RS232 Control Setting

6.1.4
Command
RS232ON/+[X]:XXX
RS232ON/-[X]:XXX
RS232OFF/+[X]:XXX
RS232OFF/-[X]:XXX
RS232U/+[X]:XXX
Function
When detecting a triggering signal,
automatically send ASCII command XXX
to the third-party device (e.g. Projector)
whose baud rate is X.
X Baud Rate
1 2400
2 4800
3 9600
4 19200
5 38400
6 57600
7 115200
When detecting a triggering signal,
automatically send HEX command XXX
to the third-party device (e.g. Projector)
whose baud rate is X.
When not detecting any triggering
signal, automatically send ASCII
command XXX to the third-party device
(e.g. Projector) whose baud rate is X.
When not detecting any triggering
signal, automatically send HEX
command XXX to the third-party device
(e.g. Projector) whose baud rate is X.
Set the user-defined ASCII command to
send to the third-party device (e.g.
projector) whose baud rate is X.
Feedback Example
RS232ON/+3:123abc
Send the ASCII command
"123abc" to the third-party
whose baud rate is 9600.
RS232ON/-3:30 31 32
Send the HEX command "30 31
32" to the third-party whose
baud rate is 9600.
RS232OFF/+3:123abc
Send the ASCII command
"123abc" to the third-party
whose baud rate is 9600.
RS232OFF/-3:30 31 32
Send the HEX command "30 31
32" to the third-party whose
baud rate is 9600.
RS232USER/+3:123abc
Send the user-defined command
"123abc" to the third-party
whose baud rate is 9600.
