Summary of Contents for Vestax PMC-25
- Page 1 Professional Mixing Controller OWNER'S MANUAL VESTAX CORPORATION VESTAX America VESTAX ( Europe ) Ltd.
-
Page 2: Table Of Contents
CONGRATULATIONS ！ Thank you for purchasing the VESTAX PMC-25, Professional Mixing Controller. Please read this owner's manual carefully before you start to use your mixer, so that you will fully understand all of the special features and enjoy the full use of the product. -
Page 3: Inportant Safeguards
I M P O R T A N T S A F E G U A R D S READ BEFORE OPERATING EQUIPMENT This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. -
Page 4: F E A T U R E S
3. The I/O panel can be placed on either the rear or top side. This feature enables the PMC-25 to be used on the table or in a rack without any extra space for the leads. -
Page 5: F U N C T I O N S
F U N C T I O N S PROGRAM SECTION MIC SECTION PROGRAM SECTION ○ INPUT SELECT (Input Select Switch) Used to select input to be sent to each PGM channel. ○ TRIM (Trim Control Volume) Adjusts the Input level of each channel. For proper adjustment, please set the INPUT FADER to Maximum position then adjust TRIM so that the INPUT LEVEL METER shows around 0 dB at... -
Page 6: Master Section
○ HI CUT (Fader type cut switch HI) When this volume is set to bottom position, high frequency range is cut of completely regardless of the position of the HI level control. The HI level control knob becomes active when this volume is set to maximum （top）... -
Page 7: Microphone Section
HOW TO REPLACE THE CROSS FADER Remove four screws, which hold the fader unit panel. ● Remove the cross fader unit, CF-R. ● Carefully remove the multi-cable connector from ● the fader unit. Insert the connector to the new fader unit. ●... -
Page 8: Rear Panel Section
REAR PANEL SECTION 24 27 32 33 ○ PHONO 1,2 [RCA PIN JACK] Connect turntables equipped with MM (Moving Magnet type) cartridge. The signal from the turntable is fed to the PGM channels when Phono input is selected. ○ LINE 1,2,3,4 [RCA PIN JACK] Connect the equipment with line level output (-10dB or 0dB), such as CD players, tape decks, DATs, MDs etc. -
Page 9: Connection （Example
ON / OFF MINI MINI ANALOG DISK TURNTABLE ［Vestax PDX-a1S］ OUT PUT LINE1 PHONO1 GND TERMINAL LINE2 GND TERMINAL OUT PUT ANALOG DISK TURNTABLE［Vestax PDX-a1S］ CD，MD PLAYER，DAT，SAMPLER，HDR etc. SEARCH PITCH TRACK REPEAT OPEN/ OUT PUT CLOSE DISPLAY STOP POINT FOCUS... -
Page 10: How To Change The Jack Panel Position
HOW TO CHANGE THE JACK PANEL POSITION The I/O jack panel of the PMC-25 can be placed either on the top or back side of the unit. Please refer to following Fig. Initially, the I/O panel is placed on the top-side. In case of changing the jack panel position to TYPE please use following instructions. -
Page 11: Block Diagram
BLOCK DIAGRAM... -
Page 12: Specifications
30Hz ∼ 20kHz ±3dB FREQUENCY RESPONSE LINE 20Hz ∼ 20kHz ±1dB） >60dB S/N RATIO LINE >75dB FADER >70d B ATTENUATION Vestax Corporation NOMINAL INPUT MAXMUM INPUT LEVEL -50dBv -42dBv -10dBv -10dBv -10dBv CROSSFADER CROSSTALK CHANNEL CROSSTALK POWER SUPPLY DIMENSION（W×H×D）...
