  • Page 1 NOMINAL SIZE NOMINAL SIZE A (mm) B (mm) A (mm) B (mm) 6ft extension 14 x 8 2610 1860 8ft extension 14 x 10 3230 2480 4450 14 x 12 3850 10ft extension 3100 12ft extension 3720...
  • Page 2 Thank you for purchasing your new Robinsons greenhouse. We recommend you familiarise yourself with the instructions and read all safety information before you commence assembly. This instruction manual is also available online at www.robinsonsgreenhouses.co.uk in our technical help section should you need to reprint it. Should you require any additional advice you can always call us on 01782 385409.
  • Page 3 OPTIONAL above and below them. LOUVRE Robinsons integral cantilever staging and shelving attaches to the inside of the greenhouse frame using either square head bolts (insert four into each side glazing bar ’D609’ during construction of the sides OPTIONAL (1)) or rectangular ‘crop head’ bolts which can be fitted retrospectively (both sets of bolts accompany the SHELVING shelving/staging).
  • Page 4 Section Section Part Section Size Part Section Size (mm) (mm) D021 2514 D626 1497 D022 3134 D111 D023 3754 D014 2517 D741L 2431 D015 3137 D742R D016 3757 RUBBER 1000 D604 1316 D174 D609 1160 D001 2517 1000 D002 3137 RUBBER (1m) 12 14 17...
  • Page 5 Section Part Section Size Section Part Section Size (mm) (mm) D618 1144 D090 + D658 1314 D347 lock = 1824 D301 D659 1610 D661 1906 D662 D092 + D735 2210 D156 strike = 1824 D303 D754 D815 1830 D870 D610 1160 D093 1824...
  • Page 7 Feed glazing rubber into each glazing bar and PARTITION trim to length. Notice that some channels are ONLY REFER TO only used on a partition. Applying a lubricant to SEPARATE MANUAL the aluminium channels will speed up insertion. PARTITION ONLY REFER TO SEPARATE MANUAL...
  • Page 8 8 X 2 DWARF Part No Quantity D014 2517 D021 2514 D014 D609 1160 D604 1316 D174 10mm 15mm D021 Rubber 1000 10 X 2 DWARF Part No Quantity D015 3137 D022 3134 D015 D609 1160 D604 1316 D174 10mm 15mm D022 Rubber...
  • Page 9 D604 10mm D609 TRANSIT BOLT ON 15mm DIAGONALS D609 D604 15mm...
  • Page 10 Part No Quantity Part No Quantity D110 1585 D741L 2431 D110R 1585 D741R 2431 D600 1270 D111 D608 1160 D174 D626 1497 D227 D653 1270 D656 1610 M6X10 D657 1314 M6X15 D675 2506 D723 1624 M6NUT D724 1624 10mm D653 D741L 10mm D742R...
  • Page 11 D741L D653 D741L D742R D111 D741L D675 D110 D608 D626 D608 D626 D675 D656 D174 D723 D600 D723...
  • Page 12 Part No Quantity Part No Quantity D608 1160 D111 D626 1497 D174 D655 1906 D227 D656 1610 D657 1314 M6X10 D670 2210 M6X15 D740 4466 D741L 2431 M6NUT D742R 2431 D743 4380 10mm D741L 10mm D670 D742R 10mm 10mm D743 D656 D608 D626...
  • Page 13 D741L D741L D742R D655 D670 D111 D741L D743 D608 D626 D608 D626 D656 D174 D740 D740...
  • Page 14 EQUAL...
  • Page 15 Part No Quantity Part No Quantity Part No mm Quantity 8’ 10’ 12’ D001 2517 D002 3137 D003 3757 D737 2427 D737 2427 D737 2427 D918 3130 D113 2510 D034 3750 D126 D126 D126 D128 1015 D128 1015 D128 1015 RUBBER RUBBER 1000...
  • Page 16 Part No mm Quantity Part No mm Quantity D220 D866 PLUS FS6060 SCREW D205 D863L D863R BOLM6X11 SYNUTM6 D862 D1208 8 X 12 S/T 1 of - FS6017 610 x 610 8 x 19 S/T pane FS6018 D863R D863R D866 D863L D866 D1208...
  • Page 17 D862 D863L D862 FLIP VIEW D119...
  • Page 18 Part No mm Quantity Part No mm Quantity D079 PLUS BOLM6X11 FLUFF D114 BOLM6X15 SYBOLM6 X11CROP SYNUTM6 D114 D079 D114 FLIP VIEW...
  • Page 19 D1208 GLASS D889 GLASS D889 GLASS...
  • Page 20 Part No mm Q Part No mm Q D232 1824 1 D094 D233 D911 D090 + D347 lock = D301 D911 555 x 812 1824 1 P053 555 x 812 pane D092 + D156 strike = pane D303 1824 1 D225 1824 1 D093...
  • Page 21 D911 555 x 812 pane D912 D232 555 x 922 pane D912 555 x 922 pane D307 D225 D097 D225 D840B P053...
  • Page 22 D666 D666 PART Section Size (mm) D662 D662 D618 1144 D755 D658 1314 D754 D659 1610 D661 1906 D662 D663 D664 D836 D836 D664 D663 D735 2210 D658 D659 D814 D814 D659 D658 D754 D815 1830 D614 D614 D870 D610 D610 D610 1160...
  • Page 23 ROOF PANES OVERLAP S S S S PART Size (mm) 8’ 10’ 12’ D1216 610 X 1162 16 18 D889 R 610 X 1855 D1208 610 X 610 D625 N 305 X 1162 D911 555 X 812 D912 555 X 922 D890 ANGLE D898...
  • Page 24 D220 D220...
  • Page 25 D862 D079...
  • Page 26 Part No Part No D163 D865 1210 D150 D845 2510 D086 BOLM6X15 SYNUTM6 2510 D085 D845 D845 D675 D836 D814 D163 D845 D675...
  • Page 27 N/A 7 D150 D086 D085 D865 N/A 4 D733 D865 D845...
  • Page 28 Part No D861 D088 D088 D861 D861 D088...
  • Page 29 Part No Quantity FS6018 D312 D204L O4mm D204R through FS6018 metal only FS6018 D204R D312 Part No N/A 3 D733 D223/B D733 D662 D754 D666 D755 D754 D662 D890 D890 NOTCH NOTCH DOWN DOWN D755 D666 D223...
  • Page 30 O7mm...
  • Page 31 Part No Quantity D168L D168R (handle) D165 D166 FS6013 D166 D166 D168L D168R D165 D165 INTERNAL VIEW D729TG - 100 x 525 panes x 6 PINCH ALL GLASS RETAINERS BEFORE GLAZING D165...
  • Page 32 3 slat Example: 2x 4’ shelves ‘ST0304’ = 8’ run 10mm crop D2013 D608 15mm 10mm 10mm D609 D608 D2014 10mm crop D2002 =1240mm D2002 =1240mm D2014 D2021 D2003 =1860mm...
  • Page 33 7 slat Example: 2x 4’ staging ‘ST0704’ = 8’ run D608 D2045 D2043 D609 D608 10mm D2044 crop 10mm crop 10mm 10mm 10mm D2046 D2046 D2047 D2043 D2045 D2044 D2042 D2042 D2042 D2002 =1240mm 10mm 10mm D2002 =1240mm FINISH START D2003 =1860mm D2002...
  • Page 34 10 slat Example: 2x 4’ staging ‘ST01004’ = 8’ run D608 D608 D2043 D2045 D609 D2044 10mm crop 10mm crop 10mm D2049 10mm D2043 10mm D2048 D2048 D2045 D2044 D2050 D2050 D2050 D2002 =1240mm 10mm 10mm D2002 =1240mm START FINISH D174 SUPPORT BRACKET ON EACH GABLE D2003...
  • Page 35 D214 D203 D201 D119 D119 D208 D608 D211 D608 D202 D841 D119 D211 D207 D206 D608...
  • Page 36  End finials need to be pinched onto ridge using ‘DV282’ grub screws.  Depending on your ridge length a half cresting may need to be cut or/ and some spacer bar ‘DV281’ cut into two equal sections.  Each finial and cresting piece needs to be siliconed ‘D119’ into place. D119 DV281 DV282...
