We thank you for choosing an Australian made shed. For further assistance please
visit our detailed instructional video library at
Http://www.abscosheds.com.au/watch-videos
At ABSCO Industries we are always looking to be number ONE, so please let us
know what you think of our instructions. Feedback makes us better.
feedback@absco.com.au
ABSCO INDUSTRIES
Absco Economy Shed
Model: J15301FK
WHEN LAYING YOUR CONCRETE
SLAB, ENSURE THERE IS A REBATED
EDGE 25mm DEEP AROUND THE PERIMETER
ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17
CHANNEL
THIS WILL HELP
REBATED EDGE
WATER EGRESS FROM
THE BASE OF THE SHED
CONCRETE SLAB
FRONT: 1.52m
SIDE:
3.0m
HEIGHT: 1.80m
75mm WIDE
REBATE
V1.1
PAGE 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ABSCO SHEDS J15301FK
Summary of Contents for ABSCO SHEDS J15301FK
- Page 1 Http://www.abscosheds.com.au/watch-videos At ABSCO Industries we are always looking to be number ONE, so please let us know what you think of our instructions. Feedback makes us better. feedback@absco.com.au ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 1...
-
Page 2: General Instructions
Do not erect your shed in windy conditions, ensure that the shed is securely anchored to a solid foundation immediately after construction is completed. · It is highly recommended to erect the shed with two or more people. ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 2... -
Page 3: Component Description
CHANNEL CHANNEL L = 1513mm L = 773mm ALL SHEETS HAVE PART NO.S LOCATED ON Part No. Here LOWER RIGHT OR UPPER LEFT CORNER OF COLORED SIDE AS SHOWN ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 3... - Page 4 4mm CSK SCREW & PADBOLT NUT SECURE HINGES HASP TO DOOR 3mm POP RIVETS SECURE SELF TAPPING HINGES TO DOOR SCREWS (ALTERNATIVE FIXING 20mm METHOD) DOOR ASSEMBLY STRAP INSTRUCTIONS L: 165mm ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 4...
- Page 5 CSJ joined channels. (on an angle). Push the CSJ into the channel until you here a 'click'. CHANNEL HIGH-SIDE LOW-SIDE 20mm (0.79") 15mm (0.59") CHANNEL ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 5...
- Page 6 CHANNEL WHERE THE CSJ JOINING CHANNEL COVERS HOLES ON THE CHANNELS YOU ARE CONNECTING 2 x 55B 4 X 81AR 4 X 81AL 2 X 55BR 2 X 55BL ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 6...
- Page 9 Do not join components together at this location yet, as the screw may obstruct further assembly of other components ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 9...
-
Page 10: Rear Panel Assembly
Absco Economy Shed INSTRUCTIONS AND VIDEOS Model: J15301FK 1. REAR PANEL ASSEMBLY ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 10... - Page 11 Absco Economy Shed INSTRUCTIONS AND VIDEOS Model: J15301FK 2. SIDE PANEL ASSEMBLY LEFT SIDE PANEL Reverse side of Door Mullion ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 11...
- Page 12 Absco Economy Shed INSTRUCTIONS AND VIDEOS Model: J15301FK 3. SIDE PANEL ASSEMBLY RIGHT SIDE PANEL ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 12...
- Page 13 Absco Economy Shed INSTRUCTIONS AND VIDEOS Model: J15301FK 4. ROOF PANEL ASSEMBLY ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 13...
-
Page 14: Front Panel Assembly
Absco Economy Shed INSTRUCTIONS AND VIDEOS Model: J15301FK 5. FRONT PANEL ASSEMBLY ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 14... -
Page 15: Door Panel Assembly
INSTRUCTIONS AND VIDEOS Model: J15301FK 6. DOOR PANEL ASSEMBLY ALL VERTICAL DOOR CHANNELS ARE INSTALLED IN THE REVERSE DIRECTION IN COMPARISON TO HORIZONTAL DOOR CHANNELS 20mm FLANGE 15mm FLANGE ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 15... - Page 16 NOTE: The two holes required to connect the padbolt hasp for each door have not been pre-punched, to allow for proper alignment. position each hasp centrally over the padbolt shaft, and drill 3mm holes and secure with screws ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 16...
- Page 17 SIDE WALL PANEL CHANNELS FIT INTO THE NOTCHED FRONT AND REAR WALL PANEL CHANNELS REPLACE PADBOLT HASP 10mm SCREWS WITH 20MM SCREWS CONNECT DOOR MULLION SECTIONS WITH SIX 20mm SCREWS ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 17...
- Page 18 - EACH ANCHOR CONSISTS OF ONE NUT, BOLT, DYNABOLT AND STEEL ANGLE SLAB - DRILL A 10mm HOLE INTO THE WALL SHEET - DRILL A 10mm HOLE INTO THE CONCRETE DYNABOLT ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J15301FK 08/05/17 V1.1 PAGE 18...
