HTP Elite Ultra ELU-150WBN Installation, Start-Up, Maintenance, Parts, Warranty

High efficiency condensing wall-hung gas boilers
Hide thumbs Also See for Elite Ultra ELU-150WBN:
Table of Contents

Advertisement

Quick Links

Installation
Start-Up
Maintenance
Parts
Warranty
ELU-150WBN / ELU-199WBN / ELU-199WCN Models
This manual must only be used by a qualified installer / service technician. Read all instructions in this manual before installing. Perform steps in the
given order. Failure to do so could result in substantial property damage, severe personal injury, or death.
Improper installation, adjustment, alteration, service, or maintenance could void product warranty and cause property damage, severe
personal injury, or death.
California Proposition 65 Warning: This product contains chemicals known to the State of California to cause cancer, birth defects, or other
reproductive harm.
The manufacturer reserves the right to make product changes or updates without notice and will not be held liable for typographical errors
in literature.
The surfaces of these products contacted by potable (consumable) water contain less than 0.25% lead by weight as required by the Safe
Drinking Water Act, Section 1417.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
272 Duchaine Blvd.
Elite Ultra
High Efficiency Condensing
Wall-Hung Gas Boilers
DANGER
!
WARNING
!
NOTICE
New Bedford, MA 02745
Heat Exchanger Bears the ASME "H" Stamp
www.htproducts.com
LP-719 Rev. 000 Rel. 000 Date 6.25.20
TM
