microphone turns off. (example: to put all microphones in the first mute group, put a 1
in the Mute Group box for each microphone.) To assign the bus to be muted and the GPI
outputs to the Mute Tally, you will configure the Mute Group under Control Settings.
8. To adjust the gain of the mic preamp, enter the value in DB in the IO Gain box. Negative
numbers reduce gain, positive numbers increase it. The valid range is xxx
9. To enable Phantom Power for the input, set Phantom Power to Yes.
10. To send the audio from this input to the audio network so other AES-67 devices can use
it, check Yes for Send to Network. Set Network Latency to Low. The JET67 will stream
this source to the network and announce it to other devices using the surface label that
you entered.
11. Click Upload to JetStream to save your changes.
12. To delete this source, click Delete this local input.
13. To cancel and return to the Local IO page, click Cancel edit changes.
