8. Control Sticks:Used to control the navigation of the ROV.
9. Phone/Tablet Clamp:Used to attach phone/tablet mount to mounting bracket.
10. Clamp Button:Pull apart the two ends and put in the phone/tablet, then press this button to tighten.
11. Robotic Arm Control:Short press to close and stop, long press for one second to open
12. Photo/Video:Short press to take photos, long press to start / end recording video
13. Left Angel Adjustment:Adjust the pitch angle
14. Right Angel Adjustment:Adjust the rollover angle
15. HDMI Socket:1080P HD image real-time output
16. Tether Connection Socket/Charging socket.
Note: Do not put the controller in the water to avoid damaging the device, damages caused by water ingress are not covered by the
warranty.
Handle indicators introduction
Battery:
10%↓Red light flashes quickly;10-19% Red light flashes slowly;20-29% Red light always on.
Red:
30-69% Yellow light always on;
Yellow:
70-100% Green light always on;
Green:
Signal Indicator
a 2.4G:2.4Ghz Wi-Fi indicator,always on when working.
b 5G:5Ghz Wi-Fi indicator,always on when working.
c ROV:Indicates the communication status between the controller and the ROV (Steady light indicates successful connection,
Blinking light indicates disconnection.)
Gesture back Button:
The blue light is always on when the ROV is in a non-horizontal position
Unlock Button:
Locking: No lights
Unlocking: Blue light on
Led Control Button:
Bright light:Blue light always on;
Low light: Blue light flash;
No
light: Blue light off.
100/200 meters Tether & Winder
The tether is used to connect the drone and the remote controller
The winder is used to store the tether.
1.
Tether connectors
2.
Tether
3.
Winder
