- Page 1 Instructions manual / Position Controller Upgrade your DOGA Hybrid Controller HDC-30i HDC-35i HDC-40i INSTRUCTIONS MANUAL...
- Page 2 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i The tool delivered with this manual may been modified for specific needs. In that case, please give us the tool code number written on our shipping note or the appoximate tool delivery date when you will place an order for a new similar tool or for spare parts.
- Page 3 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i INDEX I. Necessary equipment…………………………………………………………………………………………. .p.4 II. Upgrade process……………………………………………………………………………………………….. p.4...
- Page 4 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i I. Necessary equipment : Computer, USB Cable provided with your HDC-40i, - last version of firmware + software to upgrade it (you can download them at http://www.doga.fr/download2/hybrid_en.php) II. Upgrade process : 1.
- Page 5 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 3. After downloading the ''HDC40i-Upgrade'' archive, unzip it and copy/paste the extracted file directly on your C:\drive...
- Page 6 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 4. Launch the application ''SetupCSSPlatinium_v30118'' (follow the steps of the installation by clicking next and install). 5. Go back and open the ''HDC40i_Flash_Serial'' file. Launch the application ''SDFlash''...
- Page 7 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 6. Go to "File", "Open Project". Browse and select the "F2808SerialFlash.sdp" file.
- Page 8 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 7. Go to "Project", "Settings". 8. On the "Target Tab" browse to find the correct driver : F280xRS232Flash.dll...
- Page 9 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 9. Select the port com you are connected with. 10. Browse and select the "Board File": ccBrd028x.dat...
- Page 10 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 11. Go to the "Programming" tab. NOTE : go in the ''downloads'' file of your system and copy/paste in the ''HDC40i_Flash_Serial'' file on the (C:) repertory the .out file corresponding to the last firmware version mentioned in the necessary equipment.
- Page 11 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 13. Click on "OK". 14. Turn the HDC-40i ON. The LCD display screen will remain blank. 15. On the main window, click on the "Reset" button: 16. Then, click on the ""Flash" button:...
- Page 12 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i 17. After few seconds, you will see in the bottom part of the window that the "verify flash succeeded". 18. Close the "SDFlash" software. 19. Turn off the HDC-40i.
- Page 13 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i PERSONAL NOTE ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________...
- Page 14 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i...
- Page 15 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i...
- Page 16 Instructions manual / Upgrade your DOGA Hybrid Controller HDC-30i, HDC35i, HDC-40i...
