  • Page 1 Keysight Technologies N3304A Component Level Information...
  • Page 2 Information in this packet applies to the following assemblies: 1. 5064-0106 Control Board 2. 5064-0107 300W Power Board The following is included in this packet: 1. Component Locators 2. Schematics 3. Parts lists with Keysight Technologies, Inc. and manufacturer’s part numbers...
  • Page 3 03 | Keysight | N3304A - Component Level Information NOTE: Magnify to see component reference designators. Keysight N3304A 300W Electronic Load Module 5064-0106 Control Board PC Assembly Component Locator...
  • Page 4 04 | Keysight | N3304A - Component Level Information SECONDARY +5VS CONNECTIONS +15VS +5VS +15VS +5VS +5VS +5VE Module Input Next Module C254 C201 Cable header Connector 0180-4577 GND_OP 0160-7736 NL0160-7798 GND_DS GND_DS 5081-4987 1252-6163 ADCK_12 RESET HS_CK_MS ADAT_12 RESET...
  • Page 5 05 | Keysight | N3304A - Component Level Information +3VS POWER BOARD Cable Header AEE0 I/O80 NOTE: GROUND PIN 126 FOR DUAL MODULE AEE1 5081-4998 I/O81 XCS30XL-4TQ208C AEE2 I/O82 1821-8715 AEE3 +SENSE I/O83 5080-4998 AEE4 DONE I/O84 X_RST AEE5 PROGRAM...
  • Page 6 06 | Keysight | N3304A - Component Level Information +15VS +15VS GND_ABS +5VS R368 0160-7798 0.047 0160-5944 Quad 16 bit DAC 0699-3901 OP275 VMON_EXT 0160-7798 5.11K 5.11K 5.11K GND_16DAC 0699-3964 1826- VOUT +2.5VREF 0699-3964 0699-3964 3000 GND_EXT +15VS MAX6225BCSA 0180-4577...
  • Page 7 07 | Keysight | N3304A - Component Level Information CV RANGE AND SLEW CIRCUIRS CC RANGE AND SLEW CIRCUIRS +5VS +15VS +5VS +15VS GND_ABS GND_ABS C105 C106 GND_CC R120 C120 C121 GND_CV 0160-7798 0160-7798 2.61K 2.61K GND_DS GND_ABS +15VS +5VS...
  • Page 8 08 | Keysight | N3304A - Component Level Information +5VRB Negative Voltage Protect Circuit +5VS CR RANGE, MULTIPLIER AND SLEW CIRCUITS 0699-3819 +5VS RESET +15VS R350 C230 +15VS R322 VMON_INV GND_ABS 0160-7798 GND_ABS +5VS +15VS 0699-3970 21.5K LM393 VMON_INV +2.5VRB...
  • Page 9 09 | Keysight | N3304A - Component Level Information +5VS_AD +15VS +5VS C150 -15ADC R180 0160-7798 2.61K HIGH RANGE 1925 0699-3957 GND_AS_RDBK ADG452BR VANA VDIG GND_AQS 1826- RSW1 BUSY 16AD1_CS 1826-4325 +2.5VREF OP-27 -15VS +15VS 16AD1_R/C CURRENT READBACK CIRCUITS 16AD_BYTE...
  • Page 10 10 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) Reference Designator Keysight P/N Description Manufacturer C1, C164, C184, C21, C254, 0180-4577 CAPACITOR-FIXED 10uF +-20PCT 10V TA TAJB106M010R C62, C72, C79, C81 293D106X0010B2E3...
  • Page 11 11 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer C155, C175 0160-8025 CAP-FXD 820pF +-1pct 50 V CER C0G 08055A821FATA 500R15N821FV2 JOHANSON DIELECTRICS C0805C821F5GAC KEMET ELECTRONICS...
  • Page 12 12 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer C251 0160-7699 CAP-FXD 3300pF +-10pct 50 V CER X7R 06035C332KAT C0603C332K5RAC KEMET ELECTRONICS C1608X7R1H332K GRM188R71H332KA01D MURATA MANUFACTURING...
  • Page 13 13 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer 1902-1544 DIODE-ZNR10V5PCTTO-236(SOT-23)PD-.35W BZX84C10 PHILIPS BZX84C10LT1G ON SEMICONDUCTOR BZX84C10 D2, D7, D8, D10-D13, 1906-0291 DIODE-DUAL 70V 100MA T0-236AA...
  • Page 14 14 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer Q3, Q4, Q6, Q7, Q8 1855-0734 TRANSISTOR MOSFET 2N7002 N-CHAN E-MODE 2N7002-T1-E3 VISHAY 2N7002 FAIRCHILD SEMICONDUCTOR...
  • Page 15 15 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R120, R150, R180, R195, 0699-3957 RESISTOR 2.61K +-1pct .063W TKF CRCW06032K61FKE_ VISHAY R329, R8, R95 TC=0+-200...
  • Page 16 16 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R156, R176 0699-3803 RES-FXD 5.62K +-0.1PCT .125W TC 0+-25 RN732BT_5621B25 MCA1206-25 0, 1% P5 5.62K VISHAY BC COMPONENTS MCA1206-25 0, 1% P5 5.62K...
  • Page 17 17 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R182, R183, R197, R198 0699-2839 RESISTOR 150K +-0.1pct .125W TF TC=0+-25 RN732BT_1503B25 BLU-1206 150K .1% 25PPM...
  • Page 18 18 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R208, R85, R91 0699-3931 RESISTOR 196 +-1pct .063W TKF TC=0+-200 CRCW0603196RFKE_ VISHAY RK73H1JT_1960F 232270461961L YAGEO MCR03___FX1960...
  • Page 19 19 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R322, R323, R7 0699-3978 RESISTOR 21.5K +-1pct .063W TKF CRCW060321K5FKE_ VISHAY RK73H1JT_2152F TC=0+-200 232270462153L YAGEO MCR03___FX2152...
  • Page 20 20 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R356, R357, R368, R369, 0699-3901 RES-FXD 10 +-1PCT .063W TKF TC=0+-200 CRCW060310R0FKE_ VISHAY R376, R385 RK73H1JT_10R0F...
  • Page 21 21 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer R96, R149, R121 0699-2843 RESISTOR 100K +-0.1pct .125W TF TC=0+-25 RN732BT_1003B25 BLU-1206 100K .1% 25PPM RCD COMPONENTS...
  • Page 22 22 | Keysight | N3304A - Component Level Information 5064-0106 Control Board Parts List (Electronic Load Module) (continued) Reference Designator Keysight P/N Description Manufacturer 1826-1862 IC OP AMP LOW-BIAS-H-IMPD DUAL 8-SOIC TL072CD STMICROELECTRONICS TL072CD TEXAS INSTRUMENTS U51, U52 1826-2167 ANALOG MULTIPLEXER 8 CHNL 16-SOIC...
  • Page 23 23 | Keysight | N3304A - Component Level Information NOTE: Magnify to see component reference designators. Keysight N3304A 300W Electronic Load Module 5064-0107 300W Power Board PC Assembly Component Locator...
  • Page 24 24 | Keysight | N3304A - Component Level Information VMON DIFFERENTIAL AMP AND BUFFER STATUS COMPARATOR R241 R242 0_OHM 0_OHM 0699-1503 0699-1503 +5VS +15VS 100PF 0160-5967 0.047 R193 0160-5944 GND_ABS 10K 0.1% -LOCAL_SENSE 1/8W C105 0699-2489 R233 LM339 R102 CELL_PROG R196 0.047...
  • Page 25 25 | Keysight | N3304A - Component Level Information +5VS OV CIRCUIT CV CONTROL CIRCUIT 0.022 0699-2489 -15VS 1/8W 0160-7736 0160-6444 0699-3531 VMON_INV 0.1% 0.047 R181 0160-5944 R127 R268 R138 +15VS 8.25K 51.1K 0.047 0699-3049 0699-3073 0160-5944 0699-3473 0699-3051 GND_ABS...
  • Page 26 26 | Keysight | N3304A - Component Level Information CELL_PROG R291 VOFF CELL_PROG CELL_PROG IRFP140 IRFP140 IRFP140 IRFP140 CELL_PROG 0_OHM 1855-1786 1855-1786 1855-1786 0699-2643 FET_VGS 1855-1786 +15VS_URS +15VS_URS +15VS_URS +15VS_URS 0.047 FET ASSEMBLY 5063-2379 0.047 0160-5944 0160-5944 GND_ABS GND_ABS 8 U4...
  • Page 27 27 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List Reference Designator Keysight P/N Description Manufacturer C1-C8 0160-6103 CAP-FXD 1800pF +-5pct 50 V CER C0G 12065A182JATRA C1206C182J5GAC KEMET ELECTRONICS C3216CH1H182J GRM3195C1H182JD01D MURATA MANUFACTURING C10, C29, C97, C98...
  • Page 28 28 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer 0160-7940 CAP-FXD 0.027uF +-10pct 50 V CER X7R 08055C273KATA C0805C273K5RAC KEMET ELECTRONICS C2012X7RC273K GRM219R71H273KD01D MURATA MANUFACTURING C61, C62 0160-5945 CAP-FXD 0.01uF +-10pct 50 V CER X7R...
  • Page 29 29 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer C92, C93, C95, C96 0180-3975 CAP-FXD 2.2uF +-20PCT 20V TA TAJB225M020 293D225X0020B2E3 VISHAY 49MC225B020M0AS VISHAY BC COMPONENTS ESVB21D225M...
  • Page 30 30 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R10-R17 0699-3828 RES-FXD 21.5 OHM +-1PCT 0.1W TC 0+-100 CRCW080521R5FKE_ VISHAY RK73H2AT__21R5F MCR10___F21R5 ROHM 232273462159L YAGEO MC080521R5-FT RCD COMPONENTS...
  • Page 31 31 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R124, R191, R192, R62 0699-2485 RESISTOR 60K +-0.1pct .125W TF TC=0+-25 RN732BT_6002B25 BLU-1206 60K .1% 25PPM RCD COMPONENTS...
  • Page 32 32 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R158, R182, R86, R87, R88 0699-3045 RESISTOR 5.11K +-1pct .1W TKF TC=0+-100 CRCW08055K11FKE_ VISHAY RK73H2AT_5111F MCR10___F5111 ROHM 232273465112...
  • Page 33 33 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R183-R190 0699-3840 RES-FXD 19.6 OHM +-1PCT 0.1W TC 0+-100 RK73H2AT__19R6F 232273461969 YAGEO MCR10___F19R6 ROHM CRCW080519R6FKE_ VISHAY MC080519R6-FT RCD COMPONENTS 0699-3862 RESISTOR 200K +-1PCT .1W TKF TC=0+-100...
  • Page 34 34 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R208 0699-3040 RESISTOR 3.16K +-1pct .1W TKF TC=0+-100 CRCW08053K16FKE_ VISHAY RK73H2AT_3161F MCR10___F3161 ROHM 232273463162 YAGEO MC08053161-FT RCD COMPONENTS...
  • Page 35 35 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R228 0699-2974 RESISTOR 348 +-1pct .1W TKF TC=0+-100 CRCW0805348RFKE_ VISHAY RK73H2AT_3480F MCR10___F3480 YAGEO 232273463481 ROHM R23, R25 0699-2999 RESISTOR 178K +-1pct .1W TKF TC=0+-100...
  • Page 36 36 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer 0699-2984 RESISTOR 13.3K +-1pct .1W TKF TC=0+-100 CRCW080513K3FKE_ VISHAY RK73H2AT_1332F MCR10___F1332 ROHM 232273461333 YAGEO MC08051332-FT RCD COMPONENTS R260 0699-3075 RESISTOR 147K +-1pct .1W TKF TC=0+-100...
  • Page 37 37 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R274 0699-3698 RESISTOR 10 +-1pct .1W TKF TC=0+-100 CRCW080510R0FKE_ VISHAY RK73H2AT_10R0F MCR10___F10R0 ROHM MC080510R0-FT RCD COMPONENTS R275, R276, R277, R278, R279 0699-3843 RESISTOR 34.8 +-1pct .1W TKF TC=0+-100...
  • Page 38 38 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer R52, R53, R55, R56, 0699-3077 RESISTOR 1M +-1pct .1W TKF TC=0+-100 CRCW08051M00FKE_ VISHAY R58-R61 RK73H2AT_1004F MCR10___F1004 ROHM 232273471005...

  • Page 39: Analog Devices

    39 | Keysight | N3304A - Component Level Information 5064-0107 Power Board 300W Parts List (continued) Reference Designator Keysight P/N Description Manufacturer 1826-2959 IC MULTIPLIER 4-QUAD SINGLE 8 PIN AD633JRZ ANALOG DEVICES 1826-2149 ANALOG SWITCH 4 SPST 16 -P-SOIC DG444DY-E3...
  • Page 40 1 800 375 8100 www.keysight.com/find/channelpartners www.keysight.com/find/contactus Taiwan 0800 047 866 Get the best of both worlds: Keysight’s measurement expertise and product Other AP Countries (65) 6375 8100 (BP-09-23-14) breadth, combined with channel partner convenience. This information is subject to change without notice.
