Page 1 ANY PICTURES CONTAINED WITHIN THIS OPERATOR’S MAN- UAL THAT DEPICT SITUATIONS WITH SHIELDS, GUARDS, RAILS, OR LIDS REMOVED ARE FOR DEMONSTRATION PUR- POSES ONLY. HAGIE MANUFACTURING COMPANY STRONG- LY URGES THE OPERATOR TO KEEP ALL SHIELDS AND SAFETY DEVICES IN PLACE AT ALL TIMES.
Page 2 OPERATOR’S MANUAL HAGIE MANUFACTURING COMPANY BOX 273 CLARION, IOWA 50525 (515) 532-2861 COVERS MACHINE SERIAL NUMBERS: 037099001 thru 037099200 5-99 493186 © 2003 Hagie Manufacturing Company. Clarion, Iowa USA...
Page 3 ABBREVIATIONS A/C ..........AIR CONDITIONING MT............... MOUNT ADJ ..............ADJUST MTH ..............MONTH ADPTR ............ADAPTER MTR ..............MOTOR ALT ............ALTERNATOR NO ..............NUMBER AMP ..............AMPERE OD ..........OUTSIDE DIAMETER APPROX ........... APPROXIMATELY PLT ..............PLATE ASSY ............ASSEMBLY PRESS ............
Page 4 We thank you for choosing a Hagie detasseler and assure you of our continued interest in its satisfactory operation for you. If we might be of assistance to you, please call us.
Page 5 The user is responsible for inspecting the understand any part of the manual or require machine and having parts repaired or replaced additional information or service, contact the Hagie when continued use of the product causes damage Customer Support Department:...
Page 6: Table Of Contents
TABLE OF CONTENTS SAFETY/DECALS ......................X-X DETASSELER IDENTIFICATION ................X-X III. SPECIFICATIONS ......................X-X PREPARING TO OPERATE ................... X-X OPERATING INFORMATION ..................X-X TRANSPORTING ......................X-X VII. SERVICE AND MAINTENANCE ................. X-X VIII. STORAGE ......................... X-X TROUBLE SHOOTING ....................X-X LIMITED WARRANTY....................
Page 7: Safety/Decals
I. SAFETY/DECALS SAFETY PRECAUTIONS Most accidents occur as the result of failure to Therefore, you must study this Operator’s Manual follow simple and fundamental safety rules. For this and learn how to use the detasseler controls for reason, most accidents can be prevented by safe operation.
Page 8 I. SAFETY/DECALS OPERATING TREAD WIDTH  Select the widest tread setting to fit between the crop rows.  Never manually adjust the tread width on the detasseler until the wheels have been properly blocked. Loosen the leg clamp bolts only enough for the leg to slide on the frame. OUTRIGGERS ...
Page 9 I. SAFETY/DECALS REPAIR/MAINTENANCE HYDRAULICS  Use caution when working with hydraulic fluid under pressure. Escaping hydraulic fluid can have sufficient force to penetrate your skin, causing serious injury. This fluid may also be hot enough to burn.  Always lower load or relieve hydraulic pressure before repairing a hydraulic oil leak. ...
Page 10 I. SAFETY/DECALS WARNING DECALS Decals warning you of avoidable danger are warning decals and other instructional Hagie located on various parts of the detasseler. They are decals or machine striping may be purchased there for your personal safety and protection. DO through the Hagie Customer Support Department.
Page 11 I. SAFETY/DECALS 650320 Rear of right cab window. 650339 Front of operator station. 650339 Inside cab door. DECALS CONTINUED...
Page 12 I. SAFETY/DECALS DANGER KEEP AWAY; CUTTING BLADES 650819 2 on each cutter housing. CAUTION 650820 Quad puller head. CAUTION 650820 2 on each male corn chopper. DECALS CONTINUED...
Page 13 I. SAFETY/DECALS 650831 Steering column. 650847 Front of operator station. 650847 Outside cab, under back window. DECALS CONTINUED...
Page 14 I. SAFETY/DECALS 650848 Right of ladder on leg brace. 650849 Top of each fuel tank (diesel or gasoline). 650851 Left rear mainframe DECALS CONTINUED...
Page 15 I. SAFETY/DECALS 650851 Right rear mainframe 650852 Front of operator station. 650852 Inside cab door. DECALS CONTINUED...
Page 16 I. SAFETY/DECALS CAUTION BEFORE ENGAGING HYDRAULIC MOTORS REDUCE ENGINE SPEED TO AN IDLE CLEAR AREA OF UNAUTHORIZED PERSONNEL 650955 Operator control station. 650981 Front of mullion to left of radiator cap. 650982 Left of battery on hydraulic oil reservoir...
Page 17: Detasseler Identification
II. IDENTIFICATION NUMBERS DETASSELER IDENTIFICATION Each Hagie detasseler is identified by means hubs have identification plates that describe the of a frame serial number. This serial number type of mount and gear ratio. To ensure prompt, denotes the model, year in which it was built, and...
Page 18 II. IDENTIFICATION NUMBERS Planetary Hubs Left Right Front: Rear: Hydrostatic Pumps Front: Rear: Front Wheel Motors Left: Right: Refer to parts manual. Rear Wheel Motors Left: Right: Refer to parts manual.
Page 19: Specifications
III. SPECIFICATIONS DETASSELER DIMENSIONS 204 with 12.4-28 tire A. Overall tractor height (w/cab or canopy) ..134.5” D. Wheel base ..........106” B. Lift arm range ..........53” E. Detasseler length (w/o attachments) ..198” C. Axle height..........22.6” F. Diesel exhaust height ......134”...
Page 20 III. SPECIFICATIONS ENGINE (Gasoline) Manufacturer ..................General Motors Model.....................3508AF Type ......................V-8, liquid cooled Number of cylinders ................8 Displacement ..................5.7 liter Horsepower ...................165, intermittent Type of fuel ...................Unleaded gasoline Fuel system ...................Filtered, naturally aspirated Air cleaner .....................Dry-type, single element Slow idle ....................650 RPM Fast idle ....................2850 RPM (Diesel) Manufacturer ..................Cummins...
Page 21 III. SPECIFICATIONS POWER TRAIN Drive Hydrostatic pump ..................Sauer/Sundstrand 90 series Range ....................100cc variable displacement (diesel) 75cc variable displacement (gasoline) Drive train ....................All time four wheel drive Speed ....................0-12 mph Hydrostatic wheel motor - front ............Sauer/Sundstrand M35 - rear ............Sauer/Sundstrand M25 Final drives Type ..................Planetary Gear Reduction Hubs ®...
Page 22 III. SPECIFICATIONS ELECTRICAL SYSTEM General Electrical System Battery ....................Single 12V, negative ground Alternator ....................105 AMP, voltage regulated Starter....................12V with solenoid Circuit Breakers A/C relay (cab only) ................30 AMP Starter relay (diesel only) ..............30 AMP Work lights (see below) .................40 AMP Wire harness (diesel only)..............30 AMP Wire harness (diesel only)..............50 AMP Fuses...
Page 23 III. SPECIFICATIONS OPERATOR STATION Operator station (standard) General operator station ...............Tilt steering Flashing/hazard warning lights Turn signals Seat .......................Adjustment for: Fore-aft Height Ride firmness Canopy (optional) General canopy ..................Same as operator station Cab (optional) General cab ...................Same as operator station, also: Windshield wiper Side mirrors Dome light...
Page 24 III. SPECIFICATIONS TIRES/RIMS Rims (front and rear) Standard ....................28” X 10” Optional ....................38” X 10” Tires (front and rear) Standard ....................12.4–28 (Bias TT) Air pressure .................23 PSI Tire width ..................12.5” Load capacity (at 10 mph) ............2640 lbs. Overall diameter ................49.0” Static load radius (suggested—will vary with load) .....22.6”...
Page 25 III. SPECIFICATIONS DETASSELING EQUIPMENT OPTIONS Front mounted with or without LS System Quad Puller Number of rows available..............4, 6, 8, 10, or 12 Drive ......................Hydraulic Tire size ....................4.10/3.50 2 ply Operating speed ..................Up to 400 RPM Pulling height ..................Minimum range – 34” to 87” Maximum range –...
Page 26: Preparing To Operate
IV. PREPARING TO OPERATE WHEEL TREAD AND ROW SPACING Knowing the row spacing of the field one intends to detassel, follow the steps below to properly obtain the desired tread 1. To adjust the tread width in or out, park the detasseler on level ground and shut off the engine.
Page 27 IV. PREPARING TO OPERATE TREAD WIDTH CONTINUED 3. Loosen the leg mounting bolts on both the front and rear legs on one side of the detasseler only (fig. 4.3). Loosen leg mounting bolts only enough to allow for free movement of leg on mainframe. DO NOT remove bolts under any condition.
Page 28 IV. PREPARING TO OPERATE TREAD WIDTH CONTINUED 8. To adjust the tread out, place a suitable prying tool under the center of the tire and pry out at the same time that you push out at the top of the leg (fig. 4.6). Carefully lower the detasseler to the ground which, in turn will allow the leg to slide outward.
Page 29 - it must be a positive number). Correct toe-in adjustment. For further assistance regarding toe-in should fall somewhere between one half and three measurement and adjustment, contact the Hagie quarters of an inch. Customer Support Department. NOTE: For more information on adjusting toe-in see page 119½...
Page 30 Always make sure you have proper of the optional attachments, refer to your HAGIE equipment and help when installing the attach- 204 Parts Manual for the correct option for outlining ments. FIG 4.9 Firmly set the parking brake (fig. 4.10) and shut off engine before attaching components.
Page 31 The guide pin that is welded to outrigger mount should be located toward the bottom (fig. 4.11, item 2). 2. Attach left and right outrigger (fig. 4.11, item 3) with supplied hardware. Refer to 204 DETASSELER OPTION Parts Manual. 3. Attach outrigger support rods if required.
Page 32 The guide pin that is welded to outrigger mount should be located toward the bottom (fig. 4.12, item 2). 2. Attach left and right outrigger (fig. 4.12, item 3) with supplied hardware. Refer to 204 DETASSELER OPTION Parts Manual. 3. Attach outrigger support rods.
Page 33 ATTACHING EQUIPMENT CONTINUED Attaching Lift Assemblies FIG 4.13 Refer to 204 DETASSELER Parts Manual for correct hardware when following these steps: 1. Attach the lift mounts (fig. 4.13, item 2) to the tool bar and outriggers at the appropriate spac- ings.
Page 34 IV. PREPARING TO OPERATE ATTACHING QUAD PULLERS FIG 4.15 1. Attach the quad pullers to each lift arm tool bar (fig. 4.15). NOTE: Some quad pullers may come pre-assembled to the tool bar. In this case, you would attach them to the lift assem- 2.
Page 35 Quad Puller Hydraulic Assembly TWO-HEAD SERIES Hydraulic hoses on Quad Puller heads should be hooked up so tires rotate according to figure 4.18 and figure 4.19. Refer to 204 DETASSELER Parts Manual for correct hard- ware, hose lengths, and hydraulic schematic. FIG 4.18 THREE-HEAD SERIES FIG 4.19...
Page 36 IV. PREPARING TO OPERATE ATTACHING CUTTER HEADS FIG 4.20 1. Attach the cutter head assembly to the tool bar (fig. 4.20). NOTE: CUTTING BLADES MUST OPERATE IN CORRECT DIRECTION Some cutters may come pre-assembled to FRONT the tool bar. In this case, you would attach BLADE ROTATION BLADE ROTATION LEFT OF OPERATOR...
Page 37 4.23 figure 4.24 (counter-clockwise from above). Refer to 204 DETASSELER Parts Manual for correct hardware, hose lengths, and hydraulic schematic. NOTE: Care should be taken when installing check valve (fig. 4.23, item 1) on cutter motor so the flow arrow is oriented correctly (either two-head or three-head series).
Page 38 Hydraulic hoses on cutter heads should be hooked up so blades on heads mounted right of operator rotate according to figure 4.25 and figure 4.26 (clockwise from above). Refer to 204 DETASSELER Parts Manual for correct hardware, hose lengths, and hydraulic sche- matic. NOTE: Care should be taken when installing check valve (fig.
Page 39 3. Attach the deflector shields to the tire puller head assembly (fig. 4.28, item 3). 4. Install the hydraulic hoses according to the hydraulic schematic in the HAGIE 204 Parts Manual. 5. Normal operating angle of the tire puller is FIG 4.28...
Page 40 (fig. 4.30, item 5) and sensor mount (fig. 4.30, item 6) to the slide mount weld- ments. 5. Install the cable assembly according to the wire diagram in your HAGIE 204 Parts Manual. 6. With a tape measure, set the center of the ®...
Page 41 IV. PREPARING TO OPERATE ATTACHING DEPTH COMMAND FIG 4.32 1. Attach the depth command actuator as- sembly (fig. 4.32) to the tool bar (fig. 4.33, item 2). 2. Attach the adjustable slide mount (fig. 4.32, item 1) to the sensor arm approxi- mately 15 inches away from the sensor arm pivot (fig.
Page 42 IV. PREPARING TO OPERATE ATTACHING MALE CORN CHOPPERS 1. Disconnect the hydraulic hoses from existing heads. 2. Disconnect and remove the head assem- ® blies and, if equipped, the Tasseltrol attachments from the tool bar. 3. Attach the male corn chopper to the tool bar. 4.
Page 43 4. Install male corn cutter drop tube assembly (4.37, item 2). 5. Connect hydraulic hose to the male corn cutter motor as shown in schematic in HAG- IE 204 Parts Manual. NOTE: Mounting brackets, case drain assem- bly, or a hydraulic package may need to be ordered to attach male corn cutters.
Page 44: Operating Information
V. OPERATING INFORMATION OPERATING THE ENGINE Pre-operational Checks Page Reference 1. Check the engine oil level. Do not operate the engine when oil is below the low mark on dipstick. 2. Check the coolant level in the radiator and the coolant overflow reservoir. 3.
Page 45 V. OPERATING INFORMATION 5. Turn the ignition key switch to the start position to engage the starter. If the engine fails to start after 15 seconds, turn key to “OFF”, wait one minute and repeat the procedure. If the engine does not start after three attempts, check fuel supply system.
Page 46 V. OPERATING INFORMATION HYDROSTATIC DRIVE The power for the Hagie 204 is derived from a A manual control lever connected to the pump’s Cummins diesel or GM gasoline engine. The swashplate controls the amount and direction of oil hydrostatic power system consists of a Sauer/...
Page 47 V. OPERATING INFORMATION HYDROSTATIC SYSTEM CONTINUED 1. Open throttle slowly maximum recommended engine speed setting. NOTE: Never operate the detasseler at anything less than full recommended throttle. 2. To move forward, slowly push the hydrostatic control lever (fig. 5.5) forward. The farther the control lever is moved, the faster the detasseler will travel.
Page 48 (fig. 5.7, item 1) NOTE: The limiter is factory set and requires no further adjustment. If adjust- ments are made without contacting the Hagie Customer Support De- partment, damage may result to the system and void the warranty. HYDROSTATIC SYSTEM CONTINUED...
Page 49 FIG 5.9 hydrostatic system cooling removal contamination. NOTE: The loop flushing valve has been factory set. DO NOT adjust. Damage to the system may result if adjustment is made without contacting the Hagie Customer Support Department. HYDROSTATIC SYSTEM CONTINUED FIG 5.10...
Page 50 V. OPERATING INFORMATION HYDROSTATIC SYSTEM CONTINUED Traction Valve The Model 204 detasseler comes equipped with special hydraulic valves for increased traction (one in the front hydraulic loop and one in the rear hydraulic loop). These valves greatly reduce spin-out if muddy conditions prevail, or if wheels lose traction for any reason.
Page 51 V. OPERATING INFORMATION HYDRAULIC SYSTEM The auxiliary hydraulic system is an open type hydraulic oil is sent to the oil cooler in front of the directly mounted behind the heavy duty variable engine coolant radiator. Here it is cooled and then displacement pump.
Page 52 V. OPERATING INFORMATION HYDRAULIC SYSTEM CONTINUED Power Steering The full-time power steering system consists of a hydraulic steering motor (mounted on the end of the steering wheel shaft) which is connected to a pair of double-action steering cylinders (fig. 5.15, item 1) mounted on a steering pivot (fig.
Page 53 V. OPERATING INFORMATION HYDRAULIC SYSTEM CONTINUED Lift Cylinders To adjust the height of each detasseling head assembly, cylinders mounted on each lift unit (fig. 5.17) are connected to a console- mounted lift control (fig. 5.18). The controls are either switchable from manual to automatic or manual only.
Page 54 V. OPERATING INFORMATION HYDRAULIC SYSTEM CONTINUED Setting Each Lift Assembly Install a 3,000 PSI pressure gauge on the inlet of the elec- tro-hydraulic valve (fig. 5.20, item 1). With the engine running at ® an idle, raise each unit one at a time with the Tasseltrol while in “MANUAL”...
Page 55 V. OPERATING INFORMATION HYDRAULIC SYSTEM CONTINUED Detasseling Heads The hydraulic motors on the detasseling heads (fig. 5.23) are turned on and off with a row of switches mounted on the control panel to the right of the operator’s seat (fig. 5.22). To open the solenoid on any of the motor control valves (fig.
Page 56 V. OPERATING INFORMATION ® SETTING UP THE TASSELTROL /LS SYSTEM FIG 5.24 The control box (fig. 5.24) has three programmable parame- ters and each has four different value settings. Your programma- AUTO ble control box is factory preset with the following parameter de- faults: BOTTOM PARAMETER –...
Page 57 V. OPERATING INFORMATION ® TASSELTROL CONTINUED ® OPERATING THE TASSELTROL /LS CONTROL To use the control box with its normal parameter setting, use the following procedures. To adjust the given parame- ters, see pages XX-XX. 1. From the operator’s seat, turn the ignition to the “ON” position.
Page 58 V. OPERATING INFORMATION ® TASSELTROL CONTINUED SHORT CORN OPERATION When operating the LS system, always select “MANUAL” when first entering the field. Once you have maintained your operating speed and the cutting and/or pulling depth, select “AUTO.” When you come to an area where the corn is very short, such as a low spot in the field, you may want to switch to the “MANUAL”...
Page 59 V. OPERATING INFORMATION CAB OPERATION CONTINUED “ALL UP” and “ALL HOLD” Function This function can be used to raise or lower all row units at the same time. The switches to control this option are located on the hydrostat control handle (5.33). All the row units will move up when the red switch (5.33, item 1) is activated and will lower when the green switch (5.33, item 2) is activated.
Page 60 V. OPERATING INFORMATION ® TASSELTROL RESPONSE PARAMETER The response parameter is used to adjust the toward R1. Generally this parameter can be left at R2. response time of both photocells. How quickly the To display the response parameter, select down motion starts when no corn is detected by either “AUTO”...
Page 61 V. OPERATING INFORMATION ® TASSELTROL TOP PARAMETER The top parameter is used to adjust the sensi- onds for the “SELECT MANUAL” message. Press tivity of the top photocell. The top photocell starts the “UP” button under “PAR”. Now press the “UP” the up motion when its lights path is blocked by button under the “T”...
Page 62 V. OPERATING INFORMATION ® TASSELTROL BOTTOM PARAMETER The bottom parameter is used to adjust the tom photocells, decrease the parameter toward B1. sensitivity of the bottom photocell. The bottom pho- Generally this parameter can be left at B1. tocell stops the down motion when its light is To display the bottom parameter, select blocked by corn.
Page 63 V. OPERATING INFORMATION ® Four-Lift TASSELTROL Display Screen Quick Reference Chart Turn on ignition key Turn on ignition key ® ® with TASSELTROL with TASSELTROL power switch in “ON” power switch in “OFF” MANUAL AUTO AUTO SELECT MANUAL S.I.E., 104. 5-15-93 PAR= B1 R2 T3 RW8 DØØ...
Page 64 V. OPERATING INFORMATION ® Six-Lift TASSELTROL Display Screen Quick Reference Chart Turn on ignition key Turn on ignition key ® ® with TASSELTROL with TASSELTROL power switch in “ON” power switch in “OFF” S.I.E. level 2.1 MANUAL AUTO SELECT MANUAL CABLE BOX sn: C98ØØ9 PAR=s B1 R2 T3 L8 DØØ...
Page 65 V. OPERATING INFORMATION LS PHOTOLIGHT INDICATORS The upper and lower LS photolights (fig. 5.39) have L.E.D. lights (fig. 5.40) that indicate their operational status. LT/DK SWITCH – Light/Dark switch on photolight (fig. 5.40, item 1) changes the activated condition of green L.E.D.
Page 66 V. OPERATING INFORMATION DEPTH COMMAND FIG 5.41 The Hagie 204 comes available with optional ad- justable DEPTH COMMAND (fig. 5.41). This allows the operator to adjust the depth of the LS system from the cab. The switches are located to the right of the steering column (fig.
Page 67 V. OPERATING INFORMATION GAUGE PANEL Speedometer/Tachometer - (fig. 5.44, item 1) Fuel Gauge - (fig. 5.44, item 4) The fuel gauge Unit will display either engine RPM or speed of travel measures the amount of fuel in either fuel tank, depending on operator’s selection.
Page 68 V. OPERATING INFORMATION GAUGES CONTINUED SPEEDOMETER/TACHOMETER The speed/tach unit is programmable with a be displayed for four seconds. digital read-out indicating MPH or RPM. The PARAMETER SETTING parameters have been factory set. RPM (Diesel) ........ 357 (fig. 5.45C) (Gasoline) ......292 (fig. 5.45D) Turn the ignition key to the “ON”...
Page 69 V. OPERATING INFORMATION SPEEDOMETER/TACHOMETER CONTINUED Speedometer/Tachometer Display Screen Quick Reference Chart KEY-ON DISPLAY POWER-UP POWER-UP FOR 1 SEC. DISPLAY DISPLAY Hold down the left (RPM) button Hold down the right (MPH) button until the display with four “8’s” until the display with four “8’s” appears, then release and pa- appears, then release and pa- Hold down both buttons until the...
Page 70 V. OPERATING INFORMATION CAB OPERATION CONTINUED STANDARD OPERATOR SEAT -1- Fore-Aft Adjustment. Pull the fore-aft lock wise to lower seat height and counter- lever to the left to unlock and adjust seat for- clockwise to raise seat height. ward or rearward to desired position. Release -3- Ride Firmness.
Page 71 CAB OPERATION CONTINUED STEERING COLUMN To adjust the HAGIE 204’s steering column for driver comfort or to ease cab exit and entry, locate the tilt lock lever in the center of the column (fig. 5.49). Push down on the lever to release the lock (fig.
Page 72 V. OPERATING INFORMATION CAB OPERATION CONTINUED PARKING BRAKE The mechanically applied parking brake is located on the floor to the left of the operator’s seat (fig. 5.53). Activate the parking brake by pulling it up and back (fig. 5.54) If it is difficult to pull back, you can adjust the tension by adjusting the knob on the end of the lever (fig.
Page 73 V. OPERATING INFORMATION LIGHTS WORK LIGHTS – The front of the standard operator’s station houses two halogen work lamps (fig. 5.59). The front of the optional canopy or cab houses four halogen work lamps (fig. 5.60) and the rear houses two halogen work lamps (fig.
Page 74 V. OPERATING INFORMATION LIGHTS CONTINUED Turn Signals To activate the front (fig. 5.63, item 1 or 2) and rear turning signals (fig. 5.63, item 3) move the turn signal lever (fig. 5.61) right during a right-hand turn and left during a left-hand turn. Steering column-mounted turn...
Page 75 V. OPERATING INFORMATION HAGIE 204 CAB FIG 5.64 Emergency Exit ................XX Climate Controls ................XX Air Suspended Seat ............... XX Radio....................XX Windshield Wiper ................XX Interior Lighting ................XX CAB OPERATION CONTINUED...
Page 76 V. OPERATING INFORMATION CAB OPERATION CONTINUED Emergency Exit The right window in the cab is removable in the event that an emergency exit is required. To remove the rear window: FIG 5.65 1. Grasp and pull the tag of the nylon ring next to the emergency exit decal (fig.
Page 77 V. OPERATING INFORMATION CAB OPERATION CONTINUED Climate Controls ADJUSTING FAN BLOWER SPEED - Fan blower speed is controlled by the left rotary dial on the cab climate control panel (fig. 5.68, item 1). The fan blower speed is a continuously variable adjustment.
Page 78 V. OPERATING INFORMATION CAB OPERATION CONTINUED AIR SUSPENDED CAB SEAT -1- Ride Firmness. Pull knob out to release air slowly to raise seat position. When at desired and “soften” ride. Push knob in to pump air and height release lever to lock. “stiffen”...
Page 79 V. OPERATING INFORMATION CAB OPERATION CONTINUED Radio Your Hagie 204 is equipped with an auto reverse AM/FM cassette tuner (fig. 5.72) and two speaker system. For stereo system operation and installation information refer to the radio owner’s manual that accompanies this operator’s manual.
Page 80: Transporting
VI. TRANSPORTING A. DRIVING: When driving the detasseler on a public road or highway, drive carefully and follow these steps: 1. Always have the outrigger in the folded position and locked when driving or transporting. FIG 6.1 2. Flashing hazard/warning lights have been placed on the detasseler to warn other drivers. 3.
Page 81 VI. TRANSPORTING B. TRAILERING: NOTE: Extra care should be taken when loading the detasseler onto any trailer. Consid- er whether it is best to back the detasseler on or drive the detasseler forward. 1. Loading: NOTE: Be sure to read and understand the trailer’s owner and operator manual. Hitch the trailer to the pulling vehicle as shown in the trailer’s owner and operator man- When moving the detasseler onto a trailer, follow these steps completely: a.
Page 82 VI. TRANSPORTING FIG 6.2 NOTE: The loaded height and width of the trailer must con- form to the law of the state in which it is being used. 2. UNLOADING: When moving the detasseler off of a trailer, follow these steps completely: a.
Page 83 VI. TRANSPORTING NOTE: It is not recommended that the detasseler be towed, but if it should ever be necessary, follow these steps carefully: C. TOWING 1. Fold the outriggers in and lock them to the de- tasseler. ® 2. Disengage each Torque Hub by removing two outer cap bolts, turning the outer cap with the extended center in towards the hub and re-...
Page 84 VI. TRANSPORTING NOTE: In order for the power steering system to function, the detasseler’s engine must be run- 3. Turn on the flashing hazard/warning lights. 4. When towing, it is necessary that two vehicles of sufficient size and weight for adequate pulling and braking are used.
Page 85: Service And Maintenance
VII. SERVICE AND MAINTENANCE PAGE Service Point ENGINE OIL DAILY RADIATOR COOLANT LEVEL DAILY COOLANT OVERFLOW RESERVOIR LEVEL DAILY COOLANT CONCENTRATION AS REQ 500 HRS* RADIATOR GRILLE SCREENS AS REQ ENGINE DRIVE BELT AS REQ DAILY A/C COMPRESSOR BELT (CAB ONLY) AS REQ 250 HRS A/C COMPRESSOR (CAB ONLY)
Page 86 VII. SERVICE AND MAINTENANCE SERVICE INTERVALS Initial checks after receiving machine then IMMEDIATELY HOURS HOURS 1) Check lug nut torque, then every 50 hours (page XXX) then FIRST 50 HOURS HOURS HOURS HOURS ® 1) Change Torque Hub oil, then every 500 hours (page XXX) 2) Change hydrostatic charge pressure filter, then every 250 hours (page XXX) 3) Change hydraulic suction filter, then every 250 hours (page XXX) 4) Change hydraulic return filter, then every 250 hours (page XXX)
Page 87 VII. SERVICE AND MAINTENANCE SERVICE INTERVALS CONTINUED As Required HOURS 1) Change coolant concentration (page XXX) 2) Clean radiator grille screens (page XXX) 3) Change engine drive belt (page XXX or XXX) 4) Change A/C compressor belt (page XXX or XXX) 5) Change A/C dryer (page XXX) 6) Charge A/C compressor (page XXX) 7) Change primary fuel filter (water separator) (page XXX)
Page 88 VII. SERVICE AND MAINTENANCE SERVICE INTERVALS CONTINUED Every 50 HOURS HOURS 1) Check tire pressure (page XXX) 2) Check lug nut torque (page XXX) 3) Grease all tie rod zerks (page XXX) Every 75 HOURS HOURS ® 1) Grease Torque Hub seal boot (page XXX) Every 100 HOURS HOURS...
Page 89 VII. SERVICE AND MAINTENANCE FLUIDS Engine oil OIL LEVEL - The engine oil level dipstick is located on the left-hand side of the diesel engine (fig. 7.1, item 1) and the right- FILL hand side of the gas engine (fig. 7.2). Never operate the engine with the oil level below the “L”...
Page 90 VII. SERVICE AND MAINTENANCE FLUIDS CONTINUED ® Torque Hub ® OIL LEVEL - Each Torque Hub should maintain an oil level of half full at all times. Less than that would limit lubrication, and over half full could cause overheating and damage. To check oil ®...
Page 91 VII. SERVICE AND MAINTENANCE FLUIDS CONTINUED Cooling System COOLANT TYPE - Your cooling system should always be sufficiently charged with an adequate mixture of antifreeze and water, regardless of the climate, in order to maintain a broad operating temperature range. Your cooling system has been factory-charged with an ethylene glycol-based antifreeze.
Page 92 VII. SERVICE AND MAINTENANCE FLUIDS CONTINUED COOLANT RESERVOIR - The coolant reservoir is located under the right-hand hood behind the radiator (fig 7.10). Check its level everyday while the engine is cold. Maintain the coolant reservoir level within the normal cold range marks. CHANGING COOLANT - Your coolant should periodically be changed to eliminate the buildup of harmful chemicals.
Page 93 VII. SERVICE AND MAINTENANCE FLUIDS CONTINUED ® Hydra-Hug Leg Suspension NOTICE USE SAE 80/90 GEAR OIL TO ADJUST FRONT LEGS. SEE OWNER’S MANUAL ® To adjust the Hydra-Hug suspension system, fill a grease gun with EP-90 weight oil (fig. 7.14) and attach to the fitting FIG 7.13 located on top of the left leg (fig.
Page 94 VII. SERVICE AND MAINTENANCE FLUIDS CONTINUED Air Conditioning TYPE - The cab on your detasseler is equipped with a R- 134a air conditioning system. RECHARGING - Recharge it only with R-134a refrigerant. If your air conditioning system is mistakenly charged with R-12 refrigerant, serious problems, such as compressor seizure, may result.
Page 95 VII. SERVICE AND MAINTENANCE FILTERS Grille Screens In order to maintain maximum air flow through the engine cooling system’s radiator, oil cooler, and air conditioning condenser, the cooling air intake grille screens must be inspected often and periodically removed for cleaning. NOTE: Failure to keep cooling systems clean can cause over heating and damage to...
Page 96 VII. SERVICE AND MAINTENANCE FILTERS CONTINUED Engine Air Intake REMOVAL - The engine air intake filter element should only be removed if it is going to be replaced. After loosening the air cleaner clamp and removing the end cap, carefully remove the filter so as to not knock any dust off the filter and into the air intake passage (fig.
Page 97 VII. SERVICE AND MAINTENANCE FILTERS CONTINUED Suction Filter Remove and install a new 10 Micron rated suction filter (fig. 7.24, item 3) at the first hours use; subsequently, replace the filter every 250 hours, or once a year, whichever comes first. Charge Pressure Filter Remove and install a new 4 Micron rated charge pressure filter (fig.
Page 98 VII. SERVICE AND MAINTENANCE FILTERS CONTINUED High Pressure In-line Filters STACK VALVES - The valves on the lift control stack valve are protected by a 90 Micron in-line sintered bronze filter (fig. 7.26). When the filter element is removed for cleaning, caution should be taken so the gasket is in the proper place when re-installing (fig.
Page 99 VII. SERVICE AND MAINTENANCE FILTERS CONTINUED FUEL FILTERS Diesel PRIMARY (WATER SEPARATOR) - (fig. 7.29, item 2) Drain water and sediment from the separator daily. Replace every 500 hours or once a year, whichever comes first. SECONDARY - (fig. 7.29, item 1) Replace every 500 hours or once a year, whichever comes first.
Page 100 VII. SERVICE AND MAINTENANCE FILTERS CONTINUED Fresh Air Cab Filters PAPER FILTER - (fig. 7.33, item 1) The paper filter should be cleaned once a year, or more often if necessary. Remove the paper element and gently tap it against a flat surface. Direct low pressure compressed air through the filter to remove larger particles.
Page 101 VII. SERVICE AND MAINTENANCE LUBRICATION Leg Bearings Hagie 204 leg assemblies are constructed with upper and lower nylon bearings for suspension telescoping between the inner and outer leg weldments. These bearings must be lubricated to avoid bearing failure and ensure optimal ride quality.
Page 102 VII. SERVICE AND MAINTENANCE LUBRICATION CONTINUED Quad Pullers Each quad puller head has four bearings equipped with grease zerks (fig. 7.36). To ensure the longest life and best performance, grease each bearing twice a day: suggested times are morning and noon. Male Row Choppers Each male row chopper has two bearings equipped with grease zerks (fig.
Page 103 VII. SERVICE AND MAINTENANCE LUBRICATION CONTINUED Tire Pullers 1 – Puller spindle 7 – Outer bearing 2 – Inner bearing seal 8 – Washer 3 – Inner bearing 9 – Spindle nut 4 – Inner bearing cup 10 - Cotter pin 5 –...
Page 104 VII. SERVICE AND MAINTENANCE ELECTRICAL Battery SAFETY Batteries contain sulfuric acid. Avoid contact with skin, eyes, or clothing. Do not inhale fumes or in- gest liquid. Batteries contain gases which can ex- plode. Keep sparks and flame away while servicing. NOTE: When servicing electrical system always disconnect FIG 7.41...
Page 105 VII. SERVICE AND MAINTENANCE ELECTRICAL CONTINUED Fuses Fuses protect individual lighter duty electrical circuits. They are located toward the rear console panel to the right of the operator’s seat (fig. 7.44). If a fuse blows, remove it by rotating the fuse cap counterclockwise as you push down.
Page 106 VII. SERVICE AND MAINTENANCE FUSES CONTINUED Depth Command Fuse The fuse for the DEPTH COMMAND is located in the switch box (fig. 7.47). If the DEPTH COMMAND fuse blows, remove it by rotating the fuse cap counter-clockwise as you push in. Then pull the fuse straight out. Replace the blown fuse with the same amperage fuse only (fig.
Page 107 VII. SERVICE AND MAINTENANCE ELECTRICAL CONTINUED Circuit Breakers Circuit breakers handle the functions of the hydrostatic handle (fig 7.50, item 1), VFC lever heavier duty electrical circuits on the detasseler. knobs (fig. 7.50, item 2), and panel screws (fig. They trip when overloaded and automatically reset 7.50, item 3).
Page 108 VII. SERVICE AND MAINTENANCE BELTS Diesel Engine Drive Belt REMOVAL - Insert a 3/8 inch square ratchet drive into the belt tensioner (fig. 7.53, item 1) and lift upward to remove the belt (fig. 7.53, item 2). INSPECTION - Visually inspect the belt daily (fig. 7.54).
Page 109 VII. SERVICE AND MAINTENANCE HYDROSTATIC SYSTEM CONTINUED Gasoline Engine Drive Belt REMOVAL – Insert a 3/8 inch square ratchet drive into the belt tensioner (fig. 7.56, item 1) and push in- ward to remove the belt (fig. 7.56, item 2). INSPECTION –...
Page 110 REPAIR/REPLACEMENT - See pump handbook accompanying this operator’s manual. Hydrostatic pumps are available as a core exchange item from Hagie Manufacturing Customer Support Department. FIG 7.59 Auxiliary Gear Pumps REPAIR/REPLACEMENT - See pump handbook accompanying this operator’s manual. Gear pumps are available from the Hagie Manufacturing Customer Support Department.
Page 111 VII. SERVICE AND MAINTENANCE BOLT TORQUE Wheel Bolts ® To install wheel and tire assembly on the Torque Hub ® lubricate Torque Hub studs with anti-seize grease. Align the ® wheel bolt holes with the Torque Hub studs and mount the wheel on the hub.
Page 112 VII. SERVICE AND MAINTENANCE BOLT TORQUE CONTINUED Leg Mounting Bolts NOTE: See page XX for additional infor- mation regarding mounting Follow these procedures for torquing the leg mounting bolts: Never remove more than three leg mounting bolts from any single leg FIG 7.64 Start the nuts on the mounting bolts and tighten them until they are just snug.
Page 113 VII. SERVICE AND MAINTENANCE TIRES Air Pressure Check tire pressure once a week or every 50 hours of operation (fig. 7.66). Never inflate a tire more than the recommended maximum air pressure. Use an air line with a locking air chuck and stand behind tire tread while filling (fig. 7.67).
Page 114 VII. SERVICE AND MAINTENANCE TOE-IN ADJUSTMENT ® 1. Adjust Hydra-Hug suspension until 5. Manually pry each front wheel in or out until dimensions above and below steering arm are each is lined up exactly with the corresponding equal (fig. 7.69, dim. A — See page XXX). rear tire.
Page 115 VII. SERVICE AND MAINTENANCE DAILY INSPECTION Inspection Point Action (if necessary) Check Engine oil level .................... Add oil Radiator coolant level .................. Add antifreeze solution Coolant overflow reservoir level ..............Add antifreeze solution Engine drive belt (diesel)................Replace belt ® Filter Minder ....................
Page 116: Storage
Manufacturing Customer Support Department. 10. Replace worn or missing decals. See pages X-XX for proper location of warning decals and their corresponding part number. Warning decals and all other Hagie decals are available through the Hagie Manufacturing Customer Support NOTE:...
Page 117 IX. STORAGE STORAGE CONTINUED 11. Use a multi-purpose grease to coat exposed hydraulic cylinder rods to prevent rusting which could result in cylinder damage. 12. If the sprayer must be stored outside, cover it with a waterproof cover. B. Removing the detasseler from storage. 1.
Page 118: Trouble Shooting
IX. TROUBLE SHOOTING A. ENGINE Start engine from operator’s seat only. When running engine in a building, be sure there is adequate PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY Engine won’t crank Dead battery Recharge or replace battery Poor battery connections Clean and tighten Neutral safety switch (located in Adjust and/or replace if needed the Sauer/Sundstrand pump)
Page 119 IX. TROUBLE SHOOTING ENGINE CONTINUED PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY Engine overheats Engine overloaded Reduce load Dirty radiator core or dirty grill Remove all foreign material and screens clean all items Faulty radiator cap Replace cap Loose or faulty fan belt Tighten or replace fan belt Faulty thermostat Replace thermostat...
Page 120 IX. TROUBLE SHOOTING C. HYDROSTATIC SYSTEM DO NOT GO NEAR LEAKS. High pressure oil easily punctures skin causing injury, gangrene, or death. If injured, seek emergency medical help. Immediate surgery is required to remove oil. Do not use finger or skin to check for leaks.
Page 121 IX. TROUBLE SHOOTING HYDROSTATIC SYSTEM CONTINUED PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY Hydrostatic system responding Engine speed too low Set engine at operating RPM slowly before trying to move machine Oil level in reservoir low Fill reservoir to proper level with approved oil;...
Page 122 IX. TROUBLE SHOOTING D. HYDRAULIC SYSTEM DO NOT GO NEAR LEAKS. High pressure oil easily punctures skin causing injury, gangrene, or death. If injured, seek emergency medical help. Immediate surgery is required to remove oil. Do not use finger or skin to check for leaks.
Page 123 IX. TROUBLE SHOOTING HYDRAULIC SYSTEM CONTINUED PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY Lifting mechanism won’t lift Bad Cylinder Check cylinder; remove and rebuild or replace Blown relief valve Remove, check; replace w/ new Relief valve set too low Reset to 2000 PSI Lift arms frozen Loosen mounting bolts;...
Page 124 IX. TROUBLE SHOOTING E. ELECTRICAL NOTE: Disconnect battery when Batteries contain sulfuric acid. Avoid contact with servicing any part of electrical skin, eyes, or clothing. Do not inhale fumes or system prevent system ingest liquid. Batteries contain gases which can explode.
Page 125 IX. TROUBLE SHOOTING ® F. TASSELTROL / LS SYSTEM – HYDRAULIC DO NOT GO NEAR LEAKS. High pressure oil easily punctures skin causing injury, gangrene, or death. If injured, seek emergency medical help. Immediate surgery is required to remove oil. Do not use finger or skin to check for leaks.
Page 126 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – HYDRAULIC CONTINUED PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY All units lift slowly Hydraulic oil not at operating Allow time for oil to warm up temperature Faulty valve Replace valve Lift arm pivots too tight Lubricate and loosen pivot point Plugged high pressure filter Remove, clean, replace (see...
Page 127 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – HYDRAULIC CONTINUED PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY Only one unit lowers slowly Faulty valve Replace valve Faulty lower poppet on stack Remove, clean, replace valve Lower orifice incorrectly Re-adjust orifice (see page XX) adjusted All units lower slowly Allow time for oil to warm up...
Page 128 IX. TROUBLE SHOOTING ® G. TASSELTROL / LS SYSTEM – ELECTRICAL NOTE: Disconnect battery when servicing any part of electrical system to prevent system damage. PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY No units will lift Faulty “AUTO/MANUAL” switch Replace control box Blown fuse Find short in wire, repair and replace fuse...
Page 129 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – ELECTRICAL CONTINUED PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY No units will lower Faulty “AUTO/MANUAL” switch Replace control box Blown fuse Find short in wire, repair and replace fuse Loose wire connections Find loose connections, tighten In “AUTO”...
Page 130 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – ELECTRICAL CONTINUED ® TASSELTROL DISPLAY TROUBLESHOOTING To gain further information on the status of the The display will show the status of the upper ® Tasseltrol /LS system before operation: while and lower photo sensor on each lift assembly. If the sitting in the operator’s seat, turn the ignition key to display shows a box (“...
Page 131 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – ELECTRICAL CONTINUED ® TASSELTROL DISPLAY MANUAL MODE AUTO MODE MANUAL AUTO Unit does NOT rise automatically. PHOTO SENSOR POSSIBLE STATUS LIGHTS CAUSE Lights at lower photo sensor Faulty GREEN wire in connector cable (See page XXX, fig.
Page 132 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – ELECTRICAL CONTINUED ® TASSELTROL DISPLAY MANUAL MODE AUTO MODE AUTO MANUAL Unit rises automatically. PHOTO SENSOR POSSIBLE STATUS LIGHTS CAUSE Lights at upper photo sensor Faulty WHITE wire in sensor assembly (See page XXX, fig.
Page 133 IX. TROUBLE SHOOTING ® TASSELTROL /LS SYSTEM – ELECTRICAL CONTINUED FIG 9.1...
Page 134 IX. TROUBLE SHOOTING NOTES...
Page 135: Limited Warranty
Hagie approval. No commercial loss coverage Hagie shall not be liable for incidental or consequential damages or injuries (damage and repairs of equipment itself, loss of profits, rental or substitute equipment, loss of good will, etc.). SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAM- AGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
Page 136: Index
INDEX PAGE PAGE Charcoal Filter, Cab .............. XX Charge Pressure Filter, Hydraulic........XX Adjusting Choke ..................XX Cab Climate Controls ............XX Choppers, Male Corn Detasseling Depth ............. XX Attaching ................XX Toe-In ................XX Lubrication ................ XX Tread Width ..............XX Circuit Breakers Air Conditioning System Control Panel ..............
Page 137 INDEX PAGE PAGE Filters Hydraulic Filters Air Conditioning Dryer ............XX Charge Pressure ............... XX Return ................XX Charcoal Filter ............XX Suction ................XX Fresh Air Intake Filter..........XX Hydraulic Safety ..............XX Recirculation Filter ............XX Hydrostatic Drive System Engine Air Intake Filter ............
Page 138 INDEX PAGE PAGE Male Corn Cutters Serial Number Location Four-Blade Detasseler ................. XX Lubrication ..............XX Engine................XX Single-Blade Hydrostatic Pump .............. XX ® Attaching ..............XX Torque Hubs Front ................XX Multi-Function Valve ............. XX Rear ................XX Service Intervals ..............XX Operating Information ............
Page 139 Wheel Motors ................ XX Wheel Lug Nuts ..............XX Windshield Wiper ..............XX Transporting Detasseler Winter Storage Directions ............ XX Driving ................XX Trailering ..............XX-XX Loading ............... XX Unloading ..............XX Towing ..................XX © 2003 Hagie Manufacturing Company. Clarion, Iowa USA...
Page 140 NOTES...
