Gpio - Logitek mixIT Setup Manual

+ - Gnd
Ana Out 11
mix-IT-12 only
+ -
Ana Out 13
mixIT-12 only
+ - Gnd
Ana Out 15
mix-IT-12 only

GPIO

DB-15 Connector (female jack mounted on chassis)
1. Out-1
2. Out-2
3. Out-3
4. Out-4
5. Out-5
6. Out-6
7. Out-Common 15. Out-8
8. Ground
Inputs grounded to activate. The maximum input is 12 volts. The outputs are opto-isolated
electronic relays. The maximum load is .5 amps at 50 volts.
Logitek mixIT Audio Console System/JET67 Manual
+ -
Ana Out 12
Gnd + -
Ana Out 14
+ -
Ana Out 16
9. +3.3 VDC
10. Out-7
11. In-1
12. In-2
13. In-3
14. In-4
