Device Programming and Setup

System Installer must adhere to Article 820-40 of the NEC that provides guidelines for proper grounding and

specifies that the cable ground shall be connected to the grounding system of the building, as close to the point

of cable entry as possible.

Each unit is shipped factory tested. Ensure all items are removed from the container prior to discarding any packing

material.

Thoroughly inspect the unit for shipping damage with particular attention to connectors and controls. If there is any sign of

damage to the unit or damaged or loose connectors contact your distributor immediately. Do not put the equipment into

service if there is any indication of defect or damage.

It is highly recommended that quality cables and connectors be used for all video and audio source connections.

1. The unit is designed to be rack mounted in a standard EIA19" rack.

2. The unit comes standard with CVBS inputs. Repeat this step for each video source connection required.

Be sure the connections for each source are consistent with the unit's inputs (IN1...IN12).

3. When connecting to an IP network use an IGMP capable and enabled switch. (It is highly recommended an IT

professional who is familiar with IGMP switches assists in setting up the IGMP Switch).

4. Use a quality 75Ω coaxial cable with "F" connectors from the unit's RF OUT jack to the distribution system

(combiner or reverse splitter) or directly to a television.

5. Connect the included power cord to the unit's POWER plug.

6. Connect the power cord to an appropriately rated AC power outlet.

1. Connect an Ethernet cable directly (no Cross Over cable required) to the Web Management Port on the rear

panel of the encoder or connect the Ethernet cable to an Ethernet switch. Connect an Ethernet Cable to your

PC/Laptop.

2. Modify your PC/Laptop IP address to 192.168.1.11.

3. Enter '192.168.1.9' into your web browser.

4. Enter GUI and make required device changes.

5. Save all changes as required, upload and reboot changes.

6. Verify parameters then end web session.

NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-IPTV-QAM-12C-SD Manual v1.0 Page 6
