CONTENT OF THIS USER MANUAL
1.0
GENERAL DESCRIPTION .................................................................................. 2
2.0
UNPACKING .......................................................................................................... 2
3.0
INSTALLATION ..................................................................................................... 2
4.0
WARRANTY........................................................................................................... 2
5.0
FRONT PANEL CONTROLS .............................................................................. 3
REAR PANEL CONNECTORS .......................................................................... 3
6.0
7.0
BOTTOM PANEL CONTROLS .......................................................................... 4
8.0
TECHNICAL SPECIFICATIONS PS 19 AM .................................................... 4
PART LINE, TECHNICAL CONCEPT ............................................................... 5
9.0
10.0 CABLING ................................................................................................................ 5
11.0 BLOCK DIAGRAM PS 19 AM ............................................................................ 6
12.0
SYSTEM CONFIGURATION .............................................................................. 6
13.0 EARTHING CONCEPT ........................................................................................ 7
User Manual PS 19 AM / Issue 2011 © ASL Intercom BV
PAGE 1
