Touch Control Panel And Remote Display Panel

10
8
9
2
1
5
Button Instructions
1.
ON/OFF button
2.
Power indicator.
3.
High / Low Fan mode button. Switch the fan mode, High/Low fan mode selection.
4.
High Fan mode indicator. When the lights on (Orange Light), the High Fan mode is activated.
5.
Low Fan mode indicator. When the lights on (Orange Light), the Low Fan mode is activated.
High/Low Heating mode button. Switch the heating mode, High/Low Heating mode selection.
6.
7.
High Heating mode indicator. When the lights on (Orange Light), the High Heating mode is activated.
Low Heating mode indicator. When the lights on (Orange Light), the Low Heating mode is activated
8.
Timer / temperature set button. Setup the operation time & temperature. (P.10 -12)
9.
/
10.
Timer / temperature number button
11.
Temperature set indicator. When the lights on, can press
temperature.
Timer indicator. When the lights on, can press
12.
13.
Swing button.
14.
Swing indicator.
6
Touch Control Panel /
Display Panel
6
7
13
11
14
12
9
4
3
Remote Display Panel
10
to set the operation
to set the operation time .
