be supported up to 100% of full UPS watt rating. - Page 22 3. Any modification made to the product other than those made by Sola or its authorised representative may cause the Warranty to be void. 4. For units up to 3 kVA that are installed as a portable device, the Warranty covers repair or replacement of defective parts at the factory, or other service location as nominated by Sola Australia, provided the unit has been returned by the user packed adequately to prevent shipping damage, and approval has been obtained from Sola Australia Ltd before shipment.
-
Page 25: Sola Australia Offices
SOLA Australia Offices Head Office - Melbourne Sola Australia Ltd. 13 Healey Road Dandenong VIC 3175 Phone: 61-3-9706-5022 Fax: 61-3-9794-9150 National Service and Repair Centre Free Call: 1800 034 401 (except Melbourne) 9768 3105 (Melbourne only) http://www.solaaust.com.au Customer Service Offices Adelaide PO Box 481, Marlestone Business Centre SA 5033... -
Page 26: Appendix A: Adjusting Input Frequency Tolerance
Appendix A: Adjusting Input Frequency Tolerance The Sola 620 Rackmount automatically switches to battery operation whenever the input voltage is outside an acceptable frequency tolerance. This tolerance is user selectable from the factory preset value of 50 and 60 Hz, ±5%, to ±7%, and to ±2%. You can use the Alarm Silence/Battery Test button to change the tolerance (while the UPS is operating on AC input power) by following these steps: Press and hold the Alarm Silence/Battery Test button for 10 seconds.
