NOMINAL SIZE
A (mm)
10 x 6
10 x 8
3210
10 x 10
10 x 12
NOMINAL SIZE
B (mm)
1990
2610
3230
10ft extension
12ft extension
3850
A (mm)
6ft extension
8ft extension
-
B (mm)
1860
2480
3100
3720

Advertisement

loading
Need help?

Need help?

Do you have a question about the Rosette DWARF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Robinsons Rosette DWARF

Summary of Contents for Robinsons Rosette DWARF

  • Page 1 NOMINAL SIZE NOMINAL SIZE A (mm) B (mm) A (mm) B (mm) 10 x 6 1990 6ft extension 1860 10 x 8 2610 8ft extension 2480 3210 10 x 10 3230 10ft extension 3100 12ft extension 10 x 12 3850 3720...
  • Page 2 Thank you for purchasing your new Robinsons greenhouse. We recommend you familiarise yourself with the instructions and read all safety information before you commence assembly. This instruction manual is also available online at www.robinsonsgreenhouses.co.uk in our technical help section should you need to reprint it. Should you require any additional advice you can always call us on 01782 385409.
  • Page 3 They attach to the building during the glazing process (8) like a piece of glass with a black LOUVRE separator above and below them. Robinsons integral cantilever staging and shelving attaches to the inside of the greenhouse OPTIONAL frame using either square head bolts (insert four into each side glazing bar ’D609’ during con- SHELVING struction of the sides (1)) or rectangular ‘crop head’...
  • Page 4 Section Section Part Section Size Part Section Size (mm) (mm) D043 1894 D111 D021 2514 D022 3134 D854L 1744 D023 3754 D042 1897 D854R D014 2517 1000 RUBBER (1m) D015 3137 D016 3757 D174 D604 1316 D609 1160 D044 1897 D001 2517 1000...
  • Page 5 Section Part Section Size Section Part Section Size (mm) (mm) D618 1144 D090 + D658 1314 D347 lock = 1824 D301 D659 1610 D660 D661 1906 D092 + D662 D156 strike = 1824 D303 D870 D876 1152 D610 1160 D620 1144 D093 1824...
  • Page 7 Feed glazing rubber into each glazing bar and PARTITION trim to length. Notice that some channels are ONLY only used on a partition. Applying a lubricant to REFER TO SEPARATE the aluminium channels will speed up insertion. MANUAL PARTITION ONLY REFER TO SEPARATE MANUAL...
  • Page 8 6 X 2 DWARF Part No Quantity D042 1897 D043 1894 D042 D609 1160 D604 1316 D174 10mm 15mm D043 Rubber 1000 8 X 2 DWARF Part No Quantity D014 2517 D021 2514 D014 D609 1160 D604 1316 D174 10mm 15mm D021 Rubber...
  • Page 9 D604 10mm D609 TRANSIT BOLT ON 15mm DIAGONALS D609 D604 15mm...
  • Page 10 Part No Quantity Part No Quantity D111 D600 1270 D608 1160 D174 D626 1497 D227 D653 1270 D657 1314 M6X10 D669L 1004 M6X15 D669R 1004 M6NUT D670 2210 D854L 1744 D854R 1744 10mm D653 D854L 10mm D854R 10mm 10mm D657 D657 D608 D670...
  • Page 11 D854L D653 D854R D854L D111 D854L D670 D608 D626 D608 D670 D670 D626 D174 D669L D600 D669L...
  • Page 12 Part No Quantity Part No Quantity D038A 3226 D111 D109 3140 D174 D608 1160 D227 D626 1497 D655 1906 M6X10 D656 1610 M6X15 D657 1314 D854L 1744 M6NUT D854R 1744 10mm D854L 10mm D854R 10mm D655 10mm D109 D657 D657 D656 D608 D656...
  • Page 13 D854L D656 D854R D854L D111 D655 D854L D109 D608 D626 D608 D626 D656 D174 D038A D038A...
  • Page 14 EQUAL...
  • Page 15 6’ 8’ 10’ 12’ Part No Quantity Part No Quantity Part No mm Quantity Part No mm Quantity D044 1897 D001 2517 D002 3137 D003 3757 D065 1744 D065 1744 D065 1744 D065 1744 D126 D126 D126 D126 D128 1015 D128 1015 D128...
  • Page 16 Part No mm Quantity Part No mm Quantity D220 D866 PLUS SCREW D863L D205 D863R BOLM6X11 SYNUTM6 D862 D1208 8 X 12 S/T 1 of - FS6017 610 x 610 8 x 19 S/T pane FS6018 D863R D863R D866 D863L D866 D1208 1 of -...
  • Page 17 D862 D863L D862 FLIP VIEW D119...
  • Page 18 Part No mm Quantity Part No mm Quantity D079 PLUS BOLM6X11 FLUFF D114 BOLM6X15 SYBOLM6 X11CROP SYNUTM6 D114 D079 D114 FLIP VIEW...
  • Page 19 D1208 GLASS D1216 GLASS D1216 GLASS...
  • Page 20 Part No mm Q Part No mm Q D232 1824 1 D094 D233 D911 D090 + D347 lock = D301 D911 555 x 812 1824 1 555 x 812 P053 pane D092 + D156 strike = pane D303 1824 1 D225 1824 1 D093...
  • Page 21 D911 555 x 812 pane D912 D232 555 x 922 pane D912 555 x 922 pane D307 D225 D097 D225 D840B P053...
  • Page 22 D667 D667 PART Section Size (mm) D660 D660 D618 1144 D666 D658 1314 D662 D659 1610 D660 D661 1906 D662 D870 D876 1152 D663 D663 D614 D836 D836 D614 D610 1160 D610 D658 D814 D814 D658 D610 D620 1144 D814 1883 D871 D877...
  • Page 23 ROOF PANES OVERLAP S S S S PART Size (mm) 8’ 10’ 12’ D1216 610 X 1162 22 26 D1208 610 X 610 D625 N 305 X 1162 D911 555 X 812 D912 555 X 922 D902 ANGLE D901 ANGLE D907 ANGLE D622...
  • Page 24 D220 D220...
  • Page 25 D862 D079...
  • Page 26 Part No Part No D163 D865 1210 D150 D845 2510 D086 BOLM6X15 SYNUTM6 2510 D085 D845 D845 D836 D814 D163 D845 D670...
  • Page 27 N/A 7 D150 D086 D085 D865 N/A 4 D671 D865 D845...
  • Page 28 Part No D861 D088 D088 D861 D861 D088...
  • Page 29 Part No Quantity FS6018 D312 D204L O4mm D204R through FS6018 metal only FS6018 D204R D312 Part No N/A 3 D671 D223/B D671 D660 D662 D667 D662 D660 D662 D622 D622 NOTCH DOWN D666 D667 D223...
  • Page 30 O7mm...
  • Page 31 Part No Quantity D168L D168R (handle) D165 D166 FS6013 D166 D166 D168L D168R D165 D165 INTERNAL VIEW D729TG - 100 x 525 panes x 6 PINCH ALL GLASS RETAINERS BEFORE GLAZING D165...
  • Page 32 3 slat Example: 2x 4’ shelves ‘ST0304’ = 8’ run 10mm crop D2013 15mm D608 10mm 10mm D609 D608 D2014 10mm crop D2002 =1240mm D2002 =1240mm D2014 D2021 D2003 =1860mm...
  • Page 33 7 slat Example: 2x 4’ staging ‘ST0704’ = 8’ run D608 D2045 D2043 D609 D608 10mm D2044 crop 10mm crop 10mm 10mm 10mm D2046 D2046 D2047 D2043 D2044 D2045 D2042 D2042 D2042 D2002 =1240mm 10mm 10mm D2002 FINISH =1240mm START D2003 =1860mm D2002...
  • Page 34 10 slat Example: 2x 4’ staging ‘ST01004’ = 8’ run D608 D174 D174 D608 D2051 D2043 D2045 D609 D2044 D2052 10mm crop 10mm crop 10mm D2049 10mm D2043 10mm D2048 D2048 D2045 D2044 D2050 D2050 D2050 D2002 =1240mm 10mm 10mm D2002 =1240mm START...
  • Page 35 D214 D203 D201 D119 D119 D208 D211 D202 D608 D841 D119 D211 D608 D206 D207 D608...
  • Page 36 START ROCRE W/G FINISH ROFIN W/G ROFIN W/G D119 START FINISH EQUAL EQUAL...
  • Page 40 We wish you all the best with your new greenhouse, and we look forward to seeing your photos in the near future! THIS GREENHOUSE BOX WAS PACKED BY: DATE:___________________ ________________________________________________________________________________ www.robinsonsgreenhouses.co.uk To contact Robinsons Customer Services email us at sales@robinsonsgreenhouses.co.uk or call us on 01782 385 409. Our address is Robinsons Greenhouses, Unit 19 Blythe Park, Cresswell, Stoke-on-Trent, Staffordshire, ST11 9RD...
