Hagie NTB 16-Row Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A Word From Hagie Manufacturing Company ................................................................................ 1-1
About This Manual ........................................................................................................................... 1-1
Safety Messages Used In This Manual ............................................................................................. 1-2
Service and Assistance ...................................................................................................................... 1-3
Reporting Accidents, Injuries, or Safety Concerns ........................................................................... 1-3
Specifications .................................................................................................................................... 1-4
2015 Product Warranty ................................................................................................................... 1-10
Intended Use ..................................................................................................................................... 2-1
Safety Precautions ............................................................................................................................. 2-1
Safety Decals .................................................................................................................................... 2-3
Fold Procedure .................................................................................................................................. 3-1
Float Operation ................................................................................................................................. 3-6
Application ........................................................................................................................................ 3-9
Service - Lubrication ........................................................................................................................ 4-1
Service - Mounting Bolt Torque (60' HsTB) ................................................................................... 4-5
Storage .............................................................................................................................................. 4-5
Transporting ...................................................................................................................................... 5-1
Gauge Wheel Adjustment ................................................................................................................. 5-3
Coulter Adjustment ........................................................................................................................... 5-4
Quick-Tach System ........................................................................................................................... 5-5
Covers Machine Serial Numbers: SNU80011515001-200, SNU80021515001-200
SNU80031515001-200, SNU80041515001-200, SNU80051515001-200, SNU80061515001-200
© 2014-15 Hagie Manufacturing Company. Clarion, Iowa USA

TABLE OF CONTENTS

Part No. 493615
Rev. 15F150320

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTB 16-Row and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hagie NTB 16-Row

Summary of Contents for Hagie NTB 16-Row

  • Page 1: Table Of Contents

    TABLE OF CONTENTS 1 – INTRODUCTION A Word From Hagie Manufacturing Company ................1-1 About This Manual ........................... 1-1 Safety Messages Used In This Manual ..................... 1-2 Service and Assistance ........................1-3 Reporting Accidents, Injuries, or Safety Concerns ................1-3 Specifications ............................

  • Page 2: Introduction

    NTB without obligation to existing units. NOTE: Hagie Manufacturing Company reserves Thank you for choosing a Hagie NTB and we the right to make changes to any current ensure you of our continued interest and support patents or patents pending at any time, in its optimal performance for you.

  • Page 3: Safety Messages Used In This Manual

    NTB. If you do not understand any part of this NOTICE manual or require additional information or service, contact Hagie Customer Support for assistance. This symbol indicates operator awareness which, if not avoided, may result in personal or property damage.

  • Page 4: Service And Assistance

    (515) 532-2861 OR (800) 247-4885 www.hagiehelp.com REPORTING ACCIDENTS, INJURIES, OR SAFETY CONCERNS Should an accident or injury occur involving the use of a Hagie product, or if you have a product safety concern, report such information directly to Hagie Customer Support at (800) 247-4885.

  • Page 5: Specifications

    INTRODUCTION SPECIFICATIONS Hagie Manufacturing Company offers it’s Nitrogen Toolbar (NTB) in 12-row, 16-row, 18-skip row, and 24-skip row configurations, depending on model. The 6-ft. (182 cm) clearance (30/40’ NTB) allows growers to side-dress nitrogen later in the growing season, in some situations, after tassels have topped.
  • Page 6 SECTION 1 – INTRODUCTION Fold Points (40’ NTB) Fold Points (60’ HsTB) • RH Main • LH Outer • RH Outer • RH Main • RH Outer • LH Main Fold Fold Fold Fold Fold Fold • LH Main Fold •...
  • Page 7 SECTION 1 – INTRODUCTION NTB Transport Dimensions 40’ NTB Dimensions 30’ NTB Dimensions 40’ NTB • Overall Unfolded Width = 449.5”/37’-5” (11.4 m) 30’ NTB • Overall Unfolded Width = 350”/29’-2” (889 cm) 40’NTB • Length (from front of machine to front of folded NTB) = 180”/15’...
  • Page 8 SECTION 1 – INTRODUCTION 60-ft. HsTB Dimensions 60’ HsTB • Overall Width (when folded for transport) = 272”/22’-8” (690.9 cm) • Overall Height (when folded and raised for transport) = 178”/14’-10” (452.1 cm) 60’ HsTB • Width (from front of gauge wheel to rear of quick-tach) = 96”/8’-0”...
  • Page 9 SECTION 1 – INTRODUCTION NTB Layout 40’ NTB The following illustrations define the 16-Row/30” (76.2 cm) Spacing NTB design and will aid in identifying the various toolbar configurations. 30’ NTB 12-Row/30” (76.2 cm) Spacing 40’ NTB 16-Row/30” (76.2 cm) Spacing 24-Skip Row/20”...
  • Page 10 SECTION 1 – INTRODUCTION 60’ HsTB 24-Row/30” (76.2 cm) Spacing 60’ HsTB 24-Row/30” (76.2 cm) Spacing NTB Weight (Approximate) 30’ NTB • 4,776 lbs./2,166 kg 40’ NTB • 5,996 lbs./2,719 kg 60’ HsTB • 8,020 lbs./3,637 kg...

  • Page 11: 2015 Product Warranty

    Hagie Manufacturing Company shall not be responsible for repairs or replacements which are necessi- tated, in whole or in part; by the use of parts not manufactured by or obtainable from Hagie Manufacturing Company nor for service performed by someone other than Hagie authorized personnel, unless authorized by Hagie Manufacturing Company.

  • Page 12: Safety And Precautions

    Wear safety Do not operate the attachment for anything equipment that is appropriate for the job. other than its intended use. Hagie Manufacturing Company shall not be liable for any damage, injury, or death associated with improper use of the attachment.
  • Page 13 SECTION 2 – SAFETY AND PRECAUTIONS Be Prepared fluid can have sufficient force to pene- trate your skin, causing serious injury. • Be prepared for an emergency. Keep a This fluid may also be hot enough to fire extinguisher handy. Keep a first aid burn.

  • Page 14: Safety Decals

    • Always follow the manufacturer’s label instructional decals, or machine striping may for directions of use. be purchased through the Hagie Customer • Never allow chemicals to come in con- Support Department. tact with your skin or eyes. Always use...
  • Page 15 SECTION 2 – SAFETY AND PRECAUTIONS 650204 40’ NTB (6) - Located near each fold point 650137 (Located near electrical box cover) 650219 (2) - Located on each lift arm weldment 650178 (2) - Quick-Tach 650339 (Located on front cross-member) 650204 (8) - Located near each fold point...
  • Page 16 SECTION 2 – SAFETY AND PRECAUTIONS 650219 650204 (2) - Located on each lift arm weldment (10) - Located near each fold point 650339 (Located on front cross-member) 650208 (2) - Located on each outer fold extension 650339 (Located on front cross-member) 60’...
  • Page 17 SECTION 2 – SAFETY AND PRECAUTIONS 650447 (2) - Located near center section weldment on each parking stand...

  • Page 18: Operating Your Ntb

    SECTION 3 – OPERATING YOUR NTB FOLD PROCEDURE WARNING Before proceeding, check area around the machine for bystanders, overhead objects, and power lines. Failure to comply may result in serious injury or death. NOTE: 30/40’ NTBs fold horizontally and the Hydrostatic Drive Control Handle 60’...
  • Page 19 SECTION 3 – OPERATING YOUR NTB Field/Road Button (Located on the Machine Display Home Page) NOTE: The machine’s drive state cannot be changed unless the Hydrostatic Drive Transom Switch - UP (Located on the Hydrostatic Drive Control Handle is in the NEUTRAL Control Handle - Version 2) position.
  • Page 20 SECTION 3 – OPERATING YOUR NTB NOTE: Both left and right outer fold • Right • Right Boom/NTB UP extensions will unfold simultaneously Boom/ when this switch is pressed. NTB IN • Right Boom/ NTB OUT • Right Boom/ • Left Boom/NTB UP DOWN •...
  • Page 21 SECTION 3 – OPERATING YOUR NTB Outer Fold Extensions 4. Press and hold the Transom Switch (40’ NTB/60’ HsTB only) (located on the Hydrostatic Drive Con- trol Handle) in the UP position to raise the NTB up off ground. NOTICE Fold each outer fold extension IN before folding in the main fold sections.
  • Page 22 SECTION 3 – OPERATING YOUR NTB gravity. These latches engage and disengage • Right • Right Boom/NTB UP automatically when the outer fold extensions Boom/ are extended and retracted. NTB IN • Right Boom/ NTB OUT If the outer fold extension(s) do not extend •...

  • Page 23: Float Operation

    SECTION 3 – OPERATING YOUR NTB FLOAT OPERATION NOTICE Ensure Float operation is enabled when operating the NTB. Failure to comply may result in property damage. Field/Road Button Float operation allows the NTB to raise up (Located on the Machine Display and down while riding through the field to Home Page) avoid machine damage due to uneven...
  • Page 24 SECTION 3 – OPERATING YOUR NTB trol Handle) in the UP position to raise the NTB to desired height. Master Spray Switch (Located on the back side of the Hydrostatic Drive Control Handle - Version 1) -Typical View Transom Switch - UP (Located on the Hydrostatic Drive Control Handle - Version 1) -Typical View...
  • Page 25 SECTION 3 – OPERATING YOUR NTB One Tap Transom The One Tap Transom feature allows the operator to fully raise the transom by pressing the Transom Switch (located on the Hydrostatic Drive Control Handle) UP once, to raise the entire lift. 1.

  • Page 26: Application

    SECTION 3 – OPERATING YOUR NTB NTB Override Timer APPLICATION The override timer controls how long the outer sections raise with the transom during Float operation. NOTICE 1. Press the NTB Setup Button (located on Never attempt to operate the spray the Machine Display Settings Page).
  • Page 27 SECTION 3 – OPERATING YOUR NTB 4. Start the engine. NOTE: Main Tank Valve status (OPEN or 5. Press the Field/Road Button (located on CLOSED) and Agitation Valve the Machine Display Home Page) and pressure are displayed on the change the machine’s drive state to Machine Display Home Page - Field FIELD mode.
  • Page 28 SECTION 3 – OPERATING YOUR NTB Solution Pump Switch (Located on the side console) -Typical View Master Spray Switch (Located on the back side of the Hydrostatic 8. Press the Float Button (located on the Drive Control Handle - Version 1) Machine Display Auxiliary Controls -Typical View Page) to enable Float operation.
  • Page 29 SECTION 3 – OPERATING YOUR NTB and Agitation Valve Switches until solu- tion is refilled. Master Spray Indicator (Located on the Machine Display Home Page - Field Mode) 10. Press the individual Boom Solution Valve Switches (located on the side con- sole) to the ON position.

  • Page 30: Maintenance And Storage

    SECTION 4 – MAINTENANCE AND STORAGE SERVICE - LUBRICATION Perform grease point inspection/application as recommended in the following information. Apply ™ grease (such as Mobilgrease XHP 220-Series) as required. NOTICE Failure to properly lubricate pivot and friction points may result in unnecessary wear and damage.
  • Page 31 SECTION 4 – MAINTENANCE AND STORAGE Grease Point C (40’ NTB only) Grease Point B Grease Point A 30/40’ NTB Grease Points -Typical View * 40-ft. NTB shown Grease Point C (Outer Fold) Grease Point A * 40-ft. NTB only (Main Fold) Grease Point B (Inside Fold)
  • Page 32 SECTION 4 – MAINTENANCE AND STORAGE Grease Points (Zerks) - 60’ HsTB Lubricate the following Grease Points weekly, or as needed. • Sixteen (16) Grease Points (A, B, and C) - eight (8) per side. • Six (6) Gauge Wheel Grease Points (D) - three (3) per side. NOTE: Lubricate Grease Points A, B, and C weekly.
  • Page 33 SECTION 4 – MAINTENANCE AND STORAGE Grease Point C (Lift Arm) Grease Point A (Outer Fold) Grease Point D (Gauge Wheel) Grease Point B (Main Fold)

  • Page 34: Service - Mounting Bolt Torque (60' Hstb)

    TORQUE (60’ HSTB) 4. Thoroughly wash the attachment and touch up any chipped or damaged paint. 5. Replace any damaged or missing decals. NOTE: Contact Hagie Customer Support for paint touch-up recommendations and decal replacement. 6. Apply multi-purpose grease to hydraulic cylinder rods.

  • Page 35: Miscellaneous

    When driving on a public roadway or elsewhere, be aware of any situation where the machine will be passing near an object with Hagie Manufacturing Company does not clearance less than the transporting height and recommend any form of transportation width of the overall machine and attachment.
  • Page 36 SECTION 5 – MISCELLANEOUS Your 60’ HsTB is equipped with Parking Stands, which support the attachment during storage. Ensure the stands are in the extended (down) position before disconnecting attachment from the machine. Parking Stand (Retracted position shown) -Typical View 3.

  • Page 37: Gauge Wheel Adjustment

    SECTION 5 – MISCELLANEOUS GAUGE WHEEL ADJUSTMENT Storage to Field Position 1. Ensure the NTB is in the RAISED posi- tion. 2. Remove the two (2) Cotter Pins (located on the side of the gauge wheel mounting plate) and set aside. 3.

  • Page 38: Coulter Adjustment

    SECTION 5 – MISCELLANEOUS • Using a wrench or socket, loosen or tighten Adjustment Nut (located on the end of each coulter spring). - Loosen nut for less down pressure. - Tighten nut for more down pressure. Lift Handle (Located above gauge wheel) -Typical View 5.

  • Page 39: Quick-Tach System

    SECTION 5 – MISCELLANEOUS QUICK-TACH SYSTEM Connecting the NTB WARNING When connecting or disconnecting the attachment, observe the following safety precautions: • Monitor both sides of the attachment during fold procedure. • Select a safe area that is solid and level Lock Pin before unfolding/folding the attachment.
  • Page 40 SECTION 5 – MISCELLANEOUS • Solution Connection Valves • Solution Connection Cam Lock Levers Attachment Clearing Mounting Pins -Typical View Solution Connection Valves and Cam Lock Levers 5. Raise the machine by rotating the corre- (Located on the front sponding Air Suspension Valves in the right-hand side of machine) CLOCKWISE (Inflate) position.
  • Page 41 SECTION 5 – MISCELLANEOUS • Push the Quick Connect Handle (located on the 11. Engage the Quick-Tach Lock Assem- Hydraulic/Electric Multi-Coupler Assembly) UP blies by pushing the Lock Pins IN, ensur- to engage hydraulic/electrical connections. ing full engagement. • Quick Connect Handle Hydraulic/Electric Multi-Coupler Assembly...
  • Page 42 SECTION 5 – MISCELLANEOUS Disconnecting the NTB NOTE: It is NOT recommended to store the NTB attachment on a soft surface for an extended period of time, due to the WARNING risk of settling soil, even when blocks or wood are used. Turn the engine OFF before connecting/ 1.
  • Page 43 SECTION 5 – MISCELLANEOUS Boom Solution Valve Switches (Located on the side console) -Typical View Lock Pin (Located on the front left and 5. Engage the parking brake. right-hand side of machine) 6. Turn the engine OFF before discon- -Typical View necting any hoses or electrical lines.
  • Page 44 • Pull the Quick Connect Handle (located on the damage and contamination. If Hydraulic/Electric Multi-Coupler Assembly) necessary, cover the opening with a DOWN to disengage hydraulic/electrical plastic bag (secured with tape). connections. Contact Hagie Customer Support for replacement covers. 5-10...
  • Page 45 SECTION 5 – MISCELLANEOUS 9. Start the engine. 10. Disengage the parking brake and slowly back away from the attachment. -Typical View 11. Raise the machine by rotating the corre- sponding Air Suspension Valves in the CLOCKWISE (Inflate) position. 5-11...
  • Page 46 Safety Precautions ........2-1 Service - Lubrication ........4-1 Service - Mounting Bolt Torque (60’ HsTB) ..4-5 Service and Assistance ......... 1-3 Specifications ..........1-4 Storage ............4-5 Transporting ..........5-1 © 2014-15 Hagie Manufacturing Company. Clarion, Iowa USA...
