Operating/assembly instructions
Volleyball posts
Prod. code: 115 8029
Operating/assembly instructions for volleyball posts
Thank you very much for choosing a Sport-Thieme product. We want to make sure
that you can enjoy this product, so here is some important advice for your safety as
well as for the use and maintenance of the equipment.
Please read these instructions carefully before you assemble and
cover
for tensioning
mechanism
1. Operating and assembly instructions
The base posts are set into measured foundations. Measure the foundation in
compliance with the loads and measures as shown in illustration 2. Stable ground is
required for laying the foundations.
The insertion depth into the ground sockets is 35 cm. The foundations for the sockets
should be approx. 80x80x80 cm in undisturbed ground, or approx. 100x100x100 cm
in backfilled, light ground.
Note:
The volleyball posts can also be used for ground sockets (prod. code: 151 5608-2).
Once the base posts are standing securely, push the upper volleyball posts onto the
base posts. You can now lock the posts at the desired height using the grub screws.
When the desired height is set, you can attach the net to the existing eyelets.
use the equipment:
upper volleyball posts
height locking with
grub screw
base posts
Illustration 1: volleyball post
page 1 of 3
Sport-Thieme GmbH
38367 Grasleben / Germany
Tel: +49 (0)5357 181 81
Fax: +49 (0)5357 181 90
cover for tensioning
mechanism
04/2016
