DOGA ParaMon-Pro X V3 User Manual

Process controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User manual
Process Controller
ParaMon-Pro X V3
EN
60513 09/24
www.dogassembly.com

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the ParaMon-Pro X V3 and is the answer not in the manual?

Questions and answers

Related Manuals for DOGA ParaMon-Pro X V3

Summary of Contents for DOGA ParaMon-Pro X V3

  • Page 1 User manual Process Controller ParaMon-Pro X V3 60513 09/24 www.dogassembly.com...

  • Page 2: Table Of Contents

    I/O – Job mode only ..........................43 11.2.1 Output functions for Job mode ........................45 11.3 Log ................................46 11.4 Barcode – without job mode & BM tools with integrated scanner ............48 11.5 Network ..............................50 User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 3 For any questions regarding troubleshooting ....................95 19.5 After sales Returns ........................... 95 19.5.1 Download the after-sales return form ......................95 19.5.2 Send your equipment ..........................96 19.6 On site repair ............................96 19.7 Warranty..............................96 User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 4 22.3 Modbus TCP relay server ........................102 22.4 Job remote control ..........................104 22.5 Connect and setup a BST-LCD in USB ....................105 22.6 Connect and set up a BS-5C via the I/O’s ....................108 User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 5: Remarks About The Manual

    This warning statement indicates a moderate risk that may lead to severe or fatal injuries if not avoided. Update history Ind. Date Description Original - replace 60391 manual ParaMon-Pro X controller for BM screwdrivers 09/24 User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 6: Information

    If this is the case, when ordering a replacement or spare parts, please indicate the controller serial number written on our shipping note or contact DOGA at +33 1 30 66 41 41. In this way, you will be sure to get the required controller and/or spare parts...

  • Page 7: Product Description

    Micro-SD slot (up to 32GB) Multi-Language English, French, German, Spanish, Czech, Italian Information Do NOT use any similar adapter other than the included USB Wi-Fi adapter. There is a possibility of signal interference while operating the equipment User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 8: Dimensions

    Dimensions 1.6.1 Overall dimensions with mount bracket Caution When replacing the VESA bracket, it is essential to use the 4 existing fixing screws. Too long screws may touch and damage the CPU board. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 9: Connections & Side Dimensions

    1.6.2 Connections & side dimensions User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 10: Home

    To view the fastening graph, I/O status in real time Monitor To view software and hardware information System Enter password and log into the Admin mode Login The default password is “0”. Password can be changed in Admin mode. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 11: Administrator Mode

    Remote control of screwdrivers and outputs Remote To access ParaMon-Pro X parameters Setting To view software and hardware information System To browse directories in the internal or external memory File Browser Logs out from Administrator to Operator mode Logout User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 12: Network Configuration

    A. When you need a more extensive and powerful Wi-Fi signal for the BM and Access Point (Option) BMT series cordless tools. B. When you want to connect one or more wired MD(T) series screwdrivers to the ParaMon-Pro X User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 13: Connect Through Internal Ap

    D. Set the SSID, password and band in Wi-Fi settings. The default settings are as follows: Parameter Default Settings SSID paramon Password 12345678 Band 5 GHz Region USA – Modify to Europe Channel selection Automatic User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 14 Information It is essential to set the same Country or Region parameters between the access point and the screw- drivers, as this could lead to connection problems. (Due to different Wi-Fi frequencies used) User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 15: Connection Using External Ap

    C. Select the NETWORK tab on the left. D. Choose DHCP or STATIC in ETHERNET depending on the network configuration. E. Press [Apply]. Information We advise you to use fixed IP addresses for external Access Point configuration. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 16 F. Check the IP address by the DHCP server in the following menu: Home → System → Network. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 17: Bm/Bmt Wi-Fi Setup

    D. Enter the SSID and password: If you are using a USB Wi-Fi adapter, the SSID and password are automatically entered when you press the [Set] button. E. Press the [Save] button to save the modified settings. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 18 The signal strength is only displayed on the Operation page. To go back to the Operation page, press F1 (MODE). You can also check the IP address as shown in the following right image. Press F2 (DISP) and use F3 (DOWN) or F4 (UP) to change page. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 19: Member Tools

    This section describes how to manage member tools. Register Member Tools A. Login as Admin. The default password is “0”. B. Swipe from top to the bottom. C. Select the EDIT icon to register a member tool. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 20 D. ParaMon-Pro X automatically searches for all the tools accessible on the Ethernet and Wi-Fi networks, then displays the detected tools in the table on the right. E. Check the model and serial number on the label or on the Driver Information page. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 21 G. Press [Register] to add the selected tool on the ParaMon-Pro X. H. The selected tool in the list on the right move to the left and the registration process is done. Press [OK] to complete the setting. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 22: Release Member Tools

    A. Repeat the steps in section 5.1 to access the tool list. B. Select the tool you want to release. C. Press [Release] button. D. Once the confirmation pops up, press [OK]. E. Press [OK] to end the settings. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 23: Modify Member Tool Name

    When registering a member tool, the name of the tool is generated by default in the form of Model + Serial Number. If necessary, you can rename the tool for easier tool identification. A. Select the EDIT icon. B. Enter the tool name. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 24: Check Member Tool Status

    Model No. F/W ver Firmware version IP address IP address Port Modbus-TCP port number MAC address MAC address Temperature Realtime temperature Parameter backup & restore Backup/Restore For more information, refer to ‘16. Backup & Restore’. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 25: Status Bar

    Name of the target tool selected Date and present time Wi-Fi adapter Barcode reader BST (Bit Socket Tray) communication is normal Peripheral device status BST (Bit Socket Tray) communication fail MicroSD card USB Storage User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 26: Select Target Tool

    C. Select the target tool on the Member Tool List. Note that target tool is selectable when the tool is normally connected. ( If the target tool is normally selected, its name appears on the Status Bar. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 27: Parameters

    First you should select the tool in the member list. Refer to [ SELECT TARGET TOOL ] to select a tool. The name will be displayed in middle bottom. Unless a target tool is specified, the following page appears. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 28: Monitor

    A. Press Setting and set the graph output. B. Press Start and enable graph output. C. Press Clear and reset data output. D. Press Stop and disable graph output. Information Only the last graph data is displayed. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 29 - 5ms x 200 = 1 000 ms (1 sec) - 10ms x 200 = 2 000 ms (2 sec) - 15ms x 200 = 3 000 ms (3 sec) - 30ms x 200 = 6 000 ms (6 sec) If operating time exceeds the above level, the latest data only appear. . User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 30 Able to check the status of I/O port. If system functions are allocated to the I/O port, function names also appear. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 31: Error

    Error The latest 8 errors from the target tool appear. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 32: Remote

    10. REMOTE 10.1 Output Able to control the level of output port manually. If system functions are allocated to the output port, function names also appear. Useful in checking if properly wired after I/O wiring. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 33: Tool

    Lock Control Able to set the lock by direction if necessary. Tool Initialize Resets all settings to a default state. Alarm Reset Able to clear alarm manually. Run/Stop Run/Stop a target tool according to conditions. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 34: Paramon-Pro X Setting

    With Job: sequencing an assembly process with logical steps- single station - one screwdriver enabled per fas- tening step. Without Job: no sequencing - all screwdrivers enabled - simultaneous fastening operations on several workstations without management. Operation display with Job Operation display without Job User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 35 Suitable for a production line with several simultaneously. workstations and operators. Dedicated to a single workstation Barcode To select a job by scanning a barcode. To select screwdrivers preset scanner Process & fastening results traceability Fastening results traceability User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 36 Stop the running job and load new job. • Retightening failed This option determines how to process if retightening failed. Abort job Stop the running job. Skip screw Skip screw and continue running job. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 37: Global Options

    When ParaMon-Pro X start to collect real-time data from tool, ParaMon-Pro X check how many data stored in tool’s internal memory at first. if there is any data, ParaMon-Pro X collect all data and save log automatically. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 38 If enabled, it will automatically read the day's LOG file at boot time and display the history on the Operation screen. if disabled, the history on the Operation screen starts with a clean state when reboot. This setting does not affect the fastening data saved in daily csv log file. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 39: Options Related To Job Mode Only

    • Buttons access without password: 1, 2, 3, 4 This option determines whether a password is required when a ‘corrective action’ button is selected during job run- ning. No password required Password required Concerns below buttons: User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 40 Example of a pop-up displayed when an interrupted job is resumed: Information Only the last status of each interrupted job is saved. Restart the job at its beginning, initializes the saved progress status. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 41 Preset 3 Preset 4 is MSB (Most Significant Bit). It ranges from 1 to 15 and support up to 15 Presets. Preset 4 Lock Output selection for lock signal provided to I/O tool controller User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 42 Information Please note that you cannot use Back, Reset step after current step is over. • Skip by step This option determines the action of the Skip button. Skip by step Skip by screw User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 43: I/O - Job Mode Only

    Ports assigned to system functions cannot be used in the Input, Output steps when programming a Job. Ports assigned to IO Tool features are highlighted in grey and cannot be changed from this menu. You can clear all assigned functions using the Clear All button. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 44 Load next Job in the Job table. Previous Job Load previous Job in the Job table. Alarm Reset Reset alarm state of Pro X. Emergency Lock all screwdrivers connected to the Pro X. lock This is a software function. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 45: Output Functions For Job Mode

    Assign as Job OK output of the job. Job NG Assign as Job NG output of the job. Ready Output when a job is waiting to run on the Operation screen. Alarm Output when ParaMon-Pro X is in Alarm state. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 46: Log

    If enabled, Graph setting button is enabled. The graphs are only accessible on the ParaMon-Pro X and are stored in a database apart from the log files. • Storage location Sets a log file storage position. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 47 • Select data Fields Able to select data which appear on the screen Saves all data in the log file regardless of settings See examples below: User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 48: Barcode - Without Job Mode & Bm Tools With Integrated Scanner

    - then in Pro X settings. Therefore, up to 2 preset value changes can occur. This section describes how to save code in the Pro X. Refer to BM(T) manuals for how to save code in BM(T) internal memory. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 49 Selects target preset in which the valid regions of registered and scanned codes are matched. • Add to All Tools (Optional) Check the ADD TO ALL TOOLS checkbox and register a code to all tools in ParaMon-Pro X. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 50: Network

    Advanced Able to set manually the AP frequency channels Country: Must be set to Europe. To be checked on both ParaMon-Pro X and each screwdriver. Channel select: Selectable automatic or manual for each band User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 51 Works only if there is a DHCP server on the LAN. Manually sets IP address Static Reckless address settings cause network failure including abnormal operation. Ensure to contact the network manager before setting. Information on active networks is available on the System/Network page. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 52: Share

    Sets the password to be used in logging into the FTP server Able to check the IP address needed to get access to the FTP server in ‘System → Network’ For a method to log into the FTP server, refer to [ FTP SERVER User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 53 Tick the orange box on the left Server IP address Set the IP address of the server on which ParaNet is installed. Port Set the TCP port for communication with ParaNet - default port is 4299. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 54 Tick the orange box on the left. Set TCP port for communication with remote client Port Port must be different from the Modbus relay server port. For details refer to [ Job remote control User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 55: System

    Able to return to the former settings, if necessary, after backing up all current settings. For more information, refer to [ BACKUP & RESTORE • Factory reset Reset to a default state after all files in the repository are deleted including data log files. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 56: Sound

    11.8 Sound You can set sound effects according to the event type and supports .wav files. Fastening OK Fastening NG, Error Fastening↔Loosening change, Barcode scanning, Preset change, and so on Etc. Screen touch User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 57: System

    The update file can be copied from a USB key Click on the file to highlight it. (do not use the select button) Then press [Ok]. After update, all settings, jobs and log files are re- tained. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 58: Storage

    12.2 Storage Internal Storage Able to check the space used and free space Micro SD Able to examine if MicroSD card is inserted and check the space used and free space User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 59: Network

    If IP address is 0.0.0.0 means no ethernet connection is open. Wi-Fi Displays Wi-Fi Access Point network information of USB Wi-Fi dongle. Information If network information is not displayed, check that the USB Wi-Fi adapter and/or Ethernet cable are correctly connected. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 60: Xml

    The XML files selected for connected screwdrivers are those displayed in the XML menu table. Information All screwdrivers of the same model connected to a Pro X must be running the same firmware version. Compatible with the selected XML. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 61: Job Manager

    Deletes the selected job Copy Copes the selected job and adds it as a new job Edit Edits the selected job Rename Renames the selected job Barcode Moves to the barcode registration page for job interlocking User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 62: Edit Job & Step

    Activation or deactivation of process outputs. Output Transition step with several choices: delay time, text message validation or Delay barcode reading. Instruction display (photo or text) to be followed by a delay step defining the Message display duration. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 63 Copies the selected step and adds it as a new step Rename Renames the selected step Edit Step Data Displays the setting page according to the type of the selected step on the step list User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 64: Fastening Step

    6. If necessary, register an image and specify the position of the screw. If the area is touched, a screw-positioning page pops up as follows: To count NG tightening, rework must be selected, with a max number of retightening and a specific retightening preset if necessary. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 65 Able to change the color of a circle which shows a screw position Default: Sets the color which is displayed in a hold state OK: Sets the color which appears when normally fastened NG: Sets the color which appears when abnormally fastened User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 66 A Virtual Preset (VP named on the screwdriver or controller) includes all parameters of a fastening preset plus the advanced functions. The [Load] button is used to import parameters from one of the 15 presets P1 to P15. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 67: Input Step

    Detects a level change from ‘0 (low)’ to ‘1 (high)’ Active Low Detects a level change from ‘1 (high)’ to ‘0 (low)’ Status High Checks ‘level 1 (high)’ Status Low Checks ‘level 0 (low)’ User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 68: Output Step

    Displays level 1 (high) signal Adds a separate output step and disables the port to alter the output to ‘0 (low)’ 4. Set ‘pulse signal duration’ at level 1 (high) from 0 to 5,000ms. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 69: Delay Step

    Moves to the next step if the number of digits and code values in a valid area are matched even through registered and scanned codes differ in terms of total length If the barcode content doesn't care, the selection must be set to 0 - 0. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 70: Message Step

    4096. For optimization, however, ‘1280 x 800 (16:10)’ or ‘1280 x 720 (16:9)’ is recommended. In general, the message step should be programmed to display a message for a certain period by adding a barcode or timer delay step. Without such step, the message appears very shortly. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 71: Job Selection By Barcode

    Moves the selected item to the bottom Registers a new code Delete Deletes selected items Edit Edits selected items Select Changes a mode to select multiple items Select All Selects all items Cancel Ends a multiple item selection mode User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 72 Jobs are loaded if the number of digits and code values in a valid area are matched even through registered and scanned codes differ in terms of total length. 3. Able to set a job to be loaded when a code is scanned at ‘Job Selection’ User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 73: Operation

    Able to register a code and select jobs set when a scanner-integrated BM is Barcode Loads jobs automatically if the registered used Scanner code is scanned. Automatically altered into the Preset if the registered code is scanned User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 74: Operation Display 'With Job Mode

    Depends on setting chap 11.3.1 item ‘Skip to step’ (page 43) Skip Moves to the next screw in the Fastening Step or to next Job Step. (screw or step) Press the SKIP button on the last screw and move to the next step. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 75: Fastening Step

    Reveals a total number of screws according to the Screw Count Unit settings Shows torque in ‘actual torque’ or ‘target torque’ format Displays an error code and error details in the event of ‘NG’ User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 76 In terms of a fastening state, ‘OK’ or ‘NG’ is displayed by color depending on settings. If touched in the Full Screen mode, it is turned off temporarily and switched to the Count page. To return to the Full Screen mode, press the FULL SCREEN button. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 77: Input Step

    LED light is turned on four enabled ports only. LED light is turned on in input-sensed ports such as No.11 and No.12. LED light is off in non-input ports such as No.13 and No.14. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 78: Output Step

    14.1.3 Output Step The above page appears when four inputs were programmed to ‘Impulse’ in the Output Step. LED light is turned on four enabled ports only. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 79: Delay Step

    If the previous step is ‘Message Step’, the timer is executed in the background, and the screen keeps displaying a message. The above page shows the Delay Step set by the message. Check the message and press [OK]. Then, it moves to the next step. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 80 Once the code is scanned in USB Scanner or BM Built-In Scanner, the page moves to the next step. If the previous step is ‘Message Step’, the delay is executed in the background, and the screen keeps displaying a message. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 81: Message Step

    When setting the Message Step, if an image is already registered, it is displayed in full screen. If touched in the Full Screen mode, it is turned off temporarily. To return to the Full Screen mode, press the FULL SCREEN button. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 82: File Browser

    Supports external storage devices (FAT32 file system) such as USB memory and MicroSD and able to sele ct a storage device if the arrow is pressed. Offers a preview feature at the right bottom if a JPG or PNG image file is selected. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 83 Copies the selected files and folders. Move Moves the selected files and folders. Rename Renames the selected files and folders. Disabled if multiple files and folders are selected. Paste Pastes the files and folders chosen in Copy/Move. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 84: Ftp Server

    For the FTP client needed to get access to the FTP server, there are various types of programs. This section uses the most widely used freeware ‘Filezilla Client’. http://filezilla-project.org/ FTP server is activated in ParaMon-Pro X→Settings→Share menu. Refer to [Share] User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 85: Connection Via Wi-Fi

    4. Enter the FTP server’s username from ‘Setting → Network’. The default value is ‘paramon’. 5. Enter the FTP server’s password from ‘Setting → Network’. The default value is ‘prox’. 6. Press [Quickconnect] and log into the FTP server. 7. Check ParaMon-Pro X’s file system. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 86: Connection Via Ethernet

    3. Enter the FTP server’s username from ‘Setting → Network’. The default value is ‘paramon’. 4. Enter the FTP server’s password from ‘Setting → Network’. The default value is ‘prox’. 5. Press [Quickconnect] and log into the FTP server. 6. Check ParaMon-Pro X’s file system. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 87: Backup & Restore

    If different ParaMon-Pro X units need to be backed up or restored, it is recommended to specify an easy-to-identify name in person instead of using the default tool name when registering a member tool. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 88: Backup

    E. Wait until the backup processing is finished. F. If the backup is stored in the internal memory as recommended, copy/move it to an external storage device, using [ FILE BROWSER User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 89: Restore

    17.1.2 Restore A. Press [P2P] in ‘Setting → System’. B. Select “Load …” and press [OK]. C. Select the file and press [OK]. D. Press [OK] and restart the system. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 90: Tools Settings Bm(T) & Md(T)

    A. Press the [BACKUP] icon of the target tool on the Member Tool List. B. Set the backup storage position and filename and press [OK] for backup. The filename is automatically created in ‘Toolname_Model_Fwver.csv’ format. It can be edited if necessary. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 91: Restore

    B. Select the file to be restored. C. If you need to restore only the barcode parameters between different models, check the “Download only barcode parameter” checkbox. D. Click the [OK] button to start the restore. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 92: Software Upgrade

    E. Enter the password again. F. Select the target file and press [Upgrade]. G. Once the Confirmation page pops up, check the target file again and press [OK]. H. Wait until the process is completed. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 93 J. Once successfully reset, log into the system in ADMIN mode again. K. Select ‘System’ in the ADMIN menu. L. Choose ‘Device Info’ on the left. M. Check if successfully upgraded by checking the Software Version. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 94: Maintenance

    During manufacturing the proper functioning of the unit is checked multiple times. However, if the unit malfunctions, troubleshoot it using this list: Warning All troubleshooting tasks requiring the opening of the box must be performed by DOGA or a company authorized by DOGA. Problem...

  • Page 95: Hotline

    Following this procedure allows you to quickly take charge of your request and reduces the troubleshooting costs. DOGA reserve the right to apply a trade-in discount and to invoice, if applicable, the costs of repairing and packaging. 19.5.1 Download the after-sales return form You can download the return form by following this link: http://service.doga.fr/syst/dogatech.nsf/liste/00184...

  • Page 96: Send Your Equipment

    Our services will organize the intervention. 19.7 Warranty DOGA guarantee all his products against any defect in parts or fabrication for a period of 12 months. To benefit from the parts and labor warranty, the following conditions must be respected: •...

  • Page 97: Safety

    Do not remove or damage the labels and annotations affixed to the product, more particularly those imposed by the law. 20.2 Contra-indications Do not cover. Do not immerse. Do not expose to splashing liquids. Do not use near to a heat source. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 98: Standards

    • Clean the tool according to the instruction manual (Maintenance Chapter). • Store it in a suitable container to protect it from dust and direct sunlight. • Store it in a dry place at an ambient temperature, below 40°C. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 99: Weee Recycling And End Of Service Life

    In compliance with the French Environmental Code covering professional Waste Electric and Electronic Equipment (WEEE) (art. R543-195 et seq.), DOGA is a member of ECOSYSTEM, an eco-organization approved by public authorities under the conditions de- fined by art R543-197. You can also benefit from collection and recycling system proposed by ECOSYSTEM for WEEE originating from the professional equipment marketed by DOGA.

  • Page 100: Appendices

    Output COM Output 16 Input COM Output COM Warning An external power supply of 24VDC 1A max. is required to power the I/O commons. The voltage is not distributed by the ParaMon-Pro X controller. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 101: Backup Data Forwarding

    Fastening OK 0x02 Fastening NG (E330,332,333,334,335,336,337,338,339) 0x03 Fastening/Loosening change Status 0x04 Preset change 0x05 Alarm reset 0x06 Error (except fastening NG) 0x07 Barcode scan 0x08 Screw count -1 Snug Snug torque n (0~32) Barcode Barcode User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 102: Modbus Tcp Relay Server

    Pro X and PC cannot access the tool at the same time. In this case, the tool connects to Pro X and the PC can access the tool through Pro X's proxy server. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 103 Unit ID matches Pro X's member tool list. • Modbus-TCP Timeout setting In general, Modbus-TCP timeout is 500ms, but when using Pro X proxy server, a timeout of 1,000ms (1s) or more is recommended. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 104: Job Remote Control

    Please refer to the remote job control settings described in section [Share].to activate this function. Below is the list of remote-control Modbus registers. There is no event monitoring to keep track of the progress of jobs. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 105: Connect And Setup A Bst-Lcd In Usb

    The BST RS-422 port (RJ45 connector) is located on the rear of the product and can be connected to any port, left or right. The BST-LCD must be set to SERIAL for the Protocol parameter. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 106 BST in ‘Slave’ mode In the event list of the screwdriver controller menu, select 'preset change'. Selecting a preset on the screwdriver specifies the bit to be pick up. Tool lock/unlock depends on BST alarm status. User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 107 If the preset number of the fastening step is greater than the number of bits on the BST, the BST will remain in alarm and the tool will be locked. Information The use of Virtual Preset in the fastening steps is not possible with a BST. Only presets P1 to P15 can be selected. User manual ParaMon-Pro X V3 DOC.60513-09/24...

  • Page 108: Connect And Set Up A Bs-5C Via The I/O's

    Input 6 Output: Driver lock Output1 Input 1: select 1 Output2 Input 2: select 2 Output3 Input 3: select 3 Output 4 Input 4: select 4 Out Com Out Com In Com In Com User manual ParaMon-Pro X V3 DOC.60513-09/24...
  • Page 109 B. An input step can be added as a transition so that the fastening step only proceeds if the specified bit has been selected. This step is optional, as the bit tray can lock the screwdriver at any time if it detects a bit selection fault (via input 6). User manual ParaMon-Pro X V3 DOC.60513-09/24...
