Unitronics IO-DI8-TO8 Manual page 6

I O - D I 8 - T O 8 , I O - D I 8 - T O 8 - L
IO-DI8-TO8, IO-DI8-TO8-L Technical Specifications
Max. current consumption
Typical power consumption
Status indicator
(RUN)
Inputs
Number of inputs
Input type
Galvanic isolation
Status indicators
(IN)
Nominal input voltage
Input voltage
pnp (source)
npn (sink), voltage/current
Input current
Response time
Input #7
Resolution
Frequency
Minimum pulse width
Outputs
Number of outputs
Output type
Galvanic isolation
Output current
Maximum frequency
Short circuit protection
Status Indicators
(OUT)
(S.C)
Voltage
Operating voltage
Nominal operating voltage
Environmental
Operating temperature
Storage temperature
Relative Humidity (RH)
Dimensions (WxHxD)
Weight
Mounting
6
I / O E x p a n s i o n M o d u l e s
70mA maximum from the adapter's 5VDC
0.15W @ 5VDC
Green LED:
—Lit when a communication link is established between module and OPLC.
—Blinks when the communication link fails.
8 (in one group)
pnp (source) or npn (sink)
None
Green LEDs—Lit when the corresponding input is active. See Note 1.
24VDC for IO-DI8-TO8, 12VDC for IO-DI8-TO8-L
IO-DI8-TO8
0-5VDC for Logic '0'
17-28.8VDC for Logic '1'
17-28.8VDC/<1.1 mA for Logic '0'
0-5VDC/>4.3mA for Logic '1'
6mA@24VDC
10mSec typical
The specifications below apply when this input is wired for use as a high-speed
counter input/frequency measurer. See Notes 2 and 3.
16-bit
5kHz maximum
80µs
8 pnp (source)
P-MOSFET (open drain) for both 24VDC and 12VDC outputs
None
0.5A maximum (per output)
Total current: 3A maximum (all outputs)
20Hz (resistive load)
0.5 Hz (inductive load)
Yes
Red LEDs—Lit when the corresponding output is active.
Red LED—Lit when an output's load short-circuits. See Note 4 below.
IO-DI8-TO8
10.2 to 28.8VDC
12/24VDC
IP20 / NEMA1
0° to 50°C (32° to 122°F)
-20° to 60° C (-4° to 140°F)
5% to 95% (non-condensing)
80mm x 93mm x 60mm (3.15" x 3.66" x 2.362")
141g (4.9oz.)
Either onto a 35mm DIN-rail or screw- mounted.
IO-DI8-TO8-L
0-3VDC for Logic '0'
8-15.6V for Logic '1'
8-15.6VDC/<1.1 mA for Logic '0'
0-3VDC/>4.3mA for Logic '1'
6mA@12VDC
IO-DI8-TO8-L
10.2 to 15.6VDC
12VDC
Unitronics Industrial Automation
7 / 0 3
