ACS ACM1252U-Z6 User Manual

Small nfc reader module

Advertisement

Quick Links

ACM1252U-Z6
Small NFC Reader Module
User Manual V1.00
Subject to change without prior notice
info@acs.com.hk
www.acs.com.hk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACM1252U-Z6 and is the answer not in the manual?

Questions and answers

Summary of Contents for ACS ACM1252U-Z6

  • Page 1 ACM1252U-Z6 Small NFC Reader Module User Manual V1.00 Subject to change without prior notice info@acs.com.hk www.acs.com.hk...
  • Page 2 LED for smart card operation status ................4 2.1.3. Default LED Behaviors ....................4 2.2. Connect ACM1252U-Z6 to another device via USB ............. 5 3.0. Minimum Distances from Conductive Materials............ 6 Appendix A. Connector Specification ................7 List of Figures Figure 1 : LED Configuration ........................
  • Page 3 1.0. Introduction The ACM1252U-Z6 is an NFC reader module with an FFC connector developed based on the 13.56 MHz contactless technology. This NFC Reader Module supports all three NFC modes, namely card reader/writer, card emulation, and peer-to-peer communication. The ACM1252U-Z6 supports ISO 14443 Type A and B cards, MIFARE®, FeliCa, and ISO 18092–compliant NFC tags.
  • Page 4 ACM1252U-Z6. 2.1.3. Default LED Behaviors To control the LEDs’ output and check the LED’s behavior, you may refer to the ACM1252U-Z6 Reference Manual. Page 4 of 7 ACM1252U-Z6 – User Manual info@acs.com.hk...
  • Page 5 2.2. Connect ACM1252U-Z6 to another device via USB A USB port is available to connect the ACM1252U-Z6 to another peripheral or device. To do this: 1. Connect socket (J2) via FFC cable (6 Pins, 0.5mm Pitch) to another peripheral device (see Figure 2).
  • Page 6 3.0. Minimum Distances from Conductive Materials The table below illustrates the recommended minimum distances of the ACM1252U-Z6 from conductive materials. Location Minimum Distance Sides 15 mm Side (with connector) 5 mm Top and Bottom 30 mm Table 1: Recommended Minimum Distances from Conductive Materials Page 6 of 7 ACM1252U-Z6 –...
  • Page 7 Appendix A. Connector Specification Figure 3: ACM1252U-Z6 USB Connector Specification Note: The connector shown in Figure 3 is attached to the PCB. Page 7 of 7 ACM1252U-Z6 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
