User Manual
PT-C-HDCEC
2. Technical Specification
Video Input
Input
Input Connector
Input Video Resolution
Video Output
Output
Output Connector
Output Video Resolution
Control
Control
Control Connector
General
HDMI Standard
HDCP Version
HDCP Pass-through
CEC Control
Hot-plug
Bandwidth
HDMI Cable Length
Operation Temperature
Storage Temperature
Relative Humidity
Power Supply
Power Consumption
Dimension (W*H*D)
Net Weight
Note: Please only use high-quality HDMI cables, supporting all characteristics of HDMI 2.0 for a reliable
connection and signal transmission.
(1) HDMI IN
(1) Female type-A HDMI
Up to 4Kx2K@60Hz 4:4:4 8bit
(1) HDMI OUT/CEC
(1) Female type-A HDMI
Up to 4Kx2K@60Hz 4:4:4 8bit
(1) SET Button, (1) 4-pin DIP Switch, (1) FW, (1) IR OUT,
(1) RS232, (1) Sensor, (2) Relay (1~2)
(1) Type-A USB, (1) 3.5mm mini jack, (4) 3-pin terminal blocks
2.0
2.2
Supported
Supported
Supported
18Gbps
1080p@60Hz ≤ 33 feet (10 meters),
4K@60Hz ≤ 16 feet (5 meters)
-5℃ ~ +55℃
-25℃ ~ +70℃
10%-90%
Input:100V~240V AC; Output: 5V DC 1A
Max. 2.5W
120mm x 28mm x 84mm
305g
3
