LYSON C-01 Manual page 13

Fig 7. Terminated creaming cycle
SETTING UP THE „MIXING CYCLE"
„Mixing cycle" allows to configure the controller for the
permanent operation of the stirrer for one hour.
Activation of this cycle is possible only for the creaming
machines equipped with a heating system (i.e. on the de-
crystalling device)!!!
In order to activate the „Mixing cycle", during the controller
start-up ( ŁYSOŃ-C01 message will appear) one must press
and hold simultaneously the STOP and P buttons.
Once the menu on the display has been entered, the message
informing on the programming mode Prog being active will
appear, when both buttons are released the current
configuration of the "Mixing Cycle" will be displayed
Changing the controller's "Mixing Cycle" configuration is
possible by pressing the P button.
Configuration 1h=on (permanent mixing for one hour) means
that programme 1 h is activated.
Respectively, configuration 1h=off (permanent mixing for one
hour) means that the function 1 h will be deactivated.
Leaving the "programming Cycle" is possible by pressing the
STOP button.
P = 1h (Permanent mixing cycle),
ŁYSOŃ
P
STOP
Fig 8. „Mixing Cycle" of the controller
Once the cover if the creaming machine is opened, the safety
blockage mounted on the device cover will cause the mixing
cycle to stop (stoppage status, if such one has been active)
STOP START
START
Prog.
1h=on/off
WYJŚCIE
The screen will display the message STOP and time
countdown will stop. Closing the cover means returning to the
status in which the controller was before the cover had been
opened, i.e. the stopped cycle will continue.
P
Fig 9. Message about stopping the creaming
4.3. Error signalling
Error codes
FAULT
FAULT DESCRIPTION
CODE
INTERNAL FAULT OF A
E-001
MICROPROCESSOR CONTROLLER
THE START BUTTON PRESSED /
E-002
THE P BUTTON PRESSED /
E-003
THE STOP BUTTON PRESSED /
E-004
5. Temperature regulator
The device has been equipped with a heater with a
temperature regulator - range 0 to 80ºC and power of 2000W.
5.1. Temperature setting
1. Prior to connecting the device to the mains, make sure
STOP
STOP START
machine.
BLOCKED
BLOCKED
BLOCKED
