MELSEC iQ-F
FX5 User's Manual (Safety Control)
Safety main module
-FX5-SF-MU4T5
Safety input expansion module
-FX5-SF-8DI4
This product was jointly developed and manufactured
by Mitsubishi and SICK AG, Industrial Safety Systems in Germany.
* Note that the warranty on this product differs from
that on other programmable controllers.
(Refer to "WARRANTY" written in this manual.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MITSUBISHI ELECTRIC MELSEC iQ-F Series and is the answer not in the manual?

Questions and answers

Related Manuals for SICK MITSUBISHI ELECTRIC MELSEC iQ-F Series

Summary of Contents for SICK MITSUBISHI ELECTRIC MELSEC iQ-F Series

  • Page 1 Safety input expansion module -FX5-SF-8DI4 This product was jointly developed and manufactured by Mitsubishi and SICK AG, Industrial Safety Systems in Germany. * Note that the warranty on this product differs from that on other programmable controllers. (Refer to "WARRANTY" written in this manual.)

  • Page 3: Precautions Regarding Warranty

    PRECAUTIONS REGARDING WARRANTY This product is jointly developed and manufactured by Mitsubishi Electric Corporation and SICK AG. Note that there are differences in warranty. ● Warranty Item Safety extension module Other programmable controller products (e.g. MELSEC iQ-F series) Free warranty period...
  • Page 4 [Design Precautions] WARNING ● When the safety extension module detects a fault in an external power supply or itself, it turns off the outputs. Configure an external circuit so that the connected devices are powered off according to the output status (off) of the safety extension module. Incorrect configuration may result in an accident. ●...
  • Page 5 [Design Precautions] CAUTION ● During the control of an inductive load such as a lamp, heater, or solenoid valve, a large current (approximately ten times greater than normal) may flow when the output is turned from off to on. Take proper measures so that the flowing current dose does not exceed the value corresponding to the maximum load specification of the resistance load.
  • Page 6 [Design Precautions] CAUTION ● Observe the protective notes and measures. Observe the following items in order to ensure the proper use of the safety extension module. (1) When mounting, installing and using the safety extension module, observe the standards and directives applicable in your country.
  • Page 7 [Installation Precautions] CAUTION ● Do not touch the conductive parts of the product directly. Doing so may cause device failures or malfunctions. ● When drilling screw holes or wiring, make sure that cutting and wiring debris do not enter the ventilation slits of a programmable controller.
  • Page 8 [Wiring Precautions] WARNING ● Make sure to cut off all phases of a power supply externally before attempting installation or wiring work. Failure to do so may cause electric shock or damage to the product. ● Make sure to attach the terminal cover, provided as an accessory, before turning on the power or initiating operation after installation or wiring work.
  • Page 9 [Wiring Precautions] CAUTION ● Connect circuits isolated from hazardous voltage by double/reinforced insulation to terminal blocks or power connectors. ● Individually ground the GND wires of the safety extension module with a ground resistance of 100 Ω or less. Failure to do so may result in electric shock or malfunction. ●...
  • Page 10 [Startup and Maintenance Precautions] WARNING ● Do not touch any terminals while the programmable controller's power is on. Doing so may cause electric shock or malfunctions. ● Before cleaning or retightening terminals, cut off all phases of the power supply externally. Failure to do so in the power ON status may cause electric shock.
  • Page 11 [Startup and Maintenance Precautions] CAUTION ● Do not disassemble or modify the programmable controller. Doing so may cause failure, malfunction, or fire. ● For repair, please contact your local Mitsubishi Electric sales office. ● Turn off the power to the programmable controller before connecting or disconnecting any extension cable.

  • Page 12: Précautions De Sécurité

    PRÉCAUTIONS DE SÉCURITÉ (Lire ces précautions avant toute utilisation du produit.) Avant d’utiliser ce produit, lire attentivement ce manuel, les manuels auxquels il renvoie ainsi que les normes de sécurité, et toujours considérer la sécurité comme de la plus haute importance en manipulant le produit correctement. Les précautions de sécurité...
  • Page 13 [PRÉCAUTIONS DE CONCEPTION] AVERTISSEMENT ● Lorsque le module d’extension de sécurité détecte un problème d’alimentation externe ou une panne du module d’extension de sécurité lui-même, la sortie est désactivée. Configurez un circuit externe afin d’arrêter de façon certaine toute alimentation dangereuse en cas de désactivation de la sortie du module d’extension de sécurité.
  • Page 14 [PRÉCAUTIONS DE CONCEPTION] ATTENTION ● À la commande d'une charge inductive comme une lampe, un réchauffeur ou une électrovanne, un fort courant (environ 10 fois supérieur à l'intensité normale) peut traverser la sortie quand celle-ci passe de OFF à ON. Prenez les mesures appropriées pour que l’intensité de courant ne dépasse pas la valeur correspondant à...
  • Page 15 [PRÉCAUTIONS DE CONCEPTION] ATTENTION ● Les précautions et les mesures de sécurité doivent être respectées. Respectez les précautions suivantes afin d’utiliser correctement le module d’extension de sécurité. (1) Soyez sûr de respecter les normes et les directives qui s’appliquent dans le pays où le module d’extension de sécurité...
  • Page 16 [PRÉCAUTIONS D'INSTALLATION] ATTENTION ● Ne pas toucher directement les parties conductrices du produit. Cela pourrait être à l'origine d'une panne ou d'un dysfonctionnement. ● Lors du perçage des trous de vis ou du câblage, assurez-vous que les débris de coupe et de câblage ne pénètrent pas dans les fentes de ventilation du contrôleur programmable.
  • Page 17 [PRÉCAUTIONS DE CABLAGE] AVERTISSEMENT ● Assurez-vous de couper toutes les phases de l'alimentation externe avant d’essayer l'installation ou le câblage. Faute de quoi, il y a risque d'électrocution ou d'endommagement du produit. ● Assurez-vous d'attacher le couvercle de borne, fourni en tant qu'accessoire, avant d'alimentation ou d'opération de lancement après installation ou câblage.
  • Page 18 [PRÉCAUTIONS DE CABLAGE] ATTENTION ● Connectez le connecteur d’alimentation et le bornier à un circuit isolé des tensions dangereuses au moyen d’une isolation double ou renforcée. ● Effectuez une mise à la terre de classe D (résistance à la mise à la terre : 100 Ω ou moins) du module d’extension de sécurité.
  • Page 19 [PRÉCAUTIONS DE MISE EN SERVICE ET DE MAINTENANCE] AVERTISSEMENT ● Ne toucher aucune borne quand le contrôleur programmable est sous tension. Cela pourrait être à l'origine d’électrocutions ou de dysfonctionnements. ● Avant de nettoyer ou de resserrer les bornes, couper toutes les phases de l'alimentation externe. Faute de quoi, il y a risque d'électrocution avec les bornes sous tension.
  • Page 20 [PRÉCAUTIONS DE MISE EN SERVICE ET DE MAINTENANCE] ATTENTION ● Ne pas démonter ni modifier le contrôleur programmable. Cela pourrait causer un départ de feu, une panne ou un dysfonctionnement des équipements. ● Pour réparation, contactez votre représentant local de Mitsubishi Electric. ●...
  • Page 21 [PRÉCAUTIONS DE TRANSPORT] ATTENTION ● Le contrôleur programmable est un instrument de précision. Pendant le transport, évitez de dépasser le niveau de choc indiqué dans les spécifications générales mentionnées dans le Manuel de l’Utilisateur (Matériel) du module CPU, notamment en plaçant le contrôleur dans une boîte spéciale ou en utilisant une palette amortisseuse.

  • Page 22: Introduction

    INTRODUCTION Thank you for purchasing MELSEC iQ-F series programmable controllers. This manual describes the handling of MELSEC iQ-F series safety extension modules. Before using this product, please read this manual and relevant manuals carefully and develop familiarity with the specifications to handle the product correctly. Please make sure that the end users read this manual.

  • Page 23: Table Of Contents

    CONTENTS PRECAUTIONS REGARDING WARRANTY ........... . .1 SAFETY PRECAUTIONS .
  • Page 24 CHAPTER 8 PROGRAMMING Programming Procedure ..............111 Programming Method (for FX5-SF-MU4T5/FX5-SF-8DI4).

  • Page 25: Relevant Manuals

    RELEVANT MANUALS Manual name <manual number> Description MELSEC iQ-F FX5 User's Manual (Startup) Performance specifications, procedures before operation, and troubleshooting of FX5 CPU modules <JY997D58201> MELSEC iQ-F FX5U User's Manual (Hardware) Details of hardware of FX5U CPU modules, including I/O specifications, wiring, installation, and <JY997D55301>...
  • Page 26 Manual name <manual number> Description MELSEC iQ-F FX5 User's Manual (Temperature Temperature control modules Control) <SH-081799ENG> MELSEC iQ-F FX5 User's Manual (Safety Control) Safety extension modules <SH082078ENG> (This manual) GX Works3 Operating Manual System configuration, parameter settings, and online operations of GX Works3 <SH-081215ENG>...

  • Page 27: Terms

    TERMS Unless otherwise specified, this manual uses the following terms. Term Description ■Devices A generic term for FX5U and FX5UC programmable controllers. FX5 CPU module A generic term for FX5U CPU modules and FX5UC CPU modules. FX5U CPU module A generic term for FX5U-32MR/ES, FX5U-32MT/ES, FX5U-32MT/ESS, FX5U-64MR/ES, FX5U-64MT/ES, FX5U-64MT/ ESS, FX5U-80MR/ES, FX5U-80MT/ES, FX5U-80MT/ESS, FX5U-32MR/DS, FX5U-32MT/DS, FX5U-32MT/DSS, FX5U- 64MR/DS, FX5U-64MT/DS, FX5U-64MT/DSS, FX5U-80MR/DS, FX5U-80MT/DS, and FX5U-80MT/DSS.

  • Page 28: Chapter 1 Overview

    OVERVIEW Safety extension module is a module that can configure a safety control system with an FX5 CPU module. (1) FX5 CPU module (2) Safety main module (FX5-SF-MU4T5) (3) Safety input expansion module (FX5-SF-8DI4) (4) Robots (5) Light curtains Features The following explains the features of a safety extension module.
  • Page 29 MEMO 1 OVERVIEW...

  • Page 30: Chapter 2 Specifications

    SPECIFICATIONS This chapter explains the specifications of a safety extension module. General Specifications The following shows the specifications of a safety extension module. The general specifications other than below are the same as those of the CPU module to be connected. For the general specifications, refer to the following: MELSEC iQ-F FX5U User's Manual (Hardware) MELSEC iQ-F FX5UC User's Manual (Hardware)

  • Page 31: Power Supply Specifications

    Power Supply Specifications Power supply specifications of an FX5-SF-MU4T5 Item Specification Internal power supply 5 VDC 200 mA, 24 VDC 5 mA External power supply 24 VDC (+20%, -15%) 125 mA Power supply voltage circuit system PELV or SELV , max. 6 A Rated input current 5.2 A *1 PELV (protective extra low voltage) and SELV (safety extra low voltage) are circuits that are protected by voltage limit or insulation.

  • Page 32: Performance Specifications

    Performance Specifications The following shows the performance specifications. Safety inputs of an FX5-SF-MU4T5 Item Specification Number of inputs 4 points Input voltage (ON) 13 VDC to 30 VDC Input voltage (OFF) -5 VDC to 5 VDC Input current (ON) 3 mA (2.4 mA to 3.8 mA) Input current (OFF) -2.5 mA to 2.1 mA Input response time (filter delay)
  • Page 33 Test outputs of an FX5-SF-MU4T5 Item Specification Number of outputs 2 points Output method Source output, short-circuit protection, cross-circuit detection Output voltage 16 VDC to 30 VDC Output current 120 mA Test cycle (T0 and T1) Program 1, 2, 4, 5, 6, and 9 40 ms Program 3.2 T0 = 400 ms...

  • Page 34: Safety Output Derating Curve

    Safety inputs of an FX5-SF-8DI4 Item Specification Number of inputs 8 points Input voltage (ON) 13 VDC to 30 VDC Input voltage (OFF) -5 VDC to 5 VDC Input current (ON) 3 mA (2.4 mA to 3.8 mA) Input current (OFF) -2.5 mA to 2.1 mA Indication of input operation LED lights when an input is ON.

  • Page 35: Parts Names

    Parts Names The following shows the names of parts on a safety extension module. FX5-SF-MU4T5 2-I4.5 mounting holes (10) (12) (11) Name Description FUNCTION rotary switch To select a built-in program. For details on the functions to select a built-in program, refer to the following: Page 40 Built-In Program Selection Function DELAY rotary switch To set a delay time for off delay.
  • Page 36 FX5-SF-8DI4 2-I4.5 mounting holes (11) (10) Name Description INPUT A rotary switch To select a program. For details on the functions to select a program, refer to the following: Page 40 Built-In Program Selection Function INPUT B rotary switch Terminal block (spring clamp terminal A spring clamp terminal block.
  • Page 37 LED indication ■FX5-SF-MU4T5 The following shows the indications of the LEDs on an FX5-SF-MU4T5. LED name LED color Description POWER LED Green Indicates the power supply status. ON: Normal operation Flashing: The rotary switch setting was changed during operation. OFF: Powered OFF ERROR LED Indicates an error status.
  • Page 38 ■FX5-SF-8DI4 The following shows the indications of the LEDs on an FX5-SF-8DI4. LED name LED color Description POWER Green Indicates the power supply status. ON: Normal operation Flashing: The rotary switch setting was changed during operation. OFF: Powered OFF ERROR Indicates an error status.

  • Page 39: Chapter 3 Procedures Before Operation

    PROCEDURES BEFORE OPERATION This chapter explains the procedures before operation. Checking the specifications of a safety extension module Check the specifications of a safety extension module. (Page 28 SPECIFICATIONS) The system configuration can be checked in advance using MELSEC iQ-F Series Safety Extension Module Configuration Guide.
  • Page 40 MEMO 3 PROCEDURES BEFORE OPERATION...

  • Page 41: Chapter 4 Functions

    FUNCTIONS This chapter explains the details of functions that can be used for a safety extension module, and their setting methods. For details on the buffer memory, refer to the following: Page 136 Buffer Memory List of Functions The following lists the functions of a safety extension module. Categor Item Description...

  • Page 42: Built-In Program Selection Function

    Built-In Program Selection Function This function selects a built-in program by the rotary switch(es) on the front of an FX5-SF-MU4T5 and FX5-SF-8DI4. Setting method A built-in program can be selected by the following rotary switch(es). • FUNCTION (FX5-SF-MU4T5) • INPUT A (FX5-SF-8DI4) •...
  • Page 43 Operation One out of nine kinds of programs can be set for each of FX5-SF-MU4T5 and FX5-SF-8DI4. ■Programs that can be set for an FX5-SF-MU4T5 Each program of an FX5-SF-MU4T5 consists of logic path A and B. Each program (logic path A and B) are logic circuits that turn ON and OFF each safety output depending on the ON/OFF status of respective safety inputs.
  • Page 44 Prog Overview Description Logic path A (l0/l1) Logic path B (l2/l3) Program overview Input Input device device     Independent A program to execute two types of N/C + N/C N/C + N/C control safety control that are mutually independent.
  • Page 45 ■Programs that can be set for an FX5-SF-8DI4 Eight safety inputs of an FX5-SF-8DI4 are grouped into two safety inputs: INPUT A (safety input I0 to I3) and INPUT B (safety input I4 to I7) of the rotary switch. A program to link the four safety inputs to logic path A or B of an FX5-SF-MU4T5 can be selected by the rotary switch. The list of built-in programs that can be set for an FX5-SF-8DI4 is as follows.
  • Page 46 Prog Overview Description Logic path A Logic path B Program overview connection (l0/l1, l2/l3) connection (l4/l5, l6/l7) Input Input device device     Bypass Connect two safety inputs (I0/I1 or N/C + N/C N/C + N/C I0 I1 I2 I3 I4/I5) of either INPUT A or INPUT B in dual-channel, and link them to logic path A or B of an FX5-SF-...
  • Page 47 ■Details of FX5-SF-8DI4 program 9 The combinations of settings when INPUT A or INPUT B rotary switch is set to '9' are as follows. Rotary switch Rotary switch Description Program overview (INPUT A) (INPUT B) Connect eight inputs in single-channel, and link them to logic path A of I0 I1 I2 I3 an FX5-SF-MU4T5 using AND logic.
  • Page 48 Rotary switch Rotary switch Description Program overview (INPUT A) (INPUT B) Connect I0/I1 and I4/I5 in dual-channel, and link them to logic path A I0 I1 I2 I3 using AND logic as the trigger of a bypass function. I4 I5 I6 I7 (1) Connect logic path A with bypass When both INPUT A and INPUT B are set to '9', a configuration error ...
  • Page 49 Rotary switch Rotary switch Description Program overview (INPUT A) (INPUT B) Connect eight inputs in dual-channel, and link them to logic path B of I0 I1 I2 I3 an FX5-SF-MU4T5 using OR logic. I4 I5 I6 I7 (1) Connect logic path B with OR link Connect I0/I1 and I4/I5 in dual-channel, and link them to logic path B I0 I1 I2 I3 using AND logic as the trigger of a bypass function.
  • Page 50 Connectable devices and ladder symbols ■Connectable devices The connectable inputs and sensors, and the corresponding programs are as follows. Inputs and sensors Description Corresponding program number (rotary switch setting) FX5-SF-MU4T5 FX5-SF-8DI4 Input of logic Input of logic Input (I0 to I3) Input (I4 to I7) path A (I0, I1) path B (I2, I3) •...
  • Page 51 Details of the program 1 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '1'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 52 The details of the program 1 are as follows. One logic path Inputs/ sensors Dual-channel equivalent N/C Single-channel N/C contact contact Dual-channel equivalent N/C Cross-circuit detecting control contact (without cross-circuit signals, synchronous time detection) monitoring 1500 ms ESPE (sensors with Pressure sensitive mat (four- semiconductor output) wire system)
  • Page 53 Details of the program 2 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '2'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 54 The details of the program 2 are as follows. One logic path Inputs/ sensors Dual-channel complementary Single-channel N/C contact N/C / N/O contact Dual-channel equivalent N/C ESPE contact (without cross-circuit Cross-circuit detecting control detection) signals, synchronous time ESPE (sensors with monitoring 1500 ms semiconductor output) OR with FX5-SF-8DI4 (switch position 7)
  • Page 55 Details of the program 3 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '3'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols In the program 3.1, link a sensor and logic path A or B as follows.
  • Page 56 The details of the program 3.1 and program 3.2 are as follows. One logic path Program 3.1 Program 3.2 Inputs/ Single-channel N/C contact T0 to I0: Inductive switch with A3.1 B3.2 A3.1 B3.2 sensors Dual-channel equivalent N/C semiconductor output (bridge contact (without cross-circuit between T1 and I1) detection)
  • Page 57 Details of the program 4 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '4'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 58 The details of the program 4 are as follows. One logic path Inputs/ Two dual-channel complementary N/C / N/O contacts sensors Two-hand operation (EN 574 C compliant) Cross-circuit detecting control signals OR with FX5-SF-8DI4 (switch position 7) FX5-SF-8DI4 AND with FX5-SF-8DI4 (switch position 1 to 6) FX5-SF-8DI4 Connection of X0: without restart interlock/with start-up testing...
  • Page 59 Details of the program 5 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '5'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 60 The details of the program 5 are as follows. Two logic paths have already been connected. Program 5.1 Program 5.2 Inputs/ sensors Dual-channel equivalent N/C Two single-channel N/C contact contacts Two-hand operation (EN 574 A compliant), with/without jog mode Cross-circuit detecting control signals OR with FX5-SF-8DI4 (switch position 7) FX5-SF-8DI4...
  • Page 61 Details of the program 6 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '6'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 62 The details of the program 6 are as follows. Two logic paths have already been connected. Inputs/ sensors Dual-channel equivalent N/C Dual-channel equivalent N/C contact contact Cross-circuit detecting control Cross-circuit detecting control signals signals OR with FX5-SF-8DI4 (switch position 7) FX5-SF-8DI4 FX5-SF-8DI4 AND with FX5-SF-8DI4 (switch position 1 to 6)
  • Page 63 Details of the program 7 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '7'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 64 The details of the program 7 are as follows. Two logic paths have already been connected. Inputs/ sensors Single-channel N/C contact Single-channel N/C contact Dual-channel equivalent N/C Dual-channel equivalent N/C contact (without cross-circuit contact (without cross-circuit detection) detection) ESPE and sensors with ESPE and sensors with semiconductor output semiconductor output...
  • Page 65 Details of the program 8 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '8'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 66 The details of the program 8 are as follows. Two independent logic paths Inputs/ sensors Single-channel N/C contact Single-channel N/C contact Dual-channel equivalent N/C Dual-channel equivalent N/C contact (without cross-circuit contact (without cross-circuit detection) detection) ESPE and sensors with ESPE and sensors with semiconductor output semiconductor output OR with FX5-SF-8DI4 (switch position 7)
  • Page 67 Details of the program 9 for FX5-SF-MU4T5s The following explains the program when the FUNCTION rotary switch is set to '9'. For details on the connectable devices and ladder symbols in the program, refer to the following: Page 48 Connectable devices and ladder symbols Link a sensor and logic path A or B as follows.
  • Page 68 The details of the program 9 are as follows. Two logic paths have already been connected. Inputs/ sensors Dual-channel equivalent N/C Single-channel N/C contact contact Dual-channel equivalent N/C Cross-circuit detecting control contact (without cross-circuit signals detection) ESPE and sensors with semiconductor output OR with FX5-SF-8DI4 (switch position 7) FX5-SF-8DI4...
  • Page 69 Considerations ■Applying a setting The program does not run only by selecting a built-in program using the rotary switch(es). To run the selected built-in program, settings must be applied. For the procedure for applying the settings, refer to the following: Page 112 Applying a setting Rearranging the wiring of X0, X1, and X2 after the settings have been applied will cause an error.

  • Page 70: Off Delay Delay Setting Function

    Off Delay Delay Setting Function This function sets off delay for predefined outputs by setting the rotary switch on the front of an FX5-SF-MU4T5. By setting off delay, when a danger has been detected, the safety output is turned OFF after a user-defined period of time. When using a motor, the module turns OFF after the motor has been completely stopped.
  • Page 71 Precautions ■Applying a setting The program does not run only by selecting a built-in program using the rotary switch(es). To run the selected built-in program, settings must be applied. For the procedure for applying the settings, refer to the following: Page 112 Applying a setting Rearranging the wiring of X0, X1, and X2 after the settings have been applied will cause an error.

  • Page 72: Muting Function

    Muting Function This function temporarily disables the protection function of a safety device while a conveyance pallet passes through the detection area of electro-sensitive protective equipment (ESPE). This means that material can be transported to or from a machine or system without any disruption to the working process. Muting sensors monitor the existence of materials being transported.
  • Page 73 Considerations • The muting function is allowed to be activated only when transporting a material to the hazardous area. • The muting function should be triggered by at least two independently wired signals (which are received from muting sensors) and should not depend entirely on software signals (from a programmable controller). •...

  • Page 74: And Link

    AND link This function connects each input of an FX5-SF-MU4T5 and FX5-SF-8DI4 using AND logic. Setting method ■For FX5-SF-MU4T5 Set the FUNCTION rotary switch to '5', '6', '7', or '9'. Sensors that can be connected to an FX5-SF-MU4T5 are as follows. : Connectable, : Not connectable FX5-SF-MU4T5 Inputs and sensors...
  • Page 75 Page 57 Details of the program 5 for FX5-SF-MU4T5s Page 59 Details of the program 6 for FX5-SF-MU4T5s Page 61 Details of the program 7 for FX5-SF-MU4T5s Page 65 Details of the program 9 for FX5-SF-MU4T5s ■For FX5-SF-MU4T5 and FX5-SF-8DI4 Set the FUNCTION rotary switch of an FX5-SF-MU4T5 as necessary.

  • Page 76: Or Link

    OR link This function connects each input of an FX5-SF-MU4T5 and FX5-SF-8DI4 using OR logic. Setting method ■For FX5-SF-MU4T5 Set the FUNCTION rotary switch to '1' or '2'. Sensors that can be connected to an FX5-SF-MU4T5 are as follows. : Connectable, : Not connectable FX5-SF-MU4T5 Inputs and sensors Description...
  • Page 77 ■For FX5-SF-MU4T5 and FX5-SF-8DI4 Set the FUNCTION rotary switch of an FX5-SF-MU4T5 as necessary. Set the rotary switch of an FX5-SF-8DI4 to '7'. Sensors that can be connected to an FX5-SF-8DI4 are as follows. : Connectable, : Not connectable FX5-SF-8DI4 Inputs and sensors Description Input (I0 to...

  • Page 78: Bypass

    Bypass This function forcibly turns ON the outputs of an FX5-SF-MU4T5 for up to 60 seconds while the inputs of an FX5-SF-8DI4 turn ON, by connecting the inputs of the FX5-SF-8DI4 and a logic path of FX5-SF-MU4T5 with OR link. Setting method Set the rotary switch of an FX5-SF-8DI4 to '8'.

  • Page 79: Restart Interlock

    Restart Interlock When a danger is detected and a control output is turned OFF, a restart interlock prevents a system from restarting by keeping the safety output OFF status until safety is verified and a reset signal is turned ON. Setting method The function is available by wiring terminals.

  • Page 80: External Device Monitoring (Edm)

    External Device Monitoring (EDM) This function monitors if the contactors are turned OFF during a reset. An external device failure and adherence of parts can be detected. Setting method The function is available by wiring terminals. For the outline of the wiring diagram, refer to the following: Page 77 Restart Interlock For details on the wiring, refer to the following: Page 40 Built-In Program Selection Function...

  • Page 81: Retriggering Of The Delayed Ossds

    4.10 Retriggering of the Delayed OSSDs This function disables off delay when an input is in the safe state. Setting method The function is available by wiring terminals. To enable the function, wire the X2 terminal and the T1 terminal. Operation The following shows the retriggering timing charts when off delay is set to a value longer than zero second.

  • Page 82: Enable Input (Xs0 Terminal)

    4.11 ENABLE Input (XS0 Terminal) ENABLE input (XS0 terminal) is a terminal to enable safety outputs. Setting method Connect the XS0 terminal of an FX5-SF-MU4T5 to the same power supply as the plus terminal. Operation When the XS0 terminal goes LOW (0 V), the safety outputs Q0 to Q3 always go LOW. The input signals such as a reset and muting are not detected until the XS0 terminal goes HIGH again.

  • Page 83: Two-Hand Operation/Jog Mode

    4.12 Two-Hand Operation/Jog Mode Two-hand operation can be used by connecting a two-hand control device that complies with EN 574 (Two-hand control device - Functional aspects and design principles) A or C to an FX5-SF-MU4T5. Jog mode can limit the duration time which keeps the safety outputs Q2 and Q3 ON to five seconds by using a two-hand control device.

  • Page 84: Error History

    4.13 Error History An error history occurred in the safety main module can be saved in the error history saving area in the buffer memory. Up to 16 error history records can be saved. Operation An error occurred in a safety extension module is stored in the buffer memory as error history. Up to 16 error history records can be saved for each device.
  • Page 85 The start address of error history where the latest error is stored can be found in 'Latest address of error history' (Un\G1). When the third error occurred: The third error is stored in an error history No.3 and 720 (start address of the error history No.3) is stored in 'Latest address of error history' (Un\G1).
  • Page 86 When the 17th error occurred: The 17th error is stored in an error history No.1 and 700 (start address of the error history No.1) is stored in 'Latest address of error history' (Un\G1). 'Latest address of error history' (Un\G1): 700 Un\G700 Error history No.1 17th error...

  • Page 87: Safety Information Monitoring Function

    4.14 Safety Information Monitoring Function To store information including the I/Os, settings, and error codes of a safety extension module to the buffer memory. The safety information can be referenced by user programs and built-in functions (such as Web server) of a CPU module or the monitoring screen of GX Works3.
  • Page 88 Address Address Buffer memory name Data type Auto-refresh (decimal) (hexadecimal) 2nd Module X1 terminal startup state Monitor   2nd Module X2 terminal startup state Monitor 2nd Module Off delay time Monitor   3rd Module Input signal Monitor  3rd Module Output signal Monitor ...

  • Page 89: Chapter 5 System Configuration

    SYSTEM CONFIGURATION A safety control system can be configured by attaching a safety extension module to a general control system. A system configuration example is as follows. (1) FX5 CPU module (2) Input/output module, powered input/output module, and intelligent function module (3) Safety main module (FX5-SF-MU4T5) (4) Safety input expansion module (FX5-SF-8DI4) Number of connectable modules and position to connect...
  • Page 90 MEMO 5 SYSTEM CONFIGURATION...

  • Page 91: Chapter 6 Wiring

    WIRING This chapter explains the wiring for connecting a safety extension module. Spring Clamp Terminal Block This section explains the wiring for a spring clamp terminal block. Applicable wire A wire that can be connected to a spring clamp terminal block is as follows. Number of wires per terminal Wire size Single wire, strand wire...
  • Page 92 Removal and installation of a terminal block The following shows the method for removing and installing a terminal block. ■Lever position to lock and release A three-step stopper is attached to prevent the lever from rotating, facilitating installation and removal of the terminal block. When removing or installing the terminal block, move the lever to the corresponding position.
  • Page 93 Wiring of an electric wire ■When using a ferrule with insulation sleeve Insert a wire to which a ferrule with insulation sleeve is cramped into the wire insertion opening. ■When using a single wire or strand wire Using a flathead screwdriver, push the open/close button on the terminal block. While pushing the open/close button, insert the wire securely until it reaches the end.

  • Page 94: Terminal Arrangement

    Terminal Arrangement This section explains the terminal arrangement of a safety extension module. FX5-SF-MU4T5 The terminal arrangement of an FX5-SF-MU4T5 is as follows. Left side of terminal arrangement Right side of terminal arrangement Name Description Name Description Safety input 0 Safety output 0 Safety input 1 Safety output 1...
  • Page 95 FX5-SF-8DI4 The terminal arrangement of an FX5-SF-8DI4 is as follows. Left side of terminal arrangement Right side of terminal arrangement Name Description Name Description Safety input 0 Test output 0 Safety input 1 Test output 1 Safety input 2 Test output 2 Safety input 3 Test output 3 Safety input 4...

  • Page 96: Grounding

    Grounding Observe the following: • Provide class D grounding. (Grounding resistance: 100 Ω or less) • Provide independent grounding when possible. • If independent grounding cannot be provided, employ "Shared grounding" shown below. Programmable Programmable Programmable Equipment Equipment Equipment controller controller controller Ground...

  • Page 97: External Wiring Example

    For details on functions and programs, refer to the following section. Page 39 FUNCTIONS For details on the products including safety relay and universal output expansion module manufactured by SICK AG, refer to the SICK manuals. Check the wiring example including an FX5-SF-8DI4 in MELSEC iQ-F Series Safety Extension Module Configuration Guide.
  • Page 98 Wiring an emergency stop button The following shows an example of the program 1 with a restart interlock and EDM. +24V FX5-SF-MU4T5 FUNCTION PELV (1) Reset switch, start switch (2) Contactor contact point (3) An emergency stop button (4) Contactor 6 WIRING 6.4 External Wiring Example...
  • Page 99 Wiring a magnetic safety switch The following shows an example of the program 2 with a restart interlock and EDM. +24V SICK RE300-DA FX5-SF-MU4T5 FUNCTION PELV (1) Reset switch, start switch (2) Contactor contact point (3) Contactor 6 WIRING 6.4 External Wiring Example...
  • Page 100 Wiring light curtains and muting sensors The following shows an example of the program 3.1 with a restart interlock and EDM. +24V +24V +24V Test n.c. n.c. OSSD1 n.c. OSSD2 C4000S C4000R FX5-SF-MU4T5 +24V +24V FUNCTION WS 27-2 WE 27-2 +24V +24V WS 27-2...
  • Page 101 Wiring a non-contact switch The following shows an example of the program 3.2 with a restart interlock and EDM. +24V SICK IN40-D SICK FX5-SF-MU4T5 IN40-D FUNCTION PELV (1) Reset switch, start switch (2) Contactor contact point (3) Contactor 6 WIRING...
  • Page 102 Wiring a transmissive photoelectric switch and an universal output expansion module The following shows an example of the program 3.2 with a restart interlock and EDM. +24V +24V +24V L21S L21E FX5-SF-MU4T5 +24V +24V SICK FUNCTION UE10-30S L21E L21S +24V +24V L21S L21E 2) PELV...
  • Page 103 Wiring a two-hand control The following shows an example of the program 4 without a restart interlock and with EDM. +24V FX5-SF-MU4T5 FUNCTION PELV (1) Contactor contact point (2) Two-hand switches C (3) Contactor 6 WIRING 6.4 External Wiring Example...
  • Page 104 Wiring light curtains The following shows an example of the program 7 with a restart interlock and EDM. +24V FX5-SF-MU4T5 FUNCTION Sel1 Sel1 +24V +24V Sel2 Sel2 n.c. n.c. Test OSSD1 n.c. OSSD2 Shield Shield C2000S C2000R PELV (1) Reset switch, start switch (2) Contactor contact point (3) An emergency stop button (4) Contactor...
  • Page 105 Wiring two switches The following shows an example of the program 8 with a restart interlock and EDM. +24V FX5-SF-MU4T5 FUNCTION PELV (1) Reset switch, start switch (2) Contactor contact point (3) Contactor 6 WIRING 6.4 External Wiring Example...

  • Page 106: Considerations On Wiring External Devices

    Considerations on wiring external devices The following shows the wiring considerations. Installation precautions • Safety extension modules fulfill the EMC requirements in accordance with the basic specification IEC 61000-6-2 and EN 61131-2 for industrial use. • Mitsubishi industrial safety devices are designed only for DC power supply applications which have one power supply and one power supply destination.
  • Page 107 Wiring precautions • Power OFF the entire system while wiring. Otherwise, the system may be activated unexpectedly while connecting to devices. • Electrical installation should be designed in accordance with IEC 60204-1. • All connected sensors and downstream controllers and wiring/installation must correspond to the required category according to EN ISO 13849-1 and to the SILCL according to EN 62061 (protected installation, single plastic-sheathed cable with shielding).

  • Page 108: Installation Of Muting Sensors

    Installation of Muting Sensors This section explains the installation position of muting sensors. Always place muting sensors so that only materials are detected and not the conveyance equipment (pallet or vehicle). Additionally, they should be placed in the position where materials can pass unhindered, but people are reliably detected. (1): Conveyance equipment (2): Conveying surface (3): Material...
  • Page 109 Optical sensors When optical sensors are used for muting sensors, install the sensors with background suppression so that only materials to be transported can meet the muting condition. By using the optical sensors with background suppression, these can detect material only up to a specific distance. Objects that are further than the material to be detected are not detected.
  • Page 110 Sequential muting In the following example, the material moves from left to right. As soon as the muting sensors A1 and A2 are activated, a protection function provided by the protective equipment (ESPE) is temporality disabled. The protection function remains disabled until one of the sensors within the muting sensors B1 and B2 is enabled again. ESPE (1): Hazardous area S1: Distance between internal sensors (the sensors are placed symmetry within the ESPE detection line)

  • Page 111: Chapter 7 Parameter Settings

    PARAMETER SETTINGS Set parameters for a safety extension module. Refresh Setting Set the buffer memory area of a safety extension module for refreshing the area automatically. By configuring the refresh setting, reading/writing data from/to the buffer memory by a program becomes unnecessary. Setting method Set the module parameter in GX Works3.
  • Page 112 MEMO 7 PARAMETER SETTINGS 7.1 Refresh Setting...

  • Page 113: Chapter 8 Programming

    PROGRAMMING This chapter explains the programming procedure for a safety control system. System configuration example In this chapter, program examples based on the following system configuration are explained. (1) CPU module (FX5U CPU module) (2) Safety main module (FX5-SF-MU4T5) (3) Safety input expansion module (FX5-SF-8DI4) (4) Safety input expansion module (FX5-SF-8DI4) Programming Procedure The following shows the procedure for creating programs for running a safety control system.

  • Page 114: Programming Method (For Fx5-Sf-Mu4T5/Fx5-Sf-8Di4)

    Programming Method (for FX5-SF-MU4T5/FX5-SF- 8DI4) Select a program by turning the rotary switch on the safety extension module. FX5-SF-MU4T5 FX5-SF-8DI4 For details on the programs, refer to the following section. Page 40 Built-In Program Selection Function The settings can be checked in MELSEC iQ-F Series Safety Extension Module Configuration Guide Page 151 How to Use MELSEC iQ-F Series Safety Extension Module Configuration Guide After wiring external devices and selecting a program, apply the setting.

  • Page 115: Programming Method (For Fx5 Cpu Module)

    Programming Method (for FX5 CPU module) A sequential program is not required because a program for a safety control can be selected using a rotary switch. When using safety control information in a general control program, use the buffer memory of an FX5-SF-MU4T5 where the safety control information is stored.

  • Page 116: Chapter 9 Commissioning

    COMMISSIONING This chapter shows the considerations when checking the entire system and performing periodic inspection. Validation of Application System commissioning can be performed only when the validation of the whole system was successful. Validation may only be performed by professionals trained accordingly. Additionally, regular testing is required after the commissioning.
  • Page 117 MEMO 9 COMMISSIONING 9.2 Considerations for Inspection...

  • Page 118: Chapter 10 Troubleshooting

    TROUBLESHOOTING This chapter explains errors that may occur in a safety extension module and their troubleshooting methods. To resolve an error immediately, determining the cause and applying appropriate corrective actions are essential. The troubleshooting methods are as follows. Checking method Description Reference Checking errors visually (by LEDs)
  • Page 119 LED name LED color Description Q2/Q3 LED Green Indicates the output statuses of Q2 and Q3. ON: Output ON Flashing: In lapse of off delay time OFF: Output OFF X0 LED Green Indicates the input status of X0. ON: Input ON Flashing: Input OFF (by restart interlock or EDM) OFF: Input OFF X1 LED...
  • Page 120 LED name LED color Description I5 LED Green Indicates the input status of I5. ON: Input ON Flashing: A process error occurred or synchronous time (1500ms) was exceeded. Flashing (I4 and I5 flash in phase): A cross-circuit occurred between I4 and I5. OFF: Input OFF I6 LED Green...

  • Page 121: Checking Errors With An Engineering Tool

    10.2 Checking Errors with an Engineering Tool Check an error occurred in the module and error history, and identify the cause using an engineering tool. The detailed information such as error cause and corrective actions obtained from an engineering tool is more helpful than those obtained from LEDs.
  • Page 122 ■Common information The common items of FX5-SF-MU4T5 are displayed and the details of monitor can be checked. Item Description Model Name To display the module name "FX5-SF-MU4T5". Product No Hidden F/W Version To display the firmware version. Booter F/W Version Hidden H/W version Hidden...
  • Page 123 ■Module information list The common information of modules such as H/W information including LEDs and switches, and the information specific to each module can be checked. Item Description Operating status of a safety control Operating status To display the operating status of a safety control. Whole safety control system System CRC value To display the system CRC value of a safety control.

  • Page 124: Troubleshooting By Symptom

    10.3 Troubleshooting by Symptom When the function of a safety extension module does not work properly, check the following items and take appropriate corrective action. POWER LED on a safety extension module turns OFF FX5-SF-MU4T5 Check item Corrective action Check if the power is supplied. Check that the supply voltage from the power connected to the safety extension module is within the rated range.

  • Page 125: List Of Error Codes

    10.4 List of Error Codes When an error occurs in a running safety extension module, the error code is stored to 'Latest error code' (Un\G0) in the buffer memory, and 'Error flag' (Un\G69.15) turns ON. The following shows the error code list that will be stored in 'Latest error code' (Un\G0). Error code Error name Description...
  • Page 126 Error code Error name Description Corrective action 3107H Bus error A bus error occurred. Remove dirt and dust on the connector, and check if there is poor contact of the cable. Additionally, there is a possibility that the module is affected by noise. Take measure to reduce noise, check the setting and wiring, and reset the power of the whole system.
  • Page 127 Error code Error name Description Corrective action 3341H to Memory error A memory error occurred. Check the setting and wiring, and reset the power of the whole 3342H system. If the error is not resolved, there is a possibility that the module is malfunctioning.
  • Page 128 Error code Error name Description Corrective action 3801H to Each of the following bits indicate an error. Check the power supply voltage, and reset the power of the whole 38FFH 38H system. Lower bits: Overvoltage/undervoltage monitoring (0: no error, 1: with If the error is not resolved, there is a possibility that the module is error) malfunctioning.
  • Page 129 Error code Error name Description Corrective action 391CH to Setting and diagnostic Setting and diagnostic error occurred. Check the setting and wiring, and reset the power of the whole 391FH error system. If the error is not resolved, there is a possibility that the module is malfunctioning.
  • Page 130 Error code Error name Description Corrective action 3B04H I2/I3 synchronization A synchronization time/concurrence error Inconsistency in the double input state is detected. time/concurrence error occurred in I2/I3. Turn the input signals I2/I3 OFF and ON again. If the error is not resolved, check the wiring of the corresponding input terminals.

  • Page 131: Appendix

    APPENDIX Appendix 1 External Dimensions The following figure shows the external dimensions of a safety extension module. FX5-SF-MU4T5 19.2 (Unit: mm) • Mass (weight): 0.3 kg FX5-SF-8DI4 19.2 (Unit: mm) • Mass (weight): 0.25 kg APPX Appendix 1 External Dimensions...

  • Page 132: Appendix 2 Standards

    Appendix 2 Standards Certification of UL, cUL standards FX5-SF-MU4T5s and FX5-SF-8DI4s support UL (UL, cUL) standards. For the models that support UL standards, refer to the following file number. UL file number: E336245 Safety functions of a safety extension module are not evaluated by UL. The safety extension module is certified based on the UL 508 general application standard.

  • Page 133: Considerations For Complying With Ec Directive

    Considerations for complying with EC directive Considerations when using FX5-SF-MU4T5 or FX5-SF-8DI4 When using FX5-SF-MU4T5 or FX5-SF-8DI4, attach a ferrite core to the power cable of a CPU module. Make 3 turns around the ferrite core and attach within approximately 200 mm from the terminal block and connectors of the power cable.

  • Page 134: Ec Declaration Of Conformity

    Test item Test description Value specified in standard EN61000-4-16 Low-frequency noise is applied to power lines and • AC power Immunity to conducted, common mode signal lines. 1.5 k to 15 kHz: 1 to 10 V, 20 dB/Dec. disturbances 15 k to 150 kHz: 10 V •...

  • Page 135: Appendix 3 Checklist For Manufacturer

    Appendix 3 Checklist for Manufacturer The specifications in the following list must be available at least for the initial commissioning. They are dependent on the application, whose requirement must be checked by the manufacturer/installer. This checklist should be retained/stored with the machine documentation so that you can use it as a reference for periodical tests.

  • Page 136: Appendix 4 Module Labels

    Appendix 4 Module Labels The functions of a safety extension module can be set using module labels. Module labels A module label name consists of the following elements: "Module name"_"Number of modules"."Data type""Label name" "Module name"_"Number of modules"."Data type""Label name"_D FX5_SF_MU4T5_1.bModuleREADY_D ■Module name It indicates a module name.
  • Page 137 Module labels of the buffer memory A module label name of the buffer memory consists of the following elements. "Module name"_"Number of modules"."Construction name"["(construction number)"]."Data type""Label name" "Module name"_"Number of modules"."Construction name"_D["(construction number)"]."Data type""Label name"_D FX5_SF_MU4T5_1.stnMonitor_D[0].zReserveArea00121_D ■Module name It indicates a module name. ■Number of modules It indicates the number of modules.

  • Page 138: Appendix 5 Buffer Memory

    Appendix 5 Buffer Memory List of buffer memory This section lists the buffer memory of a safety extension module. For details on the buffer memory, refer to the following section. Page 139 Details of buffer memory addresses The buffer memory areas of a safety extension module are classified into the data types in the following table. Data type Description Monitor data...
  • Page 139 Address Address Name Data type Auto-refresh (decimal) (hexadecimal) 1st Module Off delay time Monitor    121 to 139 79 to 8B System area  2nd Module Input signal Monitor  2nd Module Output signal Monitor   142 to 143 8E to 8F System area 2nd Module Input terminal error...
  • Page 140 Error history (Un\G700 to Un\G859) : With refresh setting, : Without refresh setting Address Address Name Data type Auto-refresh (decimal) (hexadecimal)  Error history 1 Error code Monitor  Error time: First two digits of the year/ Monitor Last two digits of the year ...

  • Page 141: Details Of Buffer Memory Addresses

    Details of buffer memory addresses This section shows the details of the buffer memory in a safety extension module. Latest error code The latest error code detected in a safety extension module is stored. For details, refer to the following section. Page 123 List of Error Codes ■Buffer memory address The buffer memory address of this area is as follows.
  • Page 142 Input signals The status of a safety extension module can be checked in the buffer memory. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address Input signals ■List of input signals Buffer memory Description Module READY Module Safety READY...
  • Page 143 Input signals The information of the input terminals of a safety module is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Input signal 2nd Module Input signal 3rd Module Input signal ■List of input signals FX5-SF-MU4T5 Input terminal of FX5-SF-...
  • Page 144 Output signals and module status The information on the output terminals of a module and the statuses of each function are stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Output signal and Module state 2nd Module Output signal 3rd Module Output signal ■Output signals and statuses of each function...
  • Page 145 Output signal and internal error Error information of the whole system is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Output signal and Internal error ■List of output signals and internal errors Output status or input error Operation Output signals Q2/3...
  • Page 146 Input terminal errors The input terminal status is stored. A value to be stored is as follows. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Input terminal error 2nd Module Input terminal error 3rd Module Input terminal error ■List of input terminal errors FX5-SF-MU4T5...
  • Page 147 Error code 2 The code of an error occurred in a module is stored. For error codes to be stored, refer to the following section. Page 123 List of Error Codes ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Error code 2...
  • Page 148 X0 state The connection information of an X0 terminal is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module X0 terminal state 2nd module X0 terminal state 3rd module X0 terminal state ■Status of an X0 terminal Name Description...
  • Page 149 Module name identifier A module name identifier is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Module name identifier 2nd Module Module name identifier 3rd Module Module name identifier ■Module name identifier Name Description...
  • Page 150 Upper rotary switch startup state The information of the rotary switches that have been set at startup is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Upper Rotary Switch startup state 2nd Module Upper Rotary Switch startup state 3rd Module Upper Rotary Switch startup state ■Startup state...
  • Page 151 X1 startup state The connection information of the X1 terminal at startup is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module X1 terminal startup state 2nd Module X1 terminal startup state 3rd Module X1 terminal startup state ■Status of an X1 terminal FX5-SF-MU4T5...
  • Page 152 Off delay time For the models which can set an off delay, the value indicating the settable time unit is stored. ■Buffer memory address The buffer memory address of this area is as follows. Buffer memory name Address 1st Module Off delay time 2nd Module Off delay time 3rd Module Off delay time ■Off delay time...

  • Page 153: Appendix 6 How To Use Melsec Iq-F Series Safety Extension Module Configuration Guide

    Appendix 6 How to Use MELSEC iQ-F Series Safety Extension Module Configuration Guide MELSEC iQ-F Series Safety Extension Module Configuration Guide is a tool for checking methods, settings and electric wiring to install a safety extension module safely. The features of the configuration guide are as follows: •...

  • Page 154: Procedure To Use

    Procedure to use The following shows the procedure for using MELSEC iQ-F Series Safety Extension Module Configuration Guide. Download Installation Decompress the downloaded MELSEC iQ-F Series Safety Extension Module Configuration Guide and store to a local folder. (Save destination example: C:\) Creating configurations For the operation method, refer to the following: Page 160 Operation...

  • Page 155: Screen Configuration

    Screen configuration The following explains the screen configuration when starting MELSEC iQ-F Series Safety Extension Module Configuration Guide. Window (1) Toolbar (2) Menu (3) Module configuration area APPX Appendix 6 How to Use MELSEC iQ-F Series Safety Extension Module Configuration Guide...
  • Page 156 Toolbar The following shows the screen configuration of the toolbar. Window Displayed items Item Description Open To open saved data. Save To save set data. Clear configuration To delete the open configuration. Configuration To check and print the set configuration. For the detail screen, refer to the following: Page 155 Configuration screen General input settings...
  • Page 157 Configuration screen The following explains the configuration screen of MELSEC iQ-F Series Safety Extension Module Configuration Guide. Window Click the (Configuration) on the toolbar. Displayed items Item Description Project To enter a project name. Notes To enter notes. [Print] button To display the print screen of a browser.
  • Page 158 Wiring screen The following explains the wiring screen of MELSEC iQ-F Series Safety Extension Module Configuration Guide. Window Click the (Wiring) on the toolbar. Displayed items Item Details Project To enter a project name. Notes To enter notes. [ - ] button To zoom out the display.
  • Page 159 Menu The following explains the screen configuration of the menu. Window Displayed items Item Description Input Devices To display the list of input or output devices which can be connected to a safety extension module. The device connection destination selection screen is displayed by clicking each device. Output Devices Safety Extension Modules To place a selected safety extension module to the module configuration area.
  • Page 160 Module configuration area The following explains the screen configuration of the module configuration area. Window Displayed items Item Details Select To temporarily place a device may be connected to a safety extension module. The input or output devices whose "Select" is selected in the device connection destination selection screen are displayed.
  • Page 161 Device connection destination selection screen When clicking a device on the menu or in the module configuration area, the connection destination selection screen is displayed as shown below. Window ■When clicking a device on the menu ■When clicking a device in the module configuration area Displayed items Item Description...

  • Page 162: Operation

    Operation The following explains the basic operation of MELSEC iQ-F Series Safety Extension Module Configuration Guide. Set the following configurations. Safety extension module Program number (rotary switch setting) FX5-SF-MU4T5 FUNCTION rotary switch: 2 FX5-SF-8DI4 INPUT A rotary switch: 3 INPUT B rotary switch: 6 Adding a safety extension module to the module configuration area The following shows the procedure for adding a safety extension module to the module configuration area.
  • Page 163 Connecting an input device to input terminals of the safety extension module The following shows the procedure for connecting an input device to a safety extension module displayed in the module configuration area. Operating procedure Click "Input Devices" on the menu and select a device from the list.
  • Page 164 Editing a device connected to the safety extension module The following shows the procedure for changing the placement of a device connected to the safety extension module and removing the device from the module. ■When changing a device placement Click a device to change a placement in the module configuration area.
  • Page 165 Printing a module configuration The following shows the procedure for printing a module configuration. Operating procedure Click the (Configuration) on the toolbar. The configuration screen is displayed. Click the [Print] button. The print screen of the browser is displayed. Click the [Print] button. Setting a restart interlock and EDM The following shows the procedure for setting a restart interlock and EDM.
  • Page 166 Printing wiring diagrams The following shows the procedure for displaying and printing the wiring diagram of the created module diagram. Operating procedure Click the (Wiring) on the toolbar. Wiring diagrams are displayed. Click the [Print] button. The print screen of the browser is displayed. Click the [Print] button.

  • Page 167: Troubleshooting

    Troubleshooting The following shows the corrective actions when MELSEC iQ-F Series Safety Extension Module Configuration Guide does not operate normally. When the configuration guide does not start normally on Internet Explorer 11 (1) Perform the following procedure when MELSEC iQ-F Series Safety Extension Module Configuration Guide does not start normally on Internet Explorer 11.
  • Page 168 When the configuration guide does not start normally on Internet Explorer 11 (2) Perform the following operation when the activated MELSEC iQ-F Series Safety Extension Module Configuration Guide is not displayed properly on Internet Explorer 11. Click the (Tools) of Internet Explorer 11. Select [Compatibility View settings] from the displayed menu.
  • Page 169 MEMO APPX Appendix 6 How to Use MELSEC iQ-F Series Safety Extension Module Configuration Guide...

  • Page 170: Index

    INDEX ...79 Retriggering of the Delayed OSSDs ......72 AND Function .
  • Page 171 MEMO...

  • Page 172: Revisions

    REVISIONS *The manual number is given on the bottom left of the back cover. Revision date *Manual number Description October 2019 SH-082078ENG-A First edition Japanese manual number: SH-082077-A This manual confers no industrial property rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 173: Warranty

    WARRANTY Please confirm the following product warranty details before using this product. Gratis Warranty Term and Gratis Warranty 2. Onerous repair term after discontinuation of production Range If any faults or defects (hereinafter "Failure") found to Mitsubishi shall accept onerous product repairs for be the responsibility of Mitsubishi occurs during use of seven (7) years after production of the product is the product within the gratis warranty term, the...

  • Page 174: Trademarks

    TRADEMARKS The company names, system names and product names mentioned in this manual are either registered trademarks or trademarks of their respective companies.   In some cases, trademark symbols such as are not specified in the manual.
  • Page 176 SICK AG Tel. +49 7681 202-0 www.sick.com Manual number: SH(NA)-082078ENG-A(1910) MODEL: FX5-U-SF-E MODEL CODE: 09R576 HEAD OFFICE : TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS : 1-14 , YADA-MINAMI 5-CHOME , HIGASHI-KU, NAGOYA , JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.

This manual is also suitable for:

Mitsubishi electric melsec iq-f fx5Mitsubishi electric melsec iq-f fx5-sf-mu4t5Mitsubishi electric melsec iq-f fx5-sf-8di4

Table of Contents
