Page 3
Application ® ELEKTRA SelfTec DW / DW F heating cables have been designed to protect water pipes and pipelines from freezing. The cable can be installed: • inside pipes, • outside pipes, under the layer of thermal insulation. Placing the heating cables inside pipes can be performed in pipelines already in operation.
Page 4
ELEKTRA SelfTec DW/DWF ® Construction of the ® ELEKTRA SelfTec DW heating cable tin-coated multi-wire copper conductor self-regulating conductive core modified polyolefin insulation PET covered aluminum foil shield tinned copper braiding modified polyolefin first outer sheath LDPE second outer sheath certified...
Page 5
Construction of the ® ELEKTRA SelfTec DW F heating cable tin-coated multi-wire copper conductor self-regulating conductive core modified polyolefin insulation PET covered aluminum foil shield tinned copper braiding fluoropolymer outer sheath suitable for drinking water applications Characteristics Power output of self-regulating heating cables...
Page 6
(installation manuals included in the sets). ® Due to their properties, ELEKTRA SelfTec DW / DW F can touch or cross and they are not prone to local overheating. A significant advantage is the possibility to cut the cables into segments of required length.
Page 7
® 7 x 10 mm (ELEKTRA SelfTec DW) » ® 6 x 9 mm (ELEKTRA SelfTec DW F) • min. installation temperature: -25°C • max. operating temperature: +65°C • max. exposure temperature: +65°C • min. cable bending radius: 3.5 D •...
Page 8
DW F 16 min. switch-on type C circuit breaker tempera- ture 10 A 16 A 10 A 16 A max. circuit length [m] -20°C -15°C 0°C +10°C +10°C in water 0°C in ice water ® SelfTec DW / DW F...
Materials and tools required for the installation of heating cables inside pipes ® • ELEKTRA SelfTec DW / DW F self-regulating heating cable • HL-T plumbing lead-through set for / ", / ", 1" pipes • EC-PRO and ECM25-PRO joint sets (with KF 0404 PRO junction box) •...
Page 10
(with internal thread 1”), on which the lead-through will be mounted. ® The relevant self-regulating ELEKTRA SelfTec DW / DW F heating cable should be cut to match the pipeline’s length (the cable of the same length or shorter).
Page 11
plumbing HL-T lead-through plumbing tee joint 2. Entering the cable into a line-shaped pipeline (the so called ”tapping”): • Lead the cable through the elements of the H-LT lead-through and then enter into the pipeline through the tee joint.
Page 12
ELEKTRA SelfTec DW/DWF ® • When the cable has been entered, mount the tee joint on the pipeline. • Then mount the HL-T lead-through. Note: When leading the cable is through the H-LT lead-through, moisten it with water to make it easier for the cable to slide...
Page 13
Installation of heating cables on the pipe • The relevant self-regulating ELEKTRA ® SelfTec DW / DW F heating cable should be cut to match the pipeline’s length (the cable should be longer and the surplus is for the cold tail connection).
Page 14
ELEKTRA SelfTec DW/DWF ® • For plastic pipelines, fix additionally self- adhesive aluminum foil along the heating cable to improve the temperature distribution on the surface of the pipeline. Additionally, the aluminum foil will secure the cable from being pulled into the thermal insulation.
Page 15
The controllers below will optimally serve this purpose: ELEKTRA UTR60-PRO controller for on support bracket mounting, load 16 A, the maximum total power of directly connected self-regulating heating cables is 1200 W.
Page 16
ELEKTRA SelfTec DW/DWF ® the range of -40°C up to +120°C. Adjustable hysteresis allows to define precision of temperature measurements. ELEKTRA ETV-1991 controller for DIN bus mounting, load 16 A, recommended total power of directly connected self-regulating heating cables is 1200 W.
Sensor and heating cable mounted on the pipeline Final Check After the heating cable has been installed in the gutter or in case of pipe installation, after thermal insulation has been laid, perform the measurements of the heating cable insulation's resistance, and test-run the heating circuits to assess the correctness and safety of the system's operation.
Page 18
ELEKTRA SelfTec DW/DWF ® For heating systems executed on: • pipelines or steel tanks, • as well as those equipped with insulation made of processed metal perform the measurements of resistance of the layer (layer tightness) between: • pipeline, tank or insulation layer of processed metal and •...
Warranty ELEKTRA grants a 2 year-long warranty (from the date of purchase) for the ELEKTRA ® SelfTec DW / DW F heating cables. Warranty conditions 1. Warranty claims require: a. that the heating system has been executed in full accordance with the Installation Instructions herein, b.
Page 20
ELEKTRA SelfTec DW/DWF ® Note: The Warranty claims must be registered with the proof of purchase, in the place of purchase or the offices of ELEKTRA company.
Page 25
Zastosowanie Samoregulujące przewody grzejne ELEKTRA ® SelfTec DW / DW F służą do zabezpieczania przed zamarzaniem rur i rurociągów z wodą. Przewód można umieścić: • wewnątrz rury • na zewnątrz rury pod warstwą izolacji termicznej Umieszczenie przewodu grzejnego wewnątrz rury może być stosowane w rurociągach będących już...
Page 26
ELEKTRA SelfTec DW/DWF ® Budowa przewodu grzejnego ELEKTRA ® SelfTec DW wielodrutowa żyła z ocynowanych drutów miedzianych samoregulujący polimer przewodzący izolacja z modyfikowanej poliolefiny ekran – folia AL/PET ekran – oplot z ocynowanych drutów miedzianych pierwsza powłoka z modyfikowanej poliolefiny druga powłoka z LDPE...
Page 27
Budowa przewodu grzejnego ELEKTRA ® SelfTec DW F wielodrutowa żyła z ocynowanych drutów miedzianych samoregulujący polimer przewodzący izolacja z modyfikowanej poliolefiny ekran – folia AL/PET ekran – oplot z ocynowanych drutów miedzianych powłoka zewnętrzna z fluoropolimeru dopuszczona do kontaktu z wodą pitną...
Page 28
EC-PRO oraz ECM25-PRO (instrukcje montażu w opakowaniu zestawów). Ze względu na swoje właściwości przewody ® SelfTec DW / DW F mogą się stykać lub krzyżować i nie grozi im miejscowe przegrzanie. Istotną zaletą jest możliwość cięcia przewodu na odcinki o dowolnej długości.
Page 29
® • moc jednostkowa przewodu SelfTec DW F 16: - w temperaturze 10°C na rurze – 16 W/m - w wodzie lodowej – 22 W/m • napięcie zasilania: 230V 50/60 Hz • wymiary zewnętrzne: » ® 7 x 10mm (SelfTec DW) »...
Page 30
DW / DW F 10 DW F 16 min. tempera- zabezpieczenie, typ C tura załączenia 10 A 16 A 10 A 16 A maksymalna długość obwodu [m] -20°C -15°C 0°C +10°C +10°C w wodzie 0°C w wodzie lodowej ® SelfTec DW / DW F...
Page 31
Materiały i narzędzia wymagane do instalacji przewodu grzejnego wewnątrz rury • samoregulujący przewód grzejny ® ELEKTRA SelfTec DW / DW F • zestaw dławików hydraulicznych H-LT do rur 1/2", 3/4", 1" • zestaw przyłączeniowo-zakończeniowy EC-PRO lub ECM25-PRO (z puszką KF 0404 PRO) •...
Page 32
1", należy zastosować trójnik reduk- cyjny z odpowiednim odgałęzieniem (o gwincie wewnętrznym 1") na którym zamocowany zostanie dławik. Należy uciąć odpowiednią ® długość przewodu grzejnego ELEKTRA SelfTec DW / do długości rurociągu (tej samej długości lub nieco krótszy).
Page 33
dławik hydrauliczny H-LT trójnik 2. Wprowadzenie przewodu do rurociągu liniowego (tzw. wcinka): • Przewód należy przeprowadzić przez elementy dławika HL-T, a następnie przez trójnik i wprowadzić do rurociągu...
Page 34
ELEKTRA SelfTec DW/DWF ® • Po wprowadzeniu przewodu należy zamontować trójnik na rurociągu • Następnie należy zmontować dławik HL-T Uwaga: Przeprowadzając przewód przez dławik HL-T należy zwilżyć go wodą, aby zwięk- szyć poślizg na powierzchni powłoki.
Page 35
Montaż przewodu grzejnego na rurze • Docinamy przewód samoregulujący ELEKTRA ® SelfTec DW / DW F odpowiednio do długości rurociągu (przewód grzejny powinien być dłuższy, a nadmiar wykorzystany do instalcji przewodu zasilającego i zakończenia). • Przewód grzejny mocujemy wzdłuż rurociągu w jego dolnej części za pomocą...
Page 36
ELEKTRA SelfTec DW/DWF ® • Dodatkowo na rurociągach z tworzywa sztucznego należy stosować taśmę aluminiową naklejoną wzdłuż przewodu grzejnego w celu poprawy rozkładu temperatury na powierzchni rurociągu. • Po instalacji przewodu grzejnego na rurociąg należy nałożyć izolację termiczną.
Page 37
Do tego celu służą poniższe regulatory temperatury: Regulator ELEKTRA UTR60-PRO do montażu na wsporniku – obciążalność 16 A – maksymalna łączna moc bezpośrednio podłączonych samoregulujących przewodów grzejnych wynosi 1200 W.
Page 38
ELEKTRA SelfTec DW/DWF ® może pracować w temperaturze od -40°C do 120°C. Regulowana histereza pozwala na określenie dokładności pomiaru temperatury. Regulator ELEKTRA ETV-1991 do montażu na szynie DIN – obciążalność 16 A – zalecana łączna moc bezpośrednio podłączonych samoregulujących przewodów grzejnych wynosi 1200 W.
Page 39
Czujnik temperatury i przewód grzejmy zamontowany na rurze Kontrola wykonanej instalacji Po ułożeniu przewodów grzejnych oraz po ułoże- niu izolacji termicznej należy wykonać pomiar rezy- stancji izolacji przewodów grzejnych oraz próbnie uruchomić obwody grzejne w celu określenia pra- widłowości działania oraz bezpieczeństwa eksplo- atacji systemu.
Page 40
ELEKTRA SelfTec DW/DWF ® W przypadku wykonywania instalacji: • na rurociągach lub zbiornikach stalowych, • jak również wyposażonych w izolację z obróbką blacharską należy dokonać pomiaru rezystancji (szczelności) powłoki między • rurociągiem, zbiornikiem lub obróbką blacharską • przewodem ochronnym/ekranem przewodu grzejnego w celu wyeliminowania uszkodzeń...
Gwarancja ELEKTRA udziela 2-letniej gwarancji (licząc od dnia zakupu) na samoregulujące przewody ® grzejne ELEKTRA SelfTec DW / DW F Warunki gwarancji 1. Uznanie reklamacji wymaga: a) wykonania instalacji grzewczej zgodnie z niniejszą instrukcją montażu b) dowodu zakupu przewodu grzejnego 2.
Page 42
ELEKTRA SelfTec DW/DWF ® Uwaga: Reklamacje należy składać wraz z dowodem zakupu w miejscu sprzedaży przewodów grzejnych lub w firmie ELEKTRA.
