2' X 2
On the 2' long model the sides have
no vertical side bar 'D066'. Because of
Part No
mm
Quantity
this the sides have little substance and
D1045
657
2
you will find it easier to skip this sec-
D1046
654
2
tion '1' until you have built the front
D103
1787
2
(section 2) and rear (section 3). The
sides can then be built in situ during section '4' where the
gutters 'D1045' and cills 'D1046' will allow the front and rear
to connect.
6'
X 2
8'
X 2
10'
X 2
12'
X 2
8
D070
4'
X 2
M6-10mm
M6-15mm
D071
D042
M6-10mm
M6-15mm
D043
D014
M6-10mm
M6-15mm
D021
D015
M6-10mm
M6-15mm
D022
D016
M6-10mm
M6-15mm
D023
4' X 2
Part No
mm
Quantity
D070
1277
2
D071
1274
2
D066
1676
2
D103
1787
2
D174
2
2
4
M6-NUT
6
Rubber
1000
7
6' X 2
Part No
mm
Quantity
D042
1897
2
D043
1894
2
D066
1676
4
D103
1787
4
D174
4
4
8
M6-NUT
12
Rubber
1000
14
8' X 2
Part No
mm
Quantity
D014
2517
2
D021
2514
2
D066
1676
6
D103
1787
4
D174
4
6
10
M6-NUT
16
Rubber
1000
21
10' X 2
Part No
mm
Quantity
D015
3137
2
D022
3134
2
D066
1676
8
D103
1787
4
D174
8
8
12
M6-NUT
20
Rubber
1000
27
12' X 2
Part No
mm
Quantity
D016
3757
2
D023
3754
2
D066
1676
10
D103
1787
4
D174
8
10
14
M6-NUT
24
Rubber
1000
34
