modway EEI-3270 Manual

Armless chair, ottoman, corner

EEI-3270 ARMLESS CHAIR/EEI-3318 OTTOMAN/EEI-3319 CORNER

Thank you for purchasing the MODWAY CORNER/ CHAIR/ OTTOMAN

Before you start, here are some helpful advice:

1. We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step

instructions.

2. Owing to the size and weight of the sofa/ chair/ottoman, we recommend that it is assembled by two adults,

on a carpeted or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.

3. Please do not use any tools other than those provided or recommended in these instructions.

4. Please do not throw away any of the packaging or the instruction until you have checked all the components

and hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe

and environmentally friendly way.

5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten

the components from time to time, so please save the tools that have been provided.

6. Please keep all pieces out of reach of children.

1. Ottoman Body

4. Back cushion x 4 （1 pc Back cushion for EEI-3270; 3 pcs Back cushions for EEI-3319）

Customer Service 609-256-9000︱www.modway.com

2. Leg

Bolt M8x60mm

Flat Washer

Allen Wrench M8

Felt Pad

3. Seat Cushion

Page 1 of 4

Table of Contents

Need help?

Do you have a question about the EEI-3270 and is the answer not in the manual?

Page 1 Flat Washer Allen Wrench M8 Felt Pad Components: 1. Ottoman Body 2. Leg 3. Seat Cushion 4. Back cushion x 4 （1 pc Back cushion for EEI-3270; 3 pcs Back cushions for EEI-3319） Customer Service 609-256-9000︱www.modway.com Page 1 of 4...
Page 2 EEI-3270 ARMLESS CHAIR/EEI-3318 OTTOMAN/EEI-3319 CORNER STEP 1: THE ASSEMBLY STEPS OF EEI-3270 ARMLESS CHAIR/ EEI-3318 OTTOMAN/ EEI-3319 CORNER ARE THE SAME. THE FOLLOWING ILLUSTRATION SHOWS THE ASSEMBLY STEPS OF EEI-3318 OTTOMAN. 1. Please put Ottoman Body (1) on a carpeted or padded surface.
Page 3 STEP 4: Put Seat Cushion (3) to the assembled ottoman as shown. As for the Seat Cushion (3) for EEI-3270 and EEI-3319, please tear off the cover of velcro strip then connect Seat Cushion and Body. Put 1 piece of Back Cushion (4) to EEI-3270 and 3 pieces of Back Cushions (4) to EEI-3319.
Page 4 Option A: Align the pre-installed Clip to the pre-installed Post as shown. Push EEI-3318 Ottoman, EEI-3319 Corner and EEI-3270 Armless Chair slowly until the Clip and the Post click together tightly. If you want to unlock the sofa combination: Lift up EEI-3319 Corner and move EI-3318 Ottoman and EEI- 3270 Armless Chair apart from EEI-3319 Corner.

Eei-3318Eei-3319
